| Ref | Part Number | Description |
|---|
| 1 |
104-4620 |
SEAT This part replaces 66-5400. Price: $273.15 |
| 1 |
539111331 |
FAN COVER W/DECALS Price: $179.99 |
| 2 |
539108941 |
BLOWER HOUSING WELDMENT Price: $399.99 |
| 2 |
92-6534 |
ORDER COMPLETE SEAT This part replaces 67-9560. Price: Call Us |
| 3 |
283-72 |
PIN-LYNCH Price: $9.12 |
| 3 |
539109900 |
LOWER HOUSING Price: $149.99 |
| 4 |
3296-54 |
NUT-LOCK Price: $3.59 |
| 4 |
539106786 |
BEARING KIT-2 PCS Price: $44.99 |
| 5 |
539110111 |
FAN WELDMENT Price: $179.99 |
| 5 |
83-6630 |
SHIM - SWITCH Price: $5.56 |
| 6 |
539102691 |
BRG FLANGE Price: $3.99 |
| 6 |
75-6330 |
DISCONTINUED Price: Call Us |
| 7 |
539108301 |
COVER PLATE WELDMENT Price: $60.99 |
| 8 |
539106713 |
SHEAVE 4" Price: $54.99 |
| 8 |
83-6640 |
SENSOR - REED SWITCH Price: $223.35 |
| 9 |
539106715 |
IDLER ARM Price: $34.99 |
| 9 |
83-6700 |
SUSPENSION PLATE WA *B Price: $178.89 |
| 10 |
539101836 |
BUSHING, SLEEVE Price: $2.99 |
| 10 |
85-6160 |
PIN SPRING Price: $34.80 |
| 11 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 11 |
595281301 |
Caps This part replaces 539102535. Price: $4.99 |
| 12 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 12 |
539106721 |
PULLEY Price: $25.99 |
| 13 |
32121-4 |
PIN-ROLL, SLOTTED Price: $3.49 |
| 13 |
539106741 |
EURO DECAL, IMPELLER Price: $5.99 |
| 14 |
27-4720 |
SHAFT-PIVOT, SEAT Price: $32.27 |
| 14 |
539106801 |
SPRING ROD WLDMNT Price: $99.99 |
| 15 |
539106720 |
SPRING Price: $22.99 |
| 15 |
83-6690 |
SEAT PLATE WA *B Price: $237.12 |
| 16 |
539105785 |
DECAL, EURO WARNING Price: $8.99 |
| 16 |
85-6140 |
SPRING Price: $38.33 |
| 17 |
539101050 |
GRIP Price: $2.99 |
| 17 |
92-6533 |
SEAT CUSHION KIT This part replaces 67-9550. Price: $290.43 |
| 18 |
539990037 |
COTTER PIN 3/32 X 3/4 Price: $2.99 |
| 18 |
69-0770 |
BRACKET-ARM, RH Price: $117.82 |
| 19 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 19 |
69-1260 |
SPACER Price: $11.05 |
| 20 |
539106809 |
BEARING PLATE - BLACK Price: $12.99 |
| 20 |
69-1180 |
ARMREST Price: $166.08 |
| 21 |
32128-19 |
NUT-HF Price: $0.99 |
| 21 |
539106811 |
BELT GUIDE Price: $6.99 |
| 22 |
323-9 |
SCREW-HH Price: $1.29 |
| 22 |
539106812 |
BACKING (BLACK) Price: $6.99 |
| 23 |
3234-14 |
SCREW-HHF This part replaces 3234-23. Price: $0.61 |
| 23 |
539102067 |
KEY 1/4 SQ X 3/4 Price: $2.99 |
| 24 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 24 |
539111303 |
IDLER ARM KEEPER Price: $5.99 |
| 25 |
32120-64 |
RING-SNAP, EXTERNAL Price: $0.25 |
| 25 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539108120. Price: $1.99 |
| 26 |
596582601 |
Nuts This part replaces 539990196. Price: $2.99 |
| 27 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 28 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 29 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 30 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 31 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 32 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 33 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 34 |
596789701 |
Screws This part replaces 539111229. Price: $1.99 |
| 35 |
596238401 |
BOLT CUP HEAD SQUARE NECK BOLT This part replaces 539990074. Price: $2.99 |
| 36 |
595901601 |
GSPW Bolts This part replaces 539990316. Price: $2.99 |
| 37 |
595901501 |
Bolts This part replaces 539990208. Price: $3.99 |
| 38 |
596671401 |
Bolts This part replaces 539100472. Price: $3.99 |
| 39 |
539990655 |
HCS 3/8C X 1 1/2 Price: $3.99 |
| 40 |
539990588 |
HCS 3/8C X 2 Price: $3.99 |
| 41 |
539100141 |
HCS 7/16F X 1 1/2 Price: $7.99 |
| 42 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 43 |
581724301 |
DECAL.DECK.6MIL.EURO.NOSTEP This part replaces 539105743. Price: $3.99 |
| 44 |
539111340 |
BLOWER SUPPORT Price: $22.99 |
