| Ref | Part Number | Description |
|---|
| 1 |
32136-13 |
NUT-SHH Price: $2.85 |
| 2 |
105-7835 |
SEAL This part replaces 71-4760. Price: $2.76 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 3 |
71-4740-03 |
RH TIE ROD END ASM This part replaces 71-4740. Price: $163.79 |
| 4 |
302-55 |
FITTING-GREASE Price: $3.09 |
| 5 |
33108-040 |
DISCONTINUED Price: Call Us |
| 6 |
3256-7 |
WASHER-FLAT Price: $0.75 |
| 7 |
33026-00 |
NUT-HEX Price: $1.02 |
| 8 |
33106-035 |
SCREW-HHF Price: $8.35 |
| 9 |
17-6019 |
AXLE PIVOT ASM This part replaces 95-4411-03. Price: $354.34 |
| 9 |
596501502 |
Keepers This part replaces 584908001. Price: $9.99 |
| 10 |
93-5142 |
PIN-PIVOT, AXLE Price: $238.83 |
| 11 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 12 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 12 |
532194343 |
PULLEY ENGINE Price: $39.99 |
| 13 |
323-9 |
SCREW-HH Price: $1.29 |
| 14 |
104-0101-03 |
TUBE & CLAMP ASM Price: $264.08 |
| 15 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 16 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 17 |
93-4510 |
BUSHING-CASTER Price: $6.97 |
| 18 |
104-0193 |
TIE ROD ASM This part replaces 104-0100-03. Price: $539.80 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532439645. Price: $14.99 |
| 19 |
93-5436-03 |
ANCHOR-CYLINDER Price: $152.38 |
| 20 |
532423502 |
CONTROL.TH/CK.COBRA.B&S.TWN.BK Price: $24.99 |
| 20 |
93-5444 |
SCREW-TAPERED Price: $18.53 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 21 |
74-5560 |
TIRE (20X8-10) 6-PLY Price: $118.04 |
| 21 |
95-2625 |
TIRE (18X8.5-10) 4-PLY Price: $104.27 |
| 22 |
100-1357 |
RIM Price: $215.78 |
| 22 |
217-122 |
DISCONTINUED Price: Call Us |
| 23 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 24 |
93-5268 |
NUT-LUG Price: $2.20 |
| 25 |
95-2592 |
DISCONTINUED-SEE SB#09-15 Price: Call Us |
| 26 |
93-5962 |
DISCONTINUED Price: Call Us |
| 27 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 28 |
108-1340-03 |
ROD END-BALL JOINT This part replaces 92-5072-03. Price: $163.94 |
| 28 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
