| Ref | Part Number | Description |
|---|
| 1 |
532421708 |
TUBE.HANDLE.PLOW.LH.GREY Price: $79.99 |
| 1 |
725-3185 |
HARNESS-INDICATOR Not Available Price: |
| 1 |
76-4950 |
NUT-FLANGE Price: $12.75 |
| 2 |
532421709 |
TUBE.HANDLE.PLOW.RH.GREY Price: $34.99 |
| 2 |
76-4940 |
PULLEY-PUMP Price: $196.38 |
| 3 |
532196944 |
BRKT.PANEL.LH.INT Price: $8.99 |
| 3 |
725-3203 |
HARNESS-PEDESTAL Not Available Price: |
| 3 |
94-3220 |
DISCONTINUED Price: Call Us |
| 4 |
532196943 |
BRKT.PANEL.RH.INT Price: $8.99 |
| 4 |
925-1365 |
Bulb, Indicator This part replaces 725-1365. Price: $9.56 |
| 4 |
94-3225 |
SCREW-HH Price: $2.10 |
| 5 |
532414515 |
GRIP.HANDLE.HEATED Price: $54.99 |
| 5 |
76-4930 |
WASHER Price: $0.93 |
| 5 |
925-3159 |
HOUR METER Not Available This part replaces 725-3159. Price: |
| 6 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874780512. Price: $3.99 |
| 6 |
710-0936 |
SCREW #6-20 x .625 Not Available Price: |
| 6 |
94-3165 |
NUT-HEX Price: $2.34 |
| 7 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 7 |
725-3066 |
SWITCH Not Available Price: |
| 7 |
74-8610 |
PIN-SPRING Price: $2.73 |
| 8 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 8 |
712-3052 |
LOCK NUT #4-40 Not Available Price: |
| 8 |
74-8630 |
BUSHING-FLANGE Price: $6.93 |
| 9 |
532155415 |
WASHER.20X8.5 Price: $4.99 |
| 9 |
711-3259 |
SCREW-SWITCH Not Available Price: |
| 9 |
94-3224 |
WASHER-PLATE Price: $0.57 |
| 10 |
94-3164 |
WASHER-SPRING Price: $1.20 |
| 10 |
KB-66706-55120 |
SWITCH ASSEMBLY Not Available Price: |
| 11 |
712-3013 |
NUT-IGNITION SWITCH Not Available Price: |
| 11 |
94-3221 |
SCREW-HH Price: $9.64 |
| 12 |
74-8650 |
PACER Price: $2.36 |
| 12 |
KB-66711-55240 |
IGNITION KEY Not Available This part replaces KB-66711-55140. Price: |
| 13 |
74-8670 |
FUEL INLET ASM Price: $66.08 |
| 13 |
925-0893 |
Switch, PTO This part replaces 725-0893. Price: $72.43 |
| 14 |
712-3014 |
HEX NUT 1/2-27 x .100 THK Not Available Price: |
| 14 |
74-8680 |
GASKET Price: $5.51 |
| 15 |
48-7880 |
NUT-HEX This part replaces 94-3251. Price: $0.25 |
| 15 |
925-1756 |
TOGGLE SWITCH (SINGLE) Not Available This part replaces 725-0646. Price: |
| 16 |
3255-10 |
WASHER-LOCK / EXT This part replaces 74-8710. Price: $0.25 |
| 16 |
925-3191A |
Switch, Plunger This part replaces 725-3191. Price: $47.64 |
| 17 |
735-3036 |
BOOT-SWITCH Not Available Price: |
| 17 |
98-8806 |
SOLENOID VALVE This part replaces 93-5856. Price: $251.17 |
| 18 |
925-3167 |
Switch, Snap Mount Normally Open (Black) This part replaces 725-3167. Price: $13.53 |
| 18 |
94-3274 |
O-RING Price: $4.19 |
| 19 |
725-3019 |
CABLE ASSEMBLY-TAIL LAMP Not Available Price: |
| 19 |
94-3219 |
DISCONTINUED Price: Call Us |
| 20 |
725-3020 |
BULB Not Available Price: |
| 20 |
94-3222 |
KEY Price: $5.03 |
| 21 |
725-3018 |
Lens Assy, Tail Light Price: Call Us |
| 21 |
74-8870 |
DISCONTINUED Price: Call Us |
| 22 |
94-3249 |
TUBE-OUTLET Price: $52.36 |
| 23 |
94-3250 |
SCREW Price: $78.40 |
| 24 |
94-3161 |
DISCONTINUED Price: Call Us |
| 25 |
94-3223 |
SCREW-HH Price: $11.01 |
| 26 |
76-4910 |
STUD Price: $1.24 |
| 27 |
94-9969 |
SCREW-CONNECTION Price: $16.10 |
