| Ref | Part Number | Description |
|---|
| 2 |
93-7977 |
SEAL Price: $74.14 |
| 3 |
93-7978 |
ROD-PULL Price: $171.95 |
| 4 |
93-7983 |
PIN-CLEVIS Price: $3.19 |
| 5 |
93-7980 |
LINK Price: $13.85 |
| 6 |
93-7979 |
PIN-HITCH Price: $1.70 |
| 7 |
93-7986 |
DISC-STATIONARY Price: $26.25 |
| 8 |
104-4278 |
DISC-ROTATING Price: $55.70 |
| 9 |
93-7976 |
RING-RETAINING Price: $12.48 |
| 10 |
93-7984 |
GASKET Price: $20.21 |
| 11 |
104-4279 |
ACTUATOR-ROTATING Price: $332.95 |
| 12 |
93-7987 |
SPRING-EXTENSION Price: $9.47 |
| 13 |
93-7985 |
BALL Price: $9.39 |
| 14 |
353-990 |
PLUG ASM Price: $10.01 |
| 284 |
94704 |
SCREW, AIR CLEANER Price: Call Us |
| 284A |
94903 |
SCREW, HEX HEAD Price: Call Us |
| 294 |
810068 |
SCREW, SET Price: Call Us |
| 304 |
496281 |
HOUSING, BLOWER Price: Call Us |
| 305 |
94930 |
SCREW Price: Call Us |
| 306 |
225020 |
SHIELD, CYLINDER Price: Call Us |
| 307 |
94623 |
SCREW, SEMS, CYLINDER SHIELD MTG. Price: Call Us |
| 309 |
497595 |
MOTOR, STARTING, 12 VOLT Price: Call Us |
| 310 |
497602 |
BOLT, THRU Price: Call Us |
| 311 |
497608 |
BRUSH SET Price: Call Us |
| 333 |
495859 |
ARMATURE, MAGNETO Price: Call Us |
| 334 |
93381 |
SCREW, SEM, ARMATURE MOUNTING Price: Call Us |
| 337 |
491055 |
PLUG, SPARK Price: Call Us |
| 346 |
94909 |
SCREW, HEX HEAD Price: Call Us |
| 356 |
497708 |
WIRE ASSY Price: Call Us |
| 356A |
494705 |
WIRE, STOP Price: Call Us |
| 358 |
495993 |
GASKET SET Price: Call Us |
| 363 |
19203 |
PULLER, FLYWHEEL Price: Call Us |
| 383 |
89838 |
WRENCH SPARK PLUG Price: Call Us |
| 423 |
94903 |
SCREW, HEX HEAD Price: Call Us |
| 445 |
496894 |
CARTRIDGE, AIR CLEANER Price: Call Us |
| 455 |
222561 |
CUP, SCREEN MOUNTING Price: Call Us |
| 467 |
493903 |
KNOB, AIR CLEANER Price: Call Us |
| 474 |
393474 |
STATOR, ALTERNATOR, DUAL CIRCUIT Price: Call Us |
| 482 |
93621 |
SCREW, SEMS Price: Call Us |
| 503 |
806000 |
STRAP, STARTER Price: Call Us |
| 510 |
497606 |
DRIVE, STARTER Price: Call Us |
| 523 |
495230 |
CAP AND DIPSTICK, OIL FILLER Price: Call Us |
| 524 |
68838 |
SEAL, FILLER TUBE Price: Call Us |
| 525 |
496113 |
TUBE, OIL FILLER Price: Call Us |
| 535 |
272403 |
ELEMENT, AIR CLEANER Price: Call Us |
| 537 |
281106 |
O-RING, AIR CLEANER Price: Call Us |
| 544 |
497603 |
ARMATURE, STARTER Price: Call Us |
| 552 |
231597 |
BUSHING, GOVERNOR CRANK, 1/4" I.D. Price: Call Us |
| 562 |
94907 |
BOLT, GOVENOR LEVEL Price: Call Us |
| 592 |
231978 |
NUT, HEX Price: Call Us |
| 601 |
93053 |
CLAMP, HOSE, GREEN Price: Call Us |
| 611 |
493496 |
ELBOW, FUEL PIPE Price: Call Us |
| 614 |
93306 |
COTTER, HAIR PIN Price: Call Us |
| 615 |
263080 |
RETAINER Price: Call Us |
| 618 |
262803 |
SPRING, CHOKE RETURN Price: Call Us |
