| Ref | Part Number | Description |
|---|
| 1 |
92-8562 |
HOOK-RESTRAINT, BOOM Price: $68.40 |
| 2 |
530038227 |
Lever-Switch Price: $1.99 |
| 2 |
92-8561 |
HOSE-HOLD IN Price: $18.31 |
| 3 |
530016149 |
Spring-Switch Price: $1.99 |
| 3 |
92-8563 |
SPRING Price: $19.69 |
| 4 |
530015775 |
Screw Price: $1.99 |
| 4 |
92-8564 |
KNOB Price: $11.17 |
| 5 |
32153-5 |
NUT-HEX This part replaces 22-15-AJFD. Price: $1.59 |
| 5 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
| 6 |
530023877 |
Fitting - Fuel line Price: $1.99 |
| 6 |
92-8534 |
DISCONTINUED Price: Call Us |
| 7 |
3256-6 |
WASHER-FLAT This part replaces 24-13-AD. Price: $0.34 |
| 7 |
577858501 |
FUEL CAP ASSY W/RET This part replaces 530047192. Price: $4.99 |
| 8 |
42223-03 |
WEDGE TUBE ASM This part replaces 42223. Price: $99.98 |
| 8 |
530055322 |
Clip - "U" Price: $1.99 |
| 9 |
530055183 |
Shield - Heat Price: $5.99 |
| 9 |
92-3672 |
ANGLE-UPPER CROSS Price: $58.08 |
| 10 |
325-6 |
SCREW-HH This part replaces 20-87-AGD. Price: $1.42 |
| 10 |
530047989 |
Lever-Choke Price: $1.99 |
| 11 |
325-5 |
SCREW-HH This part replaces 20-86-AGD. Price: $1.20 |
| 11 |
530049005 |
Grommet-Choke lever Price: $1.99 |
| 12 |
42217-03 |
RH BOOM MOUNT ASM This part replaces 42217. Price: $209.28 |
| 12 |
530037809 |
Wire-Throttle Price: $1.99 |
| 13 |
42222-03 |
LH BOOM MOUNT ASM This part replaces 42222. Price: $368.05 |
| 13 |
530015922 |
Nut-Speed Price: $1.99 |
| 14 |
530014949 |
Assy.-Clutch Price: $7.99 |
| 14 |
92-8533-03 |
BRACKET-MOUNTING, BOOM This part replaces 92-8533. Price: $51.71 |
| 15 |
3217-6 |
NUT-HEX This part replaces 22-12-AJD. Price: $1.19 |
| 15 |
530015611 |
Washer-Clutch Price: $1.99 |
| 16 |
3256-3 |
WASHER-FLAT This part replaces 24-10-AD. Price: $0.49 |
| 16 |
530047061 |
Assy-Drum W/brg. Price: $11.99 |
| 17 |
322-7 |
SCREW-HH This part replaces 20-28-AGD. Price: $0.89 |
| 17 |
530015907 |
Washer - Thrust Price: $1.99 |
| 18 |
42711-03 |
LH BOOM SUPPORT ASM This part replaces 42711. Price: $244.45 |
| 19 |
530039187 |
Assy-Flywheel Price: $14.99 |
| 20 |
42707-03 |
SUPPORT BRACKET ASM This part replaces 42707. Price: $88.27 |
| 20 |
530015127 |
Washer-Flywheel Price: $1.99 |
| 21 |
3256-23 |
WASHER-PLAIN This part replaces 24-10-BD. Price: $0.28 |
| 21 |
530016134 |
Nut-Flywheel Price: $1.99 |
| 22 |
3230-2 |
BOLT-CARR This part replaces 25-25-AGD. Price: $0.47 |
| 22 |
530015920 |
Screw Price: $1.99 |
| 23 |
3296-42 |
NUT-LOCK, NI This part replaces 32146-17. Price: $0.28 |
| 23 |
530049335 |
Housing-Fan Price: $9.99 |
| 24 |
530015892 |
Screw Price: $1.99 |
| 25 |
530056402 |
