| Ref | Part Number | Description |
|---|
| 1 |
110-8785 |
HYD MOTOR ASM (CCW) Price: $1,062.27 |
| 1 |
532170803 |
CONTROL, THROTTLE Price: $24.99 |
| 2 |
340-7 |
FITTING-STRAIGHT Price: $14.00 |
| 2 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 3 |
110-8786 |
HYD MOTOR ASM (CW) Price: $1,062.27 |
| 4 |
322-9 |
SCREW-HH Price: $3.09 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 5 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 5 |
532181444 |
EXHAUST TUBE LH KAWI Price: $54.99 |
| 6 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 6 |
532181442 |
EXHAUST TUBE RH KAWI Price: $59.99 |
| 7 |
56-7971 |
CLAMP-TUBE Price: $17.90 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 8 |
95-8783 |
TUBE ASM Price: $172.34 |
| 9 |
353-990 |
PLUG ASM Price: $10.01 |
| 10 |
104-7706 |
E-RING, BOWED Price: $1.72 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 11 |
95-8784 |
TUBE ASM Price: $181.92 |
| 12 |
3274-99 |
SCREW-HSH Price: $3.04 |
| 13 |
147-3595 |
BRACKET-BRAKE This part replaces 84-2000-03. Price: $8.08 |
| 14 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
93-6838-03 |
HUB-WHEEL This part replaces 93-6838. Price: $72.59 |
| 16 |
10-6850 |
DRUM-BRAKE Price: $54.08 |
| 17 |
85-6540 |
STUD-DRIVE Price: $7.41 |
| 18 |
26-3790 |
NUT-LOCK Price: $24.46 |
| 20 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 21 |
321-5 |
SCREW-HH Price: $0.22 |
| 22 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 23 |
104-7705 |
BRAKE ASM Price: $175.69 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 24 |
104-0485-0P |
SHIELD - WHEEL This part replaces 104-0485-03. Price: $38.89 |
| 25 |
119-8238 |
SPACER-DECK PULLEY Price: $7.49 |
| 25 |
532191812 |
NEEDS DESCRIPTION Price: Call Us |
| 26 |
114-2726 |
LEVER-BRAKE Price: $29.20 |
| 28 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
115-6672 |
BRAKE LEVER ASM Price: $22.20 |
| 31 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 32 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 33 |
104-4625-03 |
SHAFT-PIVOT, BRAKE Price: $158.63 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
95-8683 |
BRACKET-PIVOT, BRAKE Price: $13.75 |
| 35 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 36 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 37 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 37 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 38 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 41 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 101 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 105 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 119 |
532400595 |
NEEDS DESCRIPTION Price: Call Us |
| 120 |
532400594 |
NEEDS DESCRIPTION Price: Call Us |
| 121 |
532196688 |
CLIPS Price: $3.99 |
| 122 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 123 |
817670508 |
SCREW, 5/16-18 X 1/2 Price: $7.99 |
