| Ref | Part Number | Description |
|---|
| 1 |
114-5052 |
HOUSING ASM This part replaces 75-0020. Price: $2,587.20 |
| 1 |
195632X421 |
Deck Weldment Mower Price: Call Us |
| 2 |
75-0030 |
GASKET-HOUSING Price: $20.85 |
| 3 |
75-0040 |
SECTION-CENTER Price: $2,817.90 |
| 4 |
83-4780 |
HOUSING-PUMP, CHARGE Price: $714.23 |
| 5 |
75-0060 |
PLUG Price: $22.19 |
| 6 |
104-2189 |
PLUG-THREAD, STRAIGHT This part replaces 75-0070. Price: $24.99 |
| 6 |
196066 |
Cover Mandrel LH Price: Call Us |
| 7 |
197181 |
Cover Mandrel RH Price: Call Us |
| 7 |
86-7520 |
RH TRUNNION COVER ASM Price: $486.26 |
| 8 |
174365 |
Bolt 7/16 Asm. Blade Price: Call Us |
| 8 |
75-0090 |
CAPSCREW-HH Price: $2.16 |
| 9 |
86-7530 |
LH TRUNNION COVER ASM Price: $465.32 |
| 10 |
75-0110 |
CAPSCREW-HH Price: $2.14 |
| 11 |
187256 |
Blade Discharge/Bagging Price: Call Us |
| 11 |
75-0120 |
CAPSCREW-HH Price: $7.11 |
| 12 |
404851 |
Rod-Anti Sway Price: Call Us |
| 12 |
75-0130 |
DISCONTINUED Price: Call Us |
| 13 |
110-6342 |
SPRING This part replaces 75-0140. Price: $9.45 |
| 13 |
187291 |
Shaft Asm. w/Lower Bearing Price: Call Us |
| 14 |
187281 |
Housing, Mandrel Price: Call Us |
| 14 |
75-0150 |
GUIDE-SEAL Price: $270.30 |
| 15 |
110485X |
Bearing, Ball, Mandrel Price: Call Us |
| 15 |
75-0160 |
PLUG-PIPE Price: $4.39 |
| 16 |
19131312 |
Washer 13/32 x 13/16 x 12 Ga. Price: Call Us |
| 16 |
75-0170 |
PLUG-THREAD, STRAIGHT Price: $18.20 |
| 17 |
75-0180 |
CAPSCREW-HH Price: $19.18 |
| 18 |
72140505 |
Bolt 5/16 - 18 x 5/8 Price: Call Us |
| 18 |
75-0190 |
PLUG-SPECIAL Price: $124.62 |
| 19 |
194208 |
Pin Cotter 5/16 Bow Tie Lock Price: Call Us |
| 19 |
67-9090 |
PLUG This part replaces 75-0200. Price: $41.68 |
| 20 |
75-0210 |
O-RING Price: $7.35 |
| 21 |
73680500 |
Nut, Crownlock 5/16-18 unc Price: Call Us |
| 21 |
75-0220 |
PIN Price: $77.53 |
| 22 |
75-0230 |
SEAL-LIP Price: $80.68 |
| 23 |
75-0240 |
O-RING Price: $2.36 |
| 24 |
105304X |
Cap Sleeve Price: Call Us |
| 24 |
75-0250 |
DISCONTINUED Price: Call Us |
| 25 |
178102 |
Spring, Torsion Price: Call Us |
| 25 |
75-0260 |
VALVE-RELIEF Price: $97.16 |
| 26 |
110452X |
Nut, Push Price: Call Us |
| 26 |
75-0270 |
SPRING Price: $9.79 |
| 27 |
187257X428 |
Deflector Shield Price: Call Us |
| 27 |
75-0280 |
SPRING Price: $7.03 |
| 28 |
75-0290 |
DISCONTINUED Price: Call Us |
| 29 |
131491 |
Rod, Hinge Price: Call Us |
| 30 |
173984 |
Screw, Thdrol. Washer Head Price: Call Us |
| 30 |
75-0310 |
SHIM Price: $131.21 |
| 31 |
187690 |
Washer, Spacer Mower Vented Price: Call Us |
| 31 |
75-0320 |
NIPPLE Price: $89.72 |
| 32 |
153535 |
Pulley, Mandrel Price: Call Us |
