| Ref | Part Number | Description |
|---|
| 1 |
104-0000-03 |
PULLEY Price: $400.11 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144927. Price: $149.99 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 2 |
99-6937 |
FAN Price: $304.08 |
| 3 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 7 |
251-318 |
BEARING-BALL Price: $16.40 |
| 8 |
104-0001 |
SPACER Price: $25.45 |
| 8 |
532007603 |
TRAY.BATTERY This part replaces 532124886. Price: $5.99 |
| 9 |
104-0017 |
HUB This part replaces 104-0017-03. Price: $185.06 |
| 10 |
323-12 |
SCREW-HH Price: $1.14 |
| 10 |
532150177 |
BATTERY TIEDOWN KIT This part replaces 532145211. Price: $8.99 |
| 11 |
532150109 |
BATTERY HOLDDOWN FRONT MOUNT Price: $4.99 |
| 11 |
63-8410 |
WASHER Price: $1.76 |
| 12 |
11-0160 |
ROLLER SHAFT SCREW ASM Price: $28.16 |
| 12 |
532150177 |
BATTERY TIEDOWN KIT This part replaces 532145769. Price: $8.99 |
| 13 |
104-1487 |
BOLT-CARR Price: $3.93 |
| 14 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 15 |
104-1440-03 |
SUPPORT-FAN Price: $395.73 |
| 16 |
104-0006-03 |
LEVER-FAN, IDLER Price: $61.11 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN This part replaces 532153664. Price: $19.99 |
| 17 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 18 |
98-3921 |
BELT Price: $16.95 |
| 19 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810090400. Price: $2.99 |
| 19 |
95-3857 |
SCREW-HSBH Price: $4.09 |
| 20 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873350400. Price: $2.99 |
| 20 |
63-8140 |
PULLEY-IDLER Price: $47.94 |
| 21 |
104-1447-03 |
BRACKET-FAN, SUPPORT Price: $39.88 |
| 21 |
532166182 |
HARNESS ASM, LIGHT W/4152J Price: $23.31 |
| 22 |
3274-12 |
SCREW-HSH Price: $0.81 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 24 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 24 |
532004014 |
CABLE, STARTER Price: $8.03 |
| 25 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 25 |
532146686 |
CABLE, BATTERY Price: $8.99 |
| 26 |
104-1481-03 |
BRACKET-MOUNT, FAN Price: $58.30 |
| 26 |
532108824 |
FUSE HYT Price: $4.99 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 27 |
98-4561-03 |
SHIELD-ALTERNATOR Price: $56.98 |
| 28 |
532157899 |
CABLE, GROUND Price: $8.17 |
| 29 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 29 |
532160784 |
PLUNGER SWITCH (COLOR:OLIVE) Price: $17.99 |
| 30 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 30 |
532175566 |
IGNITION SWITCH This part replaces 532163968. Price: $22.99 |
| 31 |
33114-020 |
SCREW-HH Price: $0.28 |
| 32 |
322-4 |
SCREW-HH Price: $0.35 |
| 33 |
104-0007 |
SPACER Price: $39.26 |
| 33 |
532140401 |
KEY MLD GEN DELTA Price: $5.99 |
| 34 |
322-3 |
SCREW-HH Price: $0.79 |
| 40 |
532166174 |
HARNESS, IGN Price: $132.76 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
532146154 |
KIT SOLENOID .95 This part replaces 532145673. Price: $19.99 |
| 46 |
532169642 |
KIT.HOURMETER.SNAP-IN This part replaces 532110940. Price: $109.99 |
| 47 |
817011008 |
Screw #10-24 x 1/2 Price: $2.38 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532154959. Price: $24.99 |
| 51 |
532140405 |
FRAME RETAINING RING Price: $3.99 |
| 61 |
532138101 |
LIGHT PACKAGE Price: $44.99 |
| 62 |
532110143 |
BULB LIGHT T Price: $3.08 |
