| Ref | Part Number | Description |
|---|
| 1 |
115-0120-03 |
PEDAL-BRAKE Price: $158.58 |
| 2 |
256-155 |
BUSHING-FLANGE Price: $1.76 |
| 2 |
532186211 |
KEY.SQUARE.187X2.500 Price: $3.99 |
| 3 |
104-7179 |
PIVOT-PEDAL Price: $43.97 |
| 4 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 5 |
99-7963-03 |
PEDAL-PARK Price: $26.63 |
| 6 |
115-5300 |
PROXIMITY SWITCH ASM Price: $137.95 |
| 7 |
531170101 |
SERVICE.KIT HUB ASM HUB.ASM.WH This part replaces 532199844. Price: $49.99 |
| 9 |
115-0129 |
ROD-PAWL, BRAKE Price: $29.11 |
| 9 |
596218701 |
Bolts Price: $2.99 |
| 10 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 11 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 12 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
99-7214 |
PAWL-BRAKE Price: $28.35 |
| 14 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 15 |
99-7140 |
SPRING-TORSION Price: $21.98 |
| 16 |
52-2891 |
BUSHING-FLANGED, NYLON Price: $3.19 |
| 17 |
323-12 |
SCREW-HH Price: $1.14 |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 18 |
117-0238 |
DETENT Price: $11.85 |
| 19 |
5-0652 |
SPACER Price: $5.35 |
| 20 |
283-14 |
PIN-CLEVIS Price: $2.92 |
| 21 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 22 |
117-0106 |
CABLE-BRAKE, RH Price: $117.67 |
| 22 |
532197329 |
ROD.SHIFT.FENDER.STGT. Price: $74.99 |
| 23 |
117-0107 |
CABLE-BRAKE, LH Price: $113.33 |
| 23 |
532140845 |
KNOB.DELUXE.(PISTOL.GRIP).BLAC Price: $11.99 |
| 24 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 25 |
110-8982 |
WASHER-SPRING Price: $2.71 |
| 26 |
115-8060 |
CLEVIS-DOUBLE Price: $15.64 |
| 27 |
115-8059 |
YOKE-CABLE Price: $11.28 |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 35 |
583864502 |
Rods Price: $6.99 |
| 37 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532008883. Price: $4.99 |
| 49 |
596136201 |
Bolts Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 56 |
592855201 |
Belts Price: $27.99 |
| 64 |
532196200 |
SHAFT.ASM.PEDAL.BRAKE. Price: $49.99 |
| 70 |
532439660 |
SUBASM.CONSOLE.HUSQ.GT.HYDRO Price: $79.99 |
| 73 |
583613301 |
BOLT.HEX.FLNG.5/16-18X3.75 This part replaces 874490560. Price: $4.99 |
| 74 |
596134101 |
Screws Price: $2.99 |
| 99 |
532415743 |
ROD.SPRING.BYPASS.K46.TEX.GT Price: $6.99 |
| 116 |
596135701 |
GSPW Nuts Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 153 |
532004497 |
RETAINER M Price: $4.99 |
| 159 |
596029501 |
Pins Price: $2.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 162 |
580457401 |
SPACER.TRANSAXLE.1" Price: $12.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532413430 |
KEEPER.CENTER SPAN.1.688 Price: $5.99 |
| 174 |
532197289 |
NUT.PUSH.500.2006 Price: $2.99 |
| 175 |
532406208 |
SHAFT ASM SHIFT Price: $22.99 |
| 176 |
532196214 |
ARM.CLEVIS.ROD.SHIFT Price: $6.99 |
| 178 |
532197456 |
SPRING.SHIFT.GT2006 Price: $4.99 |
| 183 |
532400424 |
SPACER.SPLIT.800X.350 Price: $4.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 587653701. Price: $9.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
585658602 |
Stop Price: $4.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 211 |
532196212 |
BUSHING.SHAFT.BRAKE.HAND Price: $5.99 |
| 220 |
532198908 |
REFLECTOR.RH.TEX GT Price: $14.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 227 |
596135901 |
Bolts Price: $1.99 |
| 231 |
532407287 |
IDLER.V-GROOVE.1.688.OFFSET Price: $19.99 |
| 233 |
596135201 |
Washers Price: $2.99 |
| 276 |
596238601 |
Bolts Price: $2.99 |
| 279 |
532406207 |
LINK.SHIFT.T/A.K46.FEND.TX Price: $9.99 |
| 325 |
585995702 |
BRACKET.TRQ.STP.46.22".TIRE.LH Price: $3.99 |
| 326 |
585993102 |
BRACKET.TRQ.STP.46.22".TIRE.RH Price: $3.99 |
| 334 |
585882202 |
SWAY.ROD.BRACKET.K46.X431 Price: $11.99 |
| 336 |
587259602 |
Bolts Price: $3.99 |
