| Ref | Part Number | Description |
|---|
| 2 |
705499 |
PANEL-CONTROL Price: $434.99 |
| 3 |
703804 |
SCREW Price: $3.63 |
| 4 |
705500 |
DECAL Price: $57.99 |
| 5 |
319065GS |
DECAL Price: $5.78 |
| 6 |
704183 |
GAUGE-FUEL Price: $15.07 |
| 7 |
314440GS |
SCREW Price: $3.61 |
| 8 |
202997GS |
DECAL Price: $12.80 |
| 9 |
319064GS |
DECAL Price: $6.00 |
| 10 |
703805 |
SCREW Price: $8.89 |
| 11 |
312005GS |
WASHER Price: $3.09 |
| 12 |
703264 |
DECAL Price: $15.53 |
| 13 |
705504 |
FILTER-FUEL Price: $5.87 |
| 14 |
705520 |
TANK-FUEL Price: $274.99 |
| 15 |
704142 |
DECAL Price: $11.12 |
| 16 |
705489 |
HEATSHIELD Price: $45.49 |
| 17 |
705503 |
HEATSHIELD Price: $79.99 |
| 18 |
704331 |
DECAL Price: $8.79 |
| 20 |
319066GS |
DECAL Price: $9.79 |
| 21 |
319587GS |
CAP-FUEL Price: $18.25 |
| 23 |
87680GS |
NUT Price: $6.57 |
| 25 |
319451GS |
MOUNT-VIBRATION Price: $10.58 |
| 28 |
590703 |
SCREW This part replaces 706166. Price: $2.79 |
| 29 |
706165 |
WIRE Price: $7.09 |
| 30 |
797770 |
GASKET, Exhaust This part replaces 813085GS. Price: $5.72 |
| 33 |
83083GS |
SCREEN Price: $8.49 |
| 34 |
192569GS |
MUFFLER Price: $148.05 |
| 35 |
590850 |
SCREW This part replaces 706152. Price: $3.02 |
| 36 |
705501 |
BRACKET-MUFFLER Price: $15.68 |
| 38 |
57821GS |
HHCS-M8-1.25 x 40 Price: $1.60 |
| 39 |
207824GS |
SCREW Price: $3.73 |
| 40 |
313364GS |
END COVER Price: $26.20 |
| 41 |
704140 |
STATOR Price: $402.63 |
| 42 |
704202 |
ROTOR Price: $291.49 |
| 43 |
317340GS |
BOLT Price: $5.99 |
| 44 |
317341GS |
BOLT Price: $5.99 |
| 45 |
708704 |
CARRIER-BEARING This part replaces 207838GS. Price: $90.94 |
| 46 |
207840GS |
VOLTAGE REGULATOR Price: $40.40 |
| 47 |
207827GS |
BRUSH ASSY Price: $9.35 |
| 48 |
316945GS |
TERMINAL BLOCK Price: $7.37 |
| 49 |
317338GS |
BOLT Price: $11.29 |
| 51 |
209417GS |
VALVE-FUEL Price: $7.75 |
| 53 |
317342GS |
BAND-STATOR Price: $8.29 |
| 54 |
207879GS |
BOOT Price: $6.22 |
| 55 |
207878GS |
NUT Price: $5.79 |
| 56 |
706376 |
COVER-RUBBER Price: $3.38 |
| 57 |
207826GS |
WASHER Price: $2.96 |
