| Ref | Part Number | Description |
|---|
| 1 |
3210-1 |
SCREW-HH Price: $6.29 |
| 1 |
530039127 |
Flywheel Price: $3.33 |
| 2 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 2 |
530001733 |
Nut Price: $2.99 |
| 3 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 3 |
530015254 |
Wave Washer Price: $1.99 |
| 4 |
5-1684-01 |
SKID WA This part replaces 5-1684. Price: $216.45 |
| 4 |
530027163 |
Retainer Price: $0.28 |
| 5 |
3-8058 |
Tube, Reel Price: Call Us |
| 5 |
530027170 |
Starter Pulley Price: $3.40 |
| 6 |
4-2319 |
DISCONTINUED Price: Call Us |
| 6 |
545008009 |
KIT STARTER SPRING This part replaces 530042067. Price: $5.99 |
| 7 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 7 |
530027096 |
Baffle Plate Price: $3.33 |
| 8 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 8 |
530010856 |
Fan Housing Price: $7.28 |
| 9 |
5-5101 |
DISCONTINUED This part replaces 5-1252. Price: Call Us |
| 9 |
530015425 |
Screw This part replaces 530015709. Price: $0.99 |
| 10 |
5-2186 |
REEL BEARING This part replaces 5-2183. Price: $45.95 |
| 10 |
530015441 |
Washer Price: $1.99 |
| 11 |
3-8073 |
DISCONTINUED Price: Call Us |
| 11 |
530015713 |
Screw Price: $1.99 |
| 12 |
322-3 |
SCREW-HH Price: $0.79 |
| 12 |
530027765 |
Starter Cam Price: $1.99 |
| 13 |
5-1240 |
DISCONTINUED Price: Call Us |
| 13 |
530027162 |
Starter Dog Price: $1.99 |
| 14 |
3-6665 |
BEARING CUP BOLT Price: $10.16 |
| 14 |
530015241 |
Screw Price: $1.99 |
| 15 |
3-6623 |
REEL BEARING SCREW Price: $36.51 |
| 15 |
530027569 |
Handle-Starter This part replaces 530026735. Price: $1.99 |
| 16 |
3-8623 |
DISCONTINUED Price: Call Us |
| 16 |
530069233 |
Rope Kit Price: $3.33 |
| 17 |
3-6676 |
Stud Price: Call Us |
| 17 |
530015720 |
Bolt Price: $1.99 |
| 18 |
3219-5 |
NUT-HEX Price: $1.22 |
| 18 |
530001516 |
Snap Ring Price: $1.99 |
| 19 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 19 |
530015696 |
Clip Price: $0.99 |
| 20 |
3-6677 |
DISCONTINUED Price: Call Us |
| 21 |
5-2805 |
DISCONTINUED This part replaces 3-8051. Price: Call Us |
| 21 |
530015425 |
Screw This part replaces 530015708. Price: $0.99 |
| 22 |
3-8042 |
DISCONTINUE Price: Call Us |
| 23 |
5-1310 |
Shaft, Reel Drive Price: Call Us |
| 24 |
5-1313 |
REEL DRIVE PAD Price: $29.55 |
| 24 |
530015306 |
Screw Price: $1.99 |
| 25 |
3-6626 |
DISCONTINUE Price: Call Us |
| 25 |
530027264 |
Clamp Price: $1.99 |
| 26 |
3-6625 |
DISCONTINUED Price: Call Us |
| 26 |
530032093 |
Crankshaft Bearing Price: $7.99 |
| 27 |
3-6624 |
DISCONTINUED Price: Call Us |
| 27 |
530002595 |
Flywheel Key Price: $1.99 |
| 28 |
3-8041 |
DISCONTINUED Price: Call Us |
| 28 |
530027143 |
Crankshaft/Rod Ass'y. Price: $129.99 |
| 29 |
530032111 |
Piston Pin Bearing Price: $12.99 |
| 30 |
5-2288 |
DISCONTINUED Price: Call Us |
| 30 |
530010862 |
Model 3000 Price: $59.99 |
