| Ref | Part Number | Description |
|---|
| 2 |
586727401 |
KNOB, THREADED This part replaces 535473701. Price: $9.99 |
| 3 |
506570104 |
BOLT Price: $4.99 |
| 4 |
544403101 |
BRAKE LEVER ASSY Price: $19.99 |
| 5 |
725236461 |
SCREW Price: $2.99 |
| 6 |
506946301 |
SPRING Price: $7.99 |
| 7 |
576712101 |
BRAKE WIRE This part replaces 535489601. Price: $32.99 |
| 8 |
735310920 |
E-RING 5 Price: $3.99 |
| 9 |
506535603 |
SPRING Price: $4.99 |
| 10 |
105-3735 |
CONTROL PLATE ASM Price: $167.82 |
| 10 |
582152001 |
CONTROL CABLE TRANSMISSION This part replaces 506827202. Price: $69.99 |
| 11 |
578776801 |
CONNECTOR, BALL JOINT This part replaces 506557301. Price: $9.99 |
| 12 |
732211401 |
LOCKNUT M5 Price: $2.99 |
| 13 |
731231401 |
NUT Price: $1.99 |
| 14 |
522430801 |
BRACKET This part replaces 544341701. Price: $5.99 |
| 15 |
725236461 |
SCREW Price: $2.99 |
| 16 |
738210204 |
BALL BEARING 6002-2RS1 Price: $7.99 |
| 17 |
535459901 |
ROLLER This part replaces 535480201. Price: $15.99 |
| 18 |
535459601 |
PLATE This part replaces 535480601. Price: $6.99 |
| 19 |
535459501 |
SPRING This part replaces 535480701. Price: $7.99 |
| 20 |
506506501 |
PEDAL SHAFT CLAMP This part replaces 535480801. Price: $6.99 |
| 20 |
98-9662 |
LEVER-CONTROL, SPEED Price: $72.44 |
| 21 |
506954101 |
SUPPORT This part replaces 535480901. Price: $5.99 |
| 22 |
506804101 |
PLATE This part replaces 535481001. Price: $5.99 |
| 23 |
586966401 |
PEDAL RUBBER This part replaces 535478801. Price: $14.99 |
| 24 |
586966402 |
PEDAL RUBBER L = 102MM This part replaces 535478802. Price: $14.99 |
| 30 |
98-9572 |
LEVER-CONTROL, SPEED Price: $47.15 |
| 40 |
105-3788 |
O-RING Price: $2.90 |
| 50 |
98-7602 |
PIN-SPRING Price: $0.64 |
| 60 |
98-9594 |
WASHER-PLAIN Price: $2.49 |
| 70 |
98-9589 |
NUT Price: $1.46 |
| 80 |
98-9658 |
GOVERNOR LEVER ASM Price: $34.84 |
| 90 |
98-9663 |
LEVER-STOP, ENGINE Price: $13.34 |
| 100 |
98-7601 |
SEAL-OIL Price: $7.88 |
| 110 |
98-9472 |
SPRING-RETURN Price: $8.91 |
| 120 |
98-9664 |
SHAFT-LEVER, STOP Price: $33.92 |
| 130 |
98-9637 |
GASKET Price: $3.98 |
| 140 |
98-7692 |
BOLT Price: $0.92 |
| 150 |
105-3710 |
STUD Price: $1.16 |
| 160 |
98-7572 |
NUT Price: $0.32 |
| 180 |
99-8348 |
BOLT Price: $0.24 |
| 190 |
98-7654 |
GASKET Price: $8.84 |
| 200 |
117-7565 |
BOLT-ADJUSTING Price: $2.66 |
| 210 |
117-7566 |
BOLT-ADJUSTING Price: $4.96 |
