| Ref | Part Number | Description |
|---|
| 1 |
138-2143 |
ENGINE/GEARBOX ASM (HONDA) Price: $2,176.84 |
| 2 |
122-1227 |
HARNESS-WIRE Price: $216.18 |
| 3 |
138-2050 |
PLATE-HARNESS, WIRE Price: $37.07 |
| 4 |
119-4150 |
WASHER-FLAT Price: $0.64 |
| 5 |
138-2053 |
BELLCRANK COVER ASM Price: $343.10 |
| 6 |
115-5103 |
SCREW-HHF Price: $0.34 |
| 7 |
139-5611 |
BRACKET-CABLE, TRACTION Price: $16.16 |
| 8 |
110-1718 |
SCREW-HHF Price: $1.84 |
| 9 |
138-2145 |
WASHER-FLAT Price: $11.94 |
| 10 |
137-2363 |
SPRING-TORQUE, CLUTCH LEVER Price: $4.37 |
| 11 |
137-2357 |
CLUTCH BRACKET ASM Price: $39.44 |
| 12 |
137-2397 |
LEVER-CLUTCH Price: $89.57 |
| 13 |
324-4 |
SCREW-HH Price: $0.95 |
| 14 |
112-9385 |
IDLER PULLEY ASM Price: $120.06 |
| 15 |
92-9218 |
BELT-V, MATCHED SET Price: $26.55 |
| 16 |
112-9390 |
GUIDE-BELT Price: $31.07 |
| 17 |
3296-45 |
NUT-HEX Price: $3.79 |
| 18 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 19 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 20 |
65-8270 |
WASHER Price: $1.22 |
| 21 |
137-2358 |
Shaft-Traction, Pivot Price: $14.03 |
| 22 |
137-2362 |
PULLEY-DRIVE Price: $73.70 |
| 23 |
33099-00 |
WASHER-FLAT Price: $0.95 |
| 24 |
94-8850 |
KEY-SQUARE Price: $1.26 |
| 25 |
120-2751-01 |
MOUNT-ENGINE Price: $184.90 |
| 26 |
1-323430 |
MODULE-INTERLOCK Price: $130.99 |
| 27 |
120-2697 |
LEVER-THROTTLE Price: $72.97 |
| 28 |
125-5188-03 |
BRACKET-TRACTION Price: $87.05 |
| 29 |
120-2709 |
CABLE-THROTTLE Price: $31.22 |
| 29 |
120-2737 |
CABLE-THROTTLE (GR1600 ONLY) Price: $32.94 |
| 30 |
104-2065 |
SCREW-HWH Price: $0.28 |
| 31 |
112-9420 |
SWITCH-ENGINE Price: $79.51 |
| 32 |
88-7970 |
CLIP Price: $2.51 |
| 33 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 34 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 35 |
125-5248 |
LEVER-TRACTION Price: $66.46 |
| 36 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 37 |
321-5 |
SCREW-HH Price: $0.22 |
| 38 |
132-9579 |
LINKAGE-TRACTION Price: $27.23 |
| 39 |
104-7201 |
NUT-HF Price: $0.69 |
| 40 |
112-9318 |
SCREW-HHF, LOCKING Price: $1.38 |
| 41 |
120-9646 |
WASHER-FLAT Price: $1.02 |
| 42 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 43 |
130-0114 |
PIVOT-TRACTION Price: $30.81 |
| 44 |
65-5080 |
BUSHING-FLANGE Price: $7.85 |
| 45 |
100-1270 |
SWITCH-PROXIMITY Price: $96.57 |
