| Ref | Part Number | Description |
|---|
| 1 |
120-8001-0P |
MOUNT-ENGINE,LH,FRONT This part replaces 120-8001-03. Price: $32.33 |
| 1 |
532124415 |
STEERING WHEEL Price: $58.99 |
| 2 |
120-8002-0P |
MOUNT-ENGINE, RH FRONT This part replaces 120-8002-03. Price: $26.44 |
| 2 |
532142033 |
AXLE ASSY Price: $59.99 |
| 3 |
120-8003-0P |
MOUNT-ENGINE, LH REAR This part replaces 120-8003-03. Price: $41.80 |
| 3 |
532135227 |
SPINDLE LH Price: $15.39 |
| 4 |
120-8004-0P |
MOUNT-ENGINE, RH REAR This part replaces 120-8004-03. Price: $43.35 |
| 4 |
532135228 |
SPINDLE RH Price: $12.97 |
| 5 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
33115-025 |
SCREW-HH Price: $0.61 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
53-9682 |
MOUNT-ENGINE Price: $108.69 |
| 7 |
819272016 |
WASHER Price: $3.99 |
| 8 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 9 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 10 |
532130468 |
LINK.DRAG.SOL.BALL JT.20.064 Price: $64.99 |
| 10 |
63-7400 |
WASHER-REBOUND Price: $1.70 |
| 11 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
104-5420-0P |
BATTERY SUPPORT ASM [PRIMED] This part replaces 104-5420-03. Price: $125.91 |
| 12 |
873610600 |
NUT Price: $2.99 |
| 13 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 13 |
532155134 |
KIT-AXLE This part replaces 532110438. Price: $13.26 |
| 14 |
32128-20 |
NUT-HF Price: $0.99 |
| 14 |
874011056 |
Bolt, Hex Head 5/8-11 x 3-1/2 Price: $4.99 |
| 15 |
114-8134-03 |
BRACKET-SUPPORT Price: $100.05 |
| 15 |
583612401 |
LOCKNUT M This part replaces 873901000. Price: $2.99 |
| 16 |
323-10 |
SCREW-HH Price: $0.89 |
| 16 |
532132624 |
AXLE PIN Price: $2.42 |
| 17 |
32128-21 |
NUT-HF Price: $0.39 |
| 17 |
532156544 |
STEERING SHAFT This part replaces 532128762. Price: $64.99 |
| 18 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 18 |
532057079 |
THRUST WASHER Price: $1.99 |
| 19 |
136-3615-0P |
A/C MOUNT ASM [PRIMED] This part replaces 121-3140-03. Price: $295.77 |
| 19 |
532160395 |
STEERING SHAFT SUPPORT This part replaces 532124035. Price: $8.99 |
| 20 |
121-3102-0P |
BRACKET-CONTROLLER [PRIMED] This part replaces 121-3102-03. Price: $43.43 |
| 20 |
596582301 |
Washers This part replaces 532126684. Price: $2.99 |
| 21 |
121-3098-03 |
SUPPORT-TAILPIPE Price: $113.25 |
| 21 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 22 |
532165857 |
SCREW.HX.WSH.HD This part replaces 871070410. Price: $3.99 |
| 23 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 23 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532127501. Price: $29.99 |
| 24 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 24 |
532109816 |
NYLINER T (7283A) Price: $4.99 |
| 25 |
323-6 |
SCREW-HH Price: $0.66 |
| 25 |
531152201 |
SERVICE KIT BRACKET BRKT This part replaces 532124036. Price: $12.99 |
| 26 |
18-2130 |
CLAMP Price: $5.63 |
| 27 |
532136874 |
GEAR.SECTOR Price: $69.99 |
| 27 |
99-7435 |
RELAY Price: $32.43 |
| 28 |
99-7430 |
RELAY-MINI Price: $22.99 |
| 29 |
321-3 |
SCREW-HH Price: $0.28 |
| 29 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 30 |
104-7201 |
NUT-HF Price: $0.69 |
| 31 |
3290-134 |
SCREW Price: $0.27 |
| 32 |
3290-277 |
NUT-SPEED Price: $0.61 |
| 32 |
532170162 |
ROD.ASM.TIE.BALL.JOINT.NOVAN This part replaces 532130467. Price: $79.99 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
873610500 |
This part replaces 873810500. Price: $2.15 |
| 36 |
532145207 |
BUSHING STRG 3/4 Price: $4.99 |
| 37 |
817541008 |
SCREW Price: $3.99 |
| 38 |
532124416 |
INSERT,STR WHEEL Price: $7.89 |
| 39 |
532100712 |
WASHER Price: $2.42 |
| 40 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532100711. Price: $7.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 47 |
532183226 |
FITTING.GREASE.TAPERED This part replaces 532124836. Price: $4.99 |
| 62 |
532167904 |
KIT.STEER.AMS.YT This part replaces 532149683. Price: $149.99 |