Handle-Starter Price: $2.99 |
| 26 |
42282 |
EXTENSION BOOM PIPE ASSY Price: $152.55 |
| 26 |
530069232 |
Kit-Rope Price: $3.99 |
| 27 |
3256-4 |
WASHER-FLAT This part replaces 24-11-AD. Price: $0.28 |
| 27 |
545008015 |
SPRING STARTER This part replaces 530027531. Price: $2.99 |
| 28 |
545034301 |
STARTER PULLEY This part replaces 530037817. Price: $8.99 |
| 28 |
92-3749 |
FREEZE PLUG Price: $5.92 |
| 29 |
321-10 |
SCREW-HH This part replaces 20-8-AGD. Price: $1.29 |
| 29 |
530016080 |
Screw Price: $1.99 |
| 30 |
530071666 |
Kit-Oil Check Valve Price: $7.99 |
| 31 |
530057236 |
Assy-Oil Cap Price: $5.99 |
| 32 |
42257 |
SPACER-TUBULAR Price: $11.54 |
| 32 |
530016133 |
Bolt - Bar Price: $1.99 |
| 33 |
42199 |
BOLT Price: $36.91 |
| 33 |
530029850 |
Chain Catcher Price: $1.99 |
| 34 |
106-5085-03 |
PLATE-BOOM, CENTER This part replaces 42234. Price: $19.41 |
| 34 |
530015814 |
Screw Price: $1.49 |
| 35 |
530038238 |
Plate-Bar Mounting Price: $1.99 |
| 35 |
92-8420 |
CAP-BOOM Price: $1.92 |
| 36 |
40493-03 |
PIPE-BOOM, CENTER This part replaces 40493. Price: $70.39 |
| 36 |
545139915 |
Assy.-Chain Brake Price: $22.99 |
| 37 |
325-10 |
SCREW-HH This part replaces 20-91-AGD. Price: $1.82 |
| 37 |
530015917 |
Nut-Bar Mounting Price: $0.99 |
| 38 |
530044835 |
Bar- 18" Price: $18.52 |
| 38 |
603773 |
LOCKNUT This part replaces 22-13-AJFD. Price: $2.09 |
| 39 |
40494 |
CLAMP ASM Price: $26.94 |
| 39 |
952051338 |
Chain- 18" Price: Call Us |
| 40 |
323-6 |
SCREW-HH This part replaces 20-47-AGD. Price: $0.66 |
| 40 |
530016132 |
Screw Price: $1.99 |
| 41 |
42710-03 |
RH BOOM SUPPORT ASM This part replaces 42710. Price: $244.45 |
| 41 |
530015814 |
Screw Price: $1.49 |
| 42 |
3272-11 |
PIN-COTTER This part replaces 28-18-D. Price: $0.99 |
| 42 |
530059173 |
Handle-Front This part replaces 530056798. Price: $15.99 |
| 43 |
42195 |
PIN-CLEVIS Price: $6.11 |
| 43 |
530015940 |
Screw Price: $1.99 |
| 45 |
283-83 |
PIN-CLEVIS This part replaces 42194. Price: $9.52 |
| 45 |
530037820 |
Gear-Worm Spring Price: $1.99 |
| 46 |
42240-03 |
STRUT ASM This part replaces 42240. Price: $54.18 |
| 46 |
530049477 |
Elbow-Oil Pickup Price: $1.99 |
| 47 |
301950 |
U-BOLT-SQUARE Price: $9.77 |
| 47 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 48 |
3217-30 |
NUT-HEX,HEAVY This part replaces 22-17-AJD. Price: $0.98 |
| 48 |
530019206 |
Block-Seal Price: $1.99 |
| 49 |
42237 |
ADJUSTABLE CLEVIS ASM Price: $69.25 |
| 50 |
530038373 |
Pickup-Oiler Price: $1.99 |
| 50 |
92-0010 |
U-BOLT Price: $10.65 |
| 51 |
3256-2 |
WASHER-FLAT This part replaces 24-9-AD. Price: $0.39 |