| 30 |
530010864 |
Model 2700,2800 Price: $59.99 |
| 30 |
530010986 |
Model 3100,3300 Price: $3.33 |
| 31 |
5-0878 |
DISCONTINUED Price: Call Us |
| 31 |
530015710 |
Screw Price: $3.33 |
| 32 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 32 |
530027184 |
Spur Price: $1.99 |
| 33 |
5-1840 |
Tube, Reel Price: Call Us |
| 33 |
530019146 |
Crankshaft Seal Price: $2.99 |
| 34 |
3217-6 |
NUT-HEX Price: $1.19 |
| 35 |
121-4698 |
NUT-KEPS This part replaces 32149-5. Price: $1.15 |
| 35 |
530015718 |
Screw Price: $0.24 |
| 36 |
3290-250 |
PIN-COTTER Price: $5.59 |
| 36 |
530015722 |
Washer Price: $1.99 |
| 37 |
5-1686 |
ADJ ROD Price: $41.75 |
| 37 |
530028645 |
Muffler Cover Price: $3.99 |
| 38 |
3-8045 |
Guard, Reel Price: Call Us |
| 38 |
530027095 |
Spark Arrestor Screen Price: $2.99 |
| 39 |
282-1 |
DISCONTINUED Price: Call Us |
| 39 |
530028647 |
Muffler Diffuser Price: $3.99 |
| 40 |
283-2 |
PIN-CLEVIS Price: $12.99 |
| 40 |
530028646 |
Muffler Baffle Plate Price: $1.99 |
| 41 |
3290-212 |
WASHER-SPRING Price: $1.56 |
| 41 |
530028644 |
Muffler Body Price: $4.99 |
| 42 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 42 |
530012153 |
Model 3000 Price: $2.00 |
| 42 |
530012155 |
Model 2700,2800 Price: $84.99 |
| 42 |
530012200 |
Model 3100,3300 Price: $2.08 |
| 43 |
322-2 |
SCREW-HH Price: $0.69 |
| 43 |
530030034 |
Spark Plug (CJ-4) Price: $3.44 |
| 44 |
5-1241 |
DISCONTINUED Price: Call Us |
| 44 |
530030054 |
Sealant Price: $17.99 |
| 45 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 45 |
530069227 |
Decal Kit Price: $3.33 |
| 46 |
5-4553 |
DISCONTINUED This part replaces 5-0871. Price: Call Us |
| 46 |
530015697 |
Retainer Price: $1.99 |
| 47 |
3-1058 |
DISCONTINUED Price: Call Us |
| 47 |
530001624 |
Screw Price: $1.99 |
| 48 |
3220-3 |
NUT-HJ Price: $0.28 |
| 49 |
3-7771 |
DISCONTINUED Price: Call Us |
| 49 |
530027218 |
Carburetor Adaptor Price: $6.96 |
| 50 |
3-1131 |
DISCONTINUED Price: Call Us |
| 50 |
530027090 |
Model 2700,2800 Price: $4.99 |
| 50 |
530027092 |
Model 3000 Price: $5.00 |
| 50 |
530027607 |
Model 3100,3300 Price: $3.33 |
| 51 |
3272-17 |
PIN-COTTER Price: $1.79 |
| 51 |
530015707 |
Screw Price: $1.99 |
| 52 |
3-6688 |
DISCONTINUED Price: Call Us |
| 52 |
530027285 |
Clamp Ass'y. Price: $2.99 |
| 53 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 54 |
5-0744 |
DISCONTINUED Price: Call Us |
| 55 |
5-2298 |
DISCONTINUE Price: Call Us |
| 56 |
5-1248 |
DISCONTINUED Price: Call Us |
| 57 |
5-2296 |
OUTBOARD BRG CUP WA Price: $57.47 |
| 58 |
5-1258 |
Stud, Pivot Price: Call Us |
| 59 |
251-123 |
DISCONTINUED Price: Call Us |
| 60 |
4-2390 |
WASHER-FLAT Price: $0.62 |
| 62 |
5-2277 |
DISCONTINUED Price: Call Us |
| 63 |
3290-248 |
DISCONTINUED Price: Call Us |
| 172 |
530027838 |
Deflector (Model 3300 Only) Price: $1.99 |
