| Ref | Part Number | Description |
|---|
| 1 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 1 |
817060408 |
SCREW Price: $4.99 |
| 2 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 2 |
532132752 |
CONTROL.TH/CH.RH.BLK.FLG.26 Price: $19.99 |
| 3 |
532131951 |
Engine, Briggs and Stratton Model No. 283707 Price: Call Us |
| 3 |
92-7396-03 |
MOUNT-CABLE This part replaces 92-7396. Price: $12.51 |
| 4 |
596134201 |
Screws This part replaces 871070512. Price: $2.99 |
| 4 |
92-7520 |
THROTTLE CABLE ASM Price: $70.09 |
| 5 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 5 |
98-2352-03 |
FRAME-SEAT This part replaces 98-2352. Price: $456.00 |
| 6 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 6 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED Price: $8.99 |
| 7 |
32128-25 |
NUT-HF Price: $3.19 |
| 7 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 8 |
98-2353 |
BRACKET-LATCH, SEAT Price: $17.71 |
| 9 |
322-3 |
SCREW-HH Price: $0.79 |
| 9 |
734115441 |
WASHER - 26X6.5X1.6 This part replaces 819101216. Price: $0.99 |
| 10 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 10 |
93-7598 |
LEVER-THROTTLE Price: $39.13 |
| 11 |
233-42 |
KNOB Price: $12.88 |
| 12 |
532137437 |
MUFFLER.SINGLE.B&S.12HP Price: $199.99 |
| 12 |
66-4190 |
SPRING-IDLER, CLUTCH Price: $10.15 |
| 13 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 13 |
532101326 |
DEFL MUFFLER LTV Price: $4.01 |
| 14 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 14 |
532161464 |
SCREW.HEX.WS.HD.8-18 X 7/8 This part replaces 817030808. Price: $3.99 |
| 15 |
63-9920 |
DISCONTINUED Price: Call Us |
| 16 |
85-6910 |
DECAL-RATING, NOISE Price: $7.03 |
| 17 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 817490624. Price: $6.99 |
| 17 |
95-3477 |
DECAL - CLIP (JA) Price: $22.66 |
| 17 |
98-8110 |
DECAL-CLIP Price: $47.91 |
| 18 |
110-4149 |
KIT-SEAT PLATE This part replaces 98-2350. Price: $166.30 |
| 19 |
94-2919 |
DECAL-REAR MAN,6500,JAP Price: $17.36 |
| 19 |
98-8108 |
DECAL-REAR MANIFOLD Price: $41.51 |
| 20 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 21 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 22 |
98-2354-03 |
LATCH-SEAT This part replaces 98-2354. Price: $41.34 |
| 23 |
75-3680-03 |
ROD-SEAT This part replaces 75-3680. Price: $38.90 |
| 24 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 25 |
52-5910 |
RING-RETAINING Price: $3.64 |
| 26 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 27 |
70-1480 |
RELAY Price: $105.19 |
| 28 |
76-5260 |
DISCONTINUED Price: Call Us |
| 29 |
48-7880 |
NUT-HEX Price: $0.25 |
| 30 |
48-7890 |
NUT-HEX Price: $0.25 |
| 31 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 32 |
99-8963 |
HARNESS - WIRE Price: $1,791.32 |
| 33 |
1-806003 |
PIN-COTTER This part replaces 3290-307. Price: $1.39 |
