| Ref | Part Number | Description |
|---|
| 1 |
537299201 |
OIL PUMP Price: $109.99 |
| 1 |
68-705-4053-01 |
FRAME-MAIN Price: $1,620.88 |
| 2 |
740420300 |
O-RING Price: $3.99 |
| 2 |
95-0082-01 |
ARM-MAIN, RH Price: $116.62 |
| 3 |
503230016 |
WASHER 5.1X8.5 Price: $3.99 |
| 3 |
95-0081-01 |
ARM-MAIN, LH Price: $116.62 |
| 4 |
105-7893 |
BRACKET-SPRING, INNER Price: $57.68 |
| 4 |
503184901 |
SPRING Price: $3.99 |
| 5 |
105-7894 |
BRACKET-SPRING, OUTTER Price: $80.80 |
| 5 |
503230016 |
WASHER 5.1X8.5 Price: $3.99 |
| 6 |
01-261-0190 |
SPRING Price: $229.23 |
| 6 |
503808303 |
PUMP PISTON This part replaces 503808302. Price: $17.99 |
| 7 |
327-6 |
SCREW-HH Price: $12.99 |
| 7 |
725532755 |
SCREW MC6S 5X12 Price: $2.99 |
| 8 |
537281502 |
OIL TANK CAP GREY Price: $8.99 |
| 8 |
68-604-3481 |
WASHER Price: $4.82 |
| 9 |
593620401 |
Caps Price: $17.99 |
| 9 |
68-604-3151 |
WASHER-PIVOT Price: $3.59 |
| 10 |
01-125-0050 |
BUSHING Price: $16.49 |
| 11 |
3256-7 |
WASHER-FLAT Price: $0.75 |
| 12 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 12 |
725532955 |
SCREW MC6S 5X16 Price: $6.99 |
| 13 |
3218-6 |
NUT-JAM Price: $0.61 |
| 13 |
537330101 |
RING Price: $11.99 |
| 14 |
01-158-0310 |
BOLT-SHOULDER, SOCKET HEAD Price: $7.80 |
| 14 |
537291001 |
O-RING Price: $4.99 |
| 15 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 15 |
537291101 |
HOSE Price: $5.99 |
| 16 |
13-404-0221 |
WASHER-PIVOT Price: $4.14 |
| 16 |
537371501 |
CLIP Price: $3.99 |
| 17 |
504710003 |
OIL PLUMMET Price: $9.99 |
| 17 |
68-604-3491 |
WASHER Price: $3.32 |
| 18 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 18 |
504340004 |
NIPPLE Price: $5.99 |
| 19 |
01-168-2018 |
BUSHING Price: $1.76 |
| 19 |
537371501 |
CLIP Price: $3.99 |
| 20 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 20 |
537290901 |
RETAINING RING Price: $3.99 |
| 21 |
106-0289 |
BEARING-FLANGE Price: $138.00 |
| 21 |
537056801 |
SCREW Price: $3.99 |
| 22 |
323-8 |
SCREW-HH Price: $1.20 |
| 22 |
503978201 |
SPRING Price: $3.99 |
| 23 |
537331701 |
SEALING Price: $9.99 |
| 23 |
68-604-3181 |
SHAFT-AERATOR Price: $329.15 |
| 24 |
140-6430 |
AERATOR WHEEL ASSEMBLY This part replaces 44-004-0262. Price: $350.87 |
| 24 |
537228201 |
CHAIN TENSIONER Price: $11.99 |
| 25 |
537194201 |
PLATE Price: $9.99 |
| 26 |
68-604-3421 |
SPACER-CENTER Price: $28.26 |
| 26 |
738210004 |
BALL BEARING Price: $24.99 |
| 27 |
68-604-3451 |
SPACER-INSIDE Price: $7.92 |
| 27 |
735312710 |
