| Ref | Part Number | Description |
|---|
| 1 |
11-5089 |
RH ROLLER BRACKET ASM Price: $80.99 |
| 2 |
34010 |
Bushing Price: Call Us |
| 2 |
424620 |
Plate, Clutch Bracket Price: Call Us |
| 3 |
421370 |
Plate, Clutch Anti-Rotation Price: Call Us |
| 3 |
47-4380 |
NUT-ROLLER, RH Price: $18.41 |
| 4 |
48030-09 |
Clamp, Cable 1/2" I.D. Price: Call Us |
| 4 |
5-4527 |
WASHER-THRUST Price: $3.00 |
| 5 |
04003-04 |
Bolt, Carriage 5/16-18x1" (large frame units only) Price: Call Us |
| 5 |
3296-15 |
NUT-LOCK, NI Price: $1.75 |
| 6 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
| 6 |
8-3990 |
REAR ROLLER ASM Price: $352.13 |
| 7 |
4-5189-01 |
ROLLER AND END CAP ASM This part replaces 4-5659. Price: $216.78 |
| 7 |
45418 |
Pulley Guard, 16" Small Frame Price: Call Us |
| 8 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 8 |
424661 |
Heatshield, 16" Small Frame Price: Call Us |
| 9 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 9 |
253-122 |
SEAL-OIL Price: $6.83 |
| 10 |
254-79 |
BEARING-ROLLER, CUP Price: $6.39 |
| 10 |
48028-05 |
Cable Tie, .19 x 8.0" Price: Call Us |
| 11 |
04003-11 |
SHORT SQ. NECK CARRIAGE BOLT, 3/8-16 X 1-1/4" Price: Call Us |
| 11 |
254-78 |
BEARING-CONE Price: $12.22 |
| 12 |
424002 |
Brace, (16" Small Frame) Price: Call Us |
| 12 |
5-4523 |
SLEEVE Price: $22.20 |
| 13 |
04043-04 |
Flatwasher, 3/8 (.391 x .938 x .105 HD) Grade 8 Price: Call Us |
| 13 |
253-117 |
SEAL-OIL Price: $5.72 |
| 14 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 14 |
8-3980 |
SHAFT-ROLLER Price: $76.62 |
| 15 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 15 |
47-7510 |
WASHER-NYLON Price: $1.15 |
| 16 |
3220-7 |
NUT-JAM Price: $4.09 |
| 16 |
462287 |
Engine Deck (16" Wide) with Decals - Small Frame Price: Call Us |
| 17 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 17 |
47-4390 |
NUT-ROLLER, LH Price: $18.41 |
| 18 |
04001-17 |
Bolt, Hex Head 5/16-18 x 2-1/2" (x3) (35BV & 37BV-EFI) Price: Call Us |
| 18 |
11-5079 |
LH ROLLER BRACKET ASM Price: $80.99 |
| 19 |
04002-06 |
Bolt, Hex Head M8 - 1.25 x 16 (48V / 52V) Price: Call Us |
| 19 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 20 |
04031-03 |
Lockwasher, 5/16" Ext. Tooth (Kohler x1) Price: Call Us |
| 21 |
484620 |
Muffler, Kawasaki (FS481, FS541, FS600) Price: Call Us |
| 22 |
4201134 |
Shield, Muffler Outter Price: Call Us |
| 23 |
4201133 |
Shield, Muffler Inner Price: Call Us |
| 24 |
04001-07 |
Bolt, Hex Head 1/2-13 x 1.5" Price: Call Us |
| 25 |
04001-08 |
BOLT, SERRATED FLANGE HEX HEAD 5/16-18 X 3/4" Price: Call Us |
| 26 |
04117-01 |
Nut, Flange Head Elastic Stop 5/16-18 Price: Call Us |
| 27 |
04017-37 |
Serr. Fl. Hex Head Capscrew, 1/2-13 x 1-3/4 Price: Call Us |
| 28 |
04117-04 |
Nut, Elastic Stop 1/2-13, (STT-52 & STTII-52) Price: Call Us |
