| Ref | Part Number | Description |
|---|
| 1 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 1 |
539107593 |
FENDER CONSOLE Price: $129.99 |
| 2 |
44-9050 |
HOSE Price: $70.98 |
| 2 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 539101768. Price: $24.99 |
| 3 |
3217-6 |
NUT-HEX Price: $1.19 |
| 3 |
539103275 |
THROTTLE CABLE Price: $27.99 |
| 4 |
20-4840 |
CLAMP-MUFFLER Price: $15.06 |
| 4 |
539109858 |
CONSOLE PLATE, BLACK Price: $12.99 |
| 5 |
27-7180 |
CAP Price: $70.51 |
| 5 |
596582801 |
Screws This part replaces 539990411. Price: $2.99 |
| 6 |
44-8950-03 |
AIR CLEANER TUBE This part replaces 44-8950. Price: $53.15 |
| 6 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
| 7 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 7 |
532175566 |
IGNITION SWITCH This part replaces 539107541. Price: $22.99 |
| 8 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 8 |
532140401 |
KEY MLD GEN DELTA This part replaces 539107544. Price: $5.99 |
| 9 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 9 |
576179401 |
HOUR METER This part replaces 539102540. Price: $27.99 |
| 10 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 10 |
539109838 |
DECAL, THROTTLE Price: $2.99 |
| 11 |
27-7150 |
A/C CUP ASM Price: $82.89 |
| 12 |
27-7160 |
DECAL-INSTALLATION Price: $19.89 |
| 13 |
27-7100 |
AIR CLEANER ASM Price: $323.10 |
| 14 |
80-3330 |
GASKET Price: $18.48 |
| 15 |
3258-19 |
SCREW Price: $0.42 |
| 16 |
322-3 |
SCREW-HH Price: $0.79 |
| 17 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 18 |
32107-11 |
NUT-SQUARE Price: $0.22 |