RETAINING RING SGH 26 Price: $2.99 |
| 28 |
68-604-3431 |
SPACER-END Price: $8.12 |
| 28 |
735311200 |
RETAINING RING SGA 10 Price: $2.99 |
| 29 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 29 |
575541801 |
CHAIN GUARD This part replaces 575553701. Price: $24.99 |
| 30 |
3217-9 |
NUT-HH Price: $0.37 |
| 31 |
3218-7 |
NUT-JAM Price: $3.86 |
| 31 |
537299001 |
GEAR Price: $219.99 |
| 32 |
01-168-1614 |
BUSHING Price: $0.82 |
| 32 |
738219904 |
BALL BEARING Price: $22.99 |
| 33 |
68-604-3171-01 |
ARM-MAIN, END Price: $146.74 |
| 33 |
725533355 |
SCREW MC6S 5X25 Price: $3.99 |
| 34 |
327-7 |
SCREW-HH Price: $5.69 |
| 34 |
731231801 |
NUT Price: $3.99 |
| 35 |
3217-11 |
NUT-HEX Price: $0.95 |
| 36 |
68-705-4061-01 |
ARM-LIFT, LH Price: $582.69 |
| 36 |
725532755 |
SCREW MC6S 5X12 Price: $2.99 |
| 37 |
106-0228 |
ARM-LIFT, RH Price: $582.69 |
| 37 |
537227401 |
HOUSING Price: $149.99 |
| 38 |
68-704-4201-01 |
STABILIZER-HITCH Price: $32.03 |
| 38 |
738219904 |
BALL BEARING Price: $22.99 |
| 39 |
01-252-0010 |
LIFT ARM PIN ADJUSTMENT ASM Price: $20.22 |
| 39 |
537247701 |
SPACER SLEEVE Price: $19.99 |
| 40 |
01-168-2010 |
BUSHING Price: $2.51 |
| 40 |
738219904 |
BALL BEARING Price: $22.99 |
| 41 |
328-8 |
SCREW-HH Price: $5.54 |
| 41 |
735311100 |
RETAINING RING Price: $2.99 |
| 42 |
3256-8 |
WASHER-FLAT Price: $1.09 |
| 42 |
735312510 |
RETAINING RING Price: $2.99 |
| 43 |
3253-9 |
WASHER-LOCK Price: $1.02 |
| 43 |
731711651 |
FLANGE NUT Price: $3.99 |
| 44 |
3217-12 |
NUT-HEX Price: $3.12 |
| 44 |
608000086 |
RIM .325-7T This part replaces 505303672. Price: $11.24 |
| 45 |
328-2 |
SCREW-HH Price: $6.51 |
| 45 |
503230084 |
NEEDS DESCRIPTION Price: Call Us |
| 46 |
325-8 |
SCREW-HH Price: $3.52 |
| 46 |
522704801 |
NEEDS DESCRIPTION Price: Call Us |
| 47 |
01-168-2014 |
BUSHING Price: $1.83 |
| 47 |
537271701 |
VIBRATION ABSORBER Price: $5.99 |
| 48 |
537271401 |
FLYWHEEL Price: $24.99 |
| 48 |
68-604-3571-01 |
MOUNT-SPRING This part replaces 68-604-3571. Price: $17.16 |
| 49 |
01-506-0640 |
DECAL Price: $34.09 |
| 49 |
537271601 |
COVER Price: $17.99 |
| 50 |
67-1300 |
DECAL Price: $29.99 |
| 51 |
577981901 |
NEEDS DESCRIPTION Price: Call Us |
| 52 |
2412-133 |
CLAMP-R Price: $3.19 |
| 52 |
501819901 |
SCREW M5X14 Price: $2.99 |
| 53 |
01-161-0020 |
RIVET-POP Price: $0.95 |
| 53 |
575541801 |
CHAIN GUARD Price: $24.99 |
| 54 |
104-7048 |
CAP-HOUSING Price: $5.21 |
| 54 |
503222401 |
NUT Price: $1.99 |
| 55 |
58-6520 |
DECAL-GREASE Price: $2.57 |