| 32 |
75-0330 |
SEAL-LIP Price: $31.04 |
| 33 |
400234 |
Nut, Flg. Top Lock Price: Call Us |
| 33 |
75-0340 |
BEARING-NEEDLE Price: $86.35 |
| 34 |
73680600 |
Nut Crownlock 3/8-16 unc Price: Call Us |
| 34 |
75-0350 |
PIN Price: $8.75 |
| 35 |
75-0360 |
GEROTOR Price: $430.63 |
| 36 |
75-0370 |
O-RING Price: $10.08 |
| 37 |
75-0380 |
PLATE-VALVE Price: $518.86 |
| 38 |
75-0390 |
DISCONTINUED Price: Call Us |
| 39 |
197380 |
Pulley, Idler 4.50 HUB Price: Call Us |
| 39 |
75-0400 |
PLATE-THRUST Price: $41.27 |
| 40 |
75-0410 |
O-RING Price: $5.70 |
| 41 |
86-7540 |
SHAFT-PUMP Price: $910.85 |
| 42 |
75-0430 |
RING-RETAINING Price: $23.82 |
| 43 |
196065 |
Arm, Idler Price: Call Us |
| 43 |
75-0440 |
SHAFT-MOTOR Price: $550.98 |
| 44 |
75-0450 |
COLLAR Price: $44.00 |
| 45 |
75-0460 |
BEARING-BALL Price: $175.71 |
| 46 |
137729 |
Screw, Thdrol. 1/4-20 x 5/8 Price: Call Us |
| 46 |
75-0470 |
CYLINDER BLOCK KIT Price: $1,746.91 |
| 47 |
196103 |
V-Belt, Mower Price: Call Us |
| 47 |
94-3975 |
PIN This part replaces 75-0480. Price: $5.80 |
| 49 |
73900600 |
Nut, Lock Flg. 3/8-16 unc Price: Call Us |
| 49 |
75-0500 |
BEARING-NEEDLE Price: $83.78 |
| 50 |
72110616 |
Bolt Rdhd. Sqnk. 3/8-16 unc x 2 Price: Call Us |
| 50 |
75-0510 |
PIN Price: $8.40 |
| 51 |
75-0520 |
BEARING-BALL Price: $88.98 |
| 52 |
197379 |
Pulley Idler Price: Call Us |
| 52 |
75-6930 |
VALVE-SCREW Price: $97.36 |
| 53 |
32120-74 |
RING-SNAP Price: $0.54 |
| 55 |
93-0097 |
VALVE-SCREW Price: $235.37 |
| 58 |
187342 |
Baffle Right Price: Call Us |
| 59 |
187344 |
Baffle Left Price: Call Us |
| 60 |
187607 |
Baffle Center Price: Call Us |
| 97 |
178515 |
Washer Hardened Price: Call Us |
| 98 |
196105 |
Spring Drive Price: Call Us |
| 113 |
72110508 |
Bolt Rdhd. Sqnk. 5/16-18 x 3/4 Price: Call Us |
| 114 |
187556 |
Rod Tension Relief Price: Call Us |
| 116 |
193406 |
Bolt, Shoulder Price: Call Us |
| 117 |
174873 |
Gauge Wheel Price: Call Us |
| 120 |
19132012 |
Washer 13/32 x 1-1/4 x 12 Ga. Price: Call Us |
| 122 |
187557 |
Bushing Tension Relief Price: Call Us |
| 184 |
73900500 |
Nut Lock Hex Flange 5/16-18 Price: Call Us |
| 185 |
73900700 |
Nut Lock Flange 7/16-14 Gr. 5 Price: Call Us |
| 187 |
195161 |
Stud Fastener w/"D" Anti-Rotation Price: Call Us |
| 189 |
195185 |
Arm Susp. Mower Rear Price: Call Us |
| 190 |
196539 |
Bolt Shoulder Price: Call Us |
| 192 |
198468 |
Keeper Belt Idler Price: Call Us |
| 194 |
72140716 |
Bolt Carr. Sqnk. 3/8-16 x 2-1/4 Price: Call Us |
| 196 |
72140620 |
Bolt Rdhd. Sqnk. 3/8-16 x 2-1/2 Gr. 5 Price: Call Us |
| 198 |
17670608 |
Screw Thdrol. 3/8-16 x 1/2 Price: Call Us |
