| Ref | Part Number | Description |
|---|
| 1 |
3212-5 |
SCREW-HH Price: $2.46 |
| 1 |
IH-394081-R91 |
Case Assy, Transmission Price: Call Us |
| 2 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 2 |
741-0370 |
ROLLER BEARING CUP Not Available Price: |
| 3 |
44-8160 |
DISCONTINUED Price: Call Us |
| 3 |
717-3123 |
SHIM Not Available Price: |
| 4 |
741-04548 |
Cup Bearing This part replaces 741-0372. Price: $7.72 |
| 4 |
93-6706-03 |
PULLEY This part replaces 93-6706. Price: $137.29 |
| 5 |
68-6030 |
BOLT Price: $11.34 |
| 5 |
741-3071 |
FLANGE BEARING Not Available Price: |
| 6 |
727-3025 |
Plug, Breather Price: Call Us |
| 6 |
93-6725 |
KEEPER-WIRE Price: $10.15 |
| 7 |
33004-00 |
NUT-HF Price: $0.34 |
| 7 |
IH-350837-R3 |
GASKET This part replaces IH-350837-R2. Price: $25.86 |
| 8 |
9290-412 |
Rivet-Pop Price: Call Us |
| 8 |
IH-394089-R11 |
Plate Assy, Rear Cover Price: Call Us |
| 9 |
737-0177 |
DRAIN PLUG Not Available Price: |
| 9 |
83-8080 |
KEY Price: $7.28 |
| 10 |
33114-016 |
SCREW-HH This part replaces 48-7700. Price: $0.27 |
| 10 |
IH-394090-R1 |
Cover, Top Price: Call Us |
| 11 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 11 |
IH-394091-R1 |
GASKET Not Available Price: |
| 12 |
2412-96 |
CLAMP-R Price: $3.46 |
| 12 |
921-3004 |
GASKET This part replaces 721-3004. Price: $9.36 |
| 13 |
57-6390 |
NUT-JAM Price: $0.89 |
| 14 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 14 |
IH-350787-R1 |
GEAR Not Available Price: |
| 15 |
IH-350788-R1 |
PIN Not Available Price: |
| 16 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 16 |
IH-350789-R1 |
Shaft, Pinion Price: Call Us |
| 17 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 17 |
717-3113 |
PINION-10T Not Available Price: |
| 19 |
741-0369 |
CONE BEARING ROLLER Not Available Price: |
| 19 |
93-6719 |
MUFFLER ASM Price: $513.51 |
| 20 |
IH-376158-R91 |
Cage Assy, Differential Brg Price: Call Us |
| 21 |
IH-ST974 |
BEARING Not Available Price: |
| 22 |
717-3097 |
SHIM, BEARING RETAINER, .004 Not Available Price: |
| 23 |
717-3098 |
SHIM, BEARING RETAINER, .007 Not Available Price: |
| 23 |
93-6721 |
DISCONTINUED Price: Call Us |
| 24 |
717-3099 |
Shim, Brg Retainer, .0149 Price: $32.65 |
| 24 |
93-6720 |
DISCONTINUED Price: Call Us |
| 25 |
717-3100 |
SHIM .028 Not Available Price: |
| 25 |
93-6722 |
DISCONTINUED Price: Call Us |
| 26 |
82-3110 |
SENDER-TEMP Price: $36.76 |
| 26 |
IH-394093-R1 |
Shaft, Bevel Pinion Price: Call Us |
| 27 |
93-6728 |
HOSE-RADIATOR, TOP Price: $43.77 |
| 27 |
IH-323315-C1 |
RING Not Available Price: |
| 28 |
2112-11 |
CLAMP-MUFFLER Price: $7.37 |
| 28 |
741-04549 |
Cone Bearing This part replaces 741-0373. Price: $17.28 |
| 29 |
3217-6 |
NUT-HEX Price: $1.19 |
| 29 |
717-3127 |
RETAINER RING Not Available Price: |
| 29 |
717-3129 |
