| Ref | Part Number | Description |
|---|
| 1 |
107-2379 |
DISCONTINUED Price: Call Us |
| 1 |
194177X428 |
Control Bar Price: Call Us |
| 2 |
194179X479 |
Upper Handle Price: Call Us |
| 2 |
98-4555-03 |
MUFFLER BRACKET ASM Price: $265.60 |
| 3 |
169708X479 |
Lower Handle Price: Call Us |
| 3 |
323-7 |
SCREW-HH Price: $0.65 |
| 4 |
194788 |
Rope Guide Price: Call Us |
| 4 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 5 |
132004 |
Nut, Hex Price: Call Us |
| 5 |
2112-9 |
CLAMP Price: $7.78 |
| 6 |
191574 |
Handle Bolt Price: Call Us |
| 6 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 7 |
664-26 |
Wire Tie Price: Call Us |
| 7 |
98-4524 |
TUBE-EXHAUST Price: $153.83 |
| 8 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 8 |
74780512 |
Bolt Price: Call Us |
| 9 |
154132 |
Hinge Bracket Price: Call Us |
| 9 |
2112-6 |
CLAMP-MUFFLER Price: $7.53 |
| 10 |
165754 |
Mulcher Door Price: Call Us |
| 10 |
98-4527 |
DISCONTINUED Price: Call Us |
| 11 |
176556 |
Engine Zone Control Cable Price: Call Us |
| 11 |
33014-00 |
NUT-HEX Price: $0.25 |
| 12 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 12 |
750634 |
Hex Washer Head Screw Price: Call Us |
| 13 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 13 |
86899X004 |
Up-Stop Bracket Price: Call Us |
| 14 |
105-7505 |
GUARD-FLYWHEEL Price: $116.55 |
| 14 |
189713X428 |
Handle Knob Price: Call Us |
| 15 |
33114-025 |
SCREW-HH Price: $0.70 |
| 15 |
51793 |
Hairpin Cotter Price: Call Us |
| 16 |
43-0090 |
SCREW-HH Price: $8.05 |
| 17 |
48-9590 |
WASHER-LOCK This part replaces 42-9600. Price: $0.25 |
| 18 |
106-7751 |
DRIVESHAFT ASM Price: $706.20 |
| 18 |
17600406 |
Screw 1/4-20 x 3/8 Price: Call Us |
| 19 |
401174X004 |
Axle Arm Assembly, Front, LH Price: Call Us |
| 19 |
98-9322 |
SCREW-HSH Price: $4.89 |
| 20 |
322-9 |
SCREW-HH Price: $3.09 |
| 20 |
401175X004 |
Axle Arm Assembly, Front, RH Price: Call Us |
| 21 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 21 |
413160 |
Rear Skirt Price: Call Us |
| 22 |
401621X004 |
Selector Spring, Front Price: Call Us |
| 22 |
98-9346 |
SENDER-TEMPERATURE Price: $74.58 |
| 23 |
401814X428 |
Rear Door Assembly Price: Call Us |
| 24 |
33114-020 |
SCREW-HH Price: $0.28 |
| 25 |
106-7756 |
PULLEY Price: $93.11 |
| 25 |
410385X479 |
Handle Bracket Assembly, LH Price: Call Us |
| 26 |
410386X479 |
Handle Bracket Assembly, RH Price: Call Us |
| 28 |
407499X005 |
Wheel Adjusting Bracket, Front, LH Price: Call Us |
| 29 |
407500X005 |
Wheel Adjusting Bracket, Front, RH Price: Call Us |
| 30 |
401629 |
Spacer Price: Call Us |
| 31 |
165760 |
Discharge Deflector Price: Call Us |
| 32 |
401624X004 |
Selector Spring, Rear Price: Call Us |
| 33 |
87877 |
Selector Knob Price: Call Us |
| 34 |
401176X004 |
Axle Arm Assembly, Rear, LH Price: Call Us |
| 35 |
166785 |
Locknut, Hex 5/16-18 Price: Call Us |
| 36 |
401638 |
Shoulder Bolt 5/16-18 Price: Call Us |
| 37 |
193931X617 |
Wheel & Tire Assembly, Front, 7" Price: Call Us |
| 39 |
409148 |
Locknut, Hex, Flanged Price: Call Us |
| 40 |
411949 |
Frame, Grass Bag Price: Call Us |
| 41 |
88652 |
Hinge Screw Price: Call Us |
| 42 |
405421 |
Spring, Rear Door, LH Price: Call Us |
| 43 |
405423 |
Spring, Rear Door, RH Price: Call Us |
| 44 |
184193 |
Bolt, Rear Skirt Price: Call Us |
| 45 |
150406 |
Hex Head Thread Rolling Screw 3/8-16 x 1 Price: Call Us |
| 46 |
404763 |
Danger Decal Price: Call Us |
| 47 |
751153 |
Nut, Hex Price: Call Us |
| 48 |
401177X004 |
Axle Arm Assembly, Rear, RH Price: Call Us |
| 49 |
193926X617 |
Wheel & Tire Assembly, Rear, 12" Price: Call Us |
| 50 |
401737 |
Grass Bag Price: Call Us |
| 51 |
147286 |
Rod, Hinge Price: Call Us |
| 53 |
851084 |
Hex Head Screw 3/8-24 x 1-3/8 Grade 8 Price: Call Us |
| 54 |
850263 |
Helical Lockwasher Price: Call Us |
| 55 |
851074 |
Hardened Washer Price: Call Us |
| 57 |
193825 |
Blade Adapter Price: Call Us |
| 58 |
152124 |
Spring, Hinge Price: Call Us |
| 61 |
409149 |
Locknut, Hex, Flanged Price: Call Us |
| 62 |
73800400 |
Locknut, Hex 1/4-20 Price: Call Us |
| 65 |
88348 |
Washer, Flat Price: Call Us |
| 66 |
197480 |
O-Ring Price: Call Us |
| 67 |
197991 |
Clip, Cable Price: Call Us |
| 73 |
401630 |
Washer, Curved Price: Call Us |
| 74 |
193732 |
Operator's Manual, English Price: Call Us |
| 74 |
193735 |
Operator's Manual, Spanish Price: Call Us |
| 74 |
851201X004 |
Washer, Special, Engine Price: Call Us |
