| Ref | Part Number | Description |
|---|
| 1 |
322-2 |
SCREW-HH Price: $0.69 |
| 2 |
3290-238 |
WASHER-LOCK Price: $2.71 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 3 |
24-9200 |
MTG SPACER Price: $7.91 |
| 4 |
24-9260 |
ADJUSTMENT ROD Price: $94.76 |
| 5 |
3218-2 |
NUT-JAM Price: $0.25 |
| 6 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 7 |
24-9370 |
COMPRESSION SPRING Price: $19.51 |
| 8 |
24-9220 |
DISCONTINUED Price: Call Us |
| 9 |
302-22 |
FITTING-GREASE Price: $1.30 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) Price: $11.99 |
| 10 |
237-21 |
O-RING Price: $0.70 |
| 11 |
3245-1 |
SCREW-SET, HSH Price: $0.54 |
| 12 |
24-9330 |
LH PIVOT ARM WA *R Price: $188.13 |
| 12 |
532405140 |
PULLEY.ENGINE.5.0.PD Price: $44.99 |
| 13 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 14 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 15 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 15 |
581290101 |
TANK.ASSEMBL.2.5GAL.NON-EPA This part replaces 532407489. Price: $99.99 |
| 16 |
321-9 |
SCREW-HH This part replaces 322-23. Price: $0.27 |
| 17 |
256-116 |
BUSHING-FLANGE Price: $3.52 |
| 18 |
24-9320 |
LH BASE PLATE WA Price: $113.84 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532197725. Price: $22.99 |
| 19 |
24-9240 |
DISCONTINUED Price: Call Us |
| 20 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 20 |
532401508 |
CONTROL.TH/CK.COBRA.KO Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 28 |
587044822 |
HOSE.1/4".LOW.PERM.FUEL.LN.22" This part replaces 532401137. Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 69 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE This part replaces 532188654. Price: $27.99 |
| 95 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