| 634 |
281168 |
SEAL, CHOKE SHAFT Price: Call Us |
| 634A |
491323 |
SEAL, GOVERNOR Price: Call Us |
| 634B |
281167 |
WASHER, THROTTLE SHAFT Price: Call Us |
| 635 |
280872 |
ELBOW, SPARK PLUG Price: Call Us |
| 646 |
224546 |
BRACE, AIR CLEANER Price: Call Us |
| 653 |
93585 |
SCREW, HEX HEAD Price: Call Us |
| 657 |
94906 |
SCREW Price: Call Us |
| 663 |
94929 |
SCREW, SELF-TAPPING Price: Call Us |
| 668 |
280848 |
SPACER Price: Call Us |
| 718 |
230192 |
PIN, DOWEL Price: Call Us |
| 726 |
392134 |
GEAR, RING Price: Call Us |
| 727 |
490324 |
COVER, STARTER Price: Call Us |
| 728 |
94951 |
SCREW, HEX HEAD Price: Call Us |
| 729 |
225170 |
RETAINER, WIRE Price: Call Us |
| 729A |
281390 |
CLIP, WIRE Price: Call Us |
| 741 |
262932 |
GEAR, TIMING Price: Call Us |
| 757 |
213998 |
LINK, COUNTERWEIGHT Price: Call Us |
| 758 |
399891 |
COUNTERWEIGHT ASSY Price: Call Us |
| 759 |
289909 |
PIN, COUNTERWEIGHT Price: Call Us |
| 761 |
94593 |
SCREW, COUNTERWEIGHT Price: Call Us |
| 783 |
280104 |
GEAR, STARTER Price: Call Us |
| 801 |
394856 |
CAP, DRIVE Price: Call Us |
| 802 |
497605 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 803 |
497604 |
HOUSING, STARTER Price: Call Us |
| 842 |
270920 |
SEAL, OIL FILLER CAP Price: Call Us |
| 847 |
496415 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 851 |
224110 |
TERMINAL, IGNITION CABLE Price: Call Us |
| 868 |
494435 |
SEAL ASSEMBLY, VALVE Price: Call Us |
| 868A |
272610 |
GASKET, VALVE Price: Call Us |
| 871 |
262835 |
BUSHING, GUIDE (INTAKE & EXHAUST) Price: Call Us |
| 872 |
281104 |
COVER, AIR CLEANER Price: Call Us |
| 875 |
495862 |
BODY, AIR CLEANER Price: Call Us |
| 877 |
393456 |
DIODE & CONNECTOR ASSY Price: Call Us |
| 947 |
497157 |
SOLENOID Price: Call Us |
| 965 |
94010 |
LOCKNUT, AIR CLEANER MOUNTING Price: Call Us |
| 975 |
495933 |
BOWL ASSEMBLY, CARBURETOR Price: Call Us |
| 977 |
494385 |
CARBURETOR GASKET KIT Price: Call Us |
| 987 |
281166 |
SEAL, THROTTLE SHAFT Price: Call Us |
| 1005 |
281355 |
FAN, FLYWHEEL Price: Call Us |
| 1006 |
224413 |
RETAINER, FAN Price: Call Us |
| 1019 |
496758 |
LABEL KIT Price: Call Us |
| 1022 |
272475 |
GASKET, COVER Price: Call Us |
| 1023 |
224552 |
COVER, ROCKER ARM Price: Call Us |
| 1026 |
494432 |
ROD, PUSH, INTAKE Price: Call Us |
| 1029 |
224554 |
ARM, ROCKER Price: Call Us |
| 1033 |
495992 |
VALVE OVERHAUL KIT Price: Call Us |
| 1034 |
495248 |
GUIDE ASSEMBLY, PUSH ROD Price: Call Us |
| 1044 |
94673 |
SCREW, SHOULDER, HEX HEAD Price: Call Us |
| 1058 |
272623 |
MANUAL, OWNER'S Price: Call Us |
| 1090 |
497607 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 495136 |
ROD, |
PUSH, EXHAUST Price: Call Us 495136 |