RETAINER RING Not Available Price: |
| 29 |
717-3130 |
RETAINER RING Not Available Price: |
| 29 |
717-3132 |
RETAINER RING Not Available Price: |
| 29 |
917-3128 |
RETAINER Not Available This part replaces 717-3128. Price: |
| 29 |
IH-395099-R1 |
Ring, Pinion Shaft Frt Brg Ret, .101 Price: Call Us |
| 30 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 30 |
726-0216 |
EXPANSION PLUG Not Available Price: |
| 31 |
703-0401 |
BAR-FIXED DRAW Not Available Price: |
| 31 |
93-6713-03 |
BRACKET-MOUNT, ENGINE ASM This part replaces 93-6713. Price: $45.57 |
| 32 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 33 |
923-3014 |
Filter, Oil This part replaces 723-3014. Price: $18.90 |
| 33 |
93-6729 |
HOSE-RADIATOR, LOWER Price: $54.09 |
| 34 |
717-3147 |
Gear, Constant Mesh -66T Price: Call Us |
| 35 |
931-3009 |
COOLING FAN This part replaces 731-3009. Price: $27.54 |
| 36 |
927-3008 |
HYDRAULIC TUBE ASSEMBLY Not Available This part replaces 727-3008. Price: |
| 37 |
727-3009 |
CONNECTOR-37 DEGREE-7/8-14 Not Available Price: |
| 37 |
81-1690 |
CLAMP-CABLE Price: $2.24 |
| 38 |
721-3005 |
O-RING Not Available Price: |
| 39 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 39 |
903-0204 |
DRIVE SHAFT FLANGE ASSEMBLY This part replaces 703-0204. Price: $35.89 |
| 40 |
722-3000 |
Disc, Flexible Coupling Price: $25.02 |
| 40 |
93-6892-03 |
BRACKET-CABLE, THROTTLE This part replaces 93-6892. Price: $23.11 |
| 41 |
283-62 |
PIN-CLEVIS Price: $0.61 |
| 41 |
748-3001 |
ARM-COUPLING Not Available Price: |
| 42 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 42 |
903-0794 |
DRIVE COUPLING SHAFT This part replaces 703-0794. Price: $214.46 |
| 43 |
92-3154 |
TAB-THROTTLE Price: $7.93 |
| 43 |
941-3004 |
BALL BUSHING This part replaces 741-3004. Price: $44.91 |
| 44 |
33093-00 |
WASHER-FLAT This part replaces 48-8010. Price: $0.70 |
| 44 |
738-3011 |
Shaft, Drive Price: $102.81 |
| 45 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 46 |
93-6712-03 |
BRACKET-ENGINE MOUNT, FRONT ASM This part replaces 93-6712. Price: $50.27 |
| 47 |
32148-14 |
NUT-CLINCH Price: $1.29 |
| 48 |
33115-025 |
SCREW-HH This part replaces 48-7780. Price: $0.61 |
| 49 |
93-6707 |
DISCONTINUED Price: Call Us |
| 50 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 51 |
3255-17 |
WASHER-LOCK, EXT Price: $0.29 |
| 53 |
33114-020 |
SCREW-HH This part replaces 66-3160. Price: $0.28 |
| 54 |
93-6727 |
CLUTCH Price: $622.49 |
| 55 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 56 |
3234-24 |
SCREW-HHF Price: $3.19 |
| 57 |
3290-432 |
SCREW-HH Price: $0.81 |
| 58 |
94-3692 |
DISCONTINUED Price: Call Us |
| 59 |
93-6775 |
CABLE-BATTERY, POS Price: $111.66 |
| 60 |
94-5980 |
CABLE-BATTERY, NEG Price: $92.64 |
| 61 |
75-4703 |
HOSE Price: $16.06 |
| 63 |
33004-00 |
NUT-HF Price: $0.34 |
