| Ref | Part Number | Description |
|---|
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 2 |
70-1690 |
DISCONTINUED Price: Call Us |
| 3 |
2412-119 |
CLAMP-HOSE, WORM DRIVE Price: $1.83 |
| 4 |
70-1670 |
HOSE-HEAT Price: $73.26 |
| 5 |
67-8940 |
DISCONTINUED Price: Call Us |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
E630173-S71M |
Lockwasher Price: Call Us |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
E602187-S82 |
Bolt Price: Call Us |
| 8 |
70-2050 |
HOSE-BREATHER Price: $36.69 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
2412-39 |
CLAMP-R Price: $1.70 |
| 11 |
67-9130-03 |
PIPE-INLET, MUFFLER This part replaces 67-9130. Price: $10.11 |
| 12 |
2112-6 |
CLAMP-MUFFLER Price: $7.53 |
| 13 |
5-0652 |
SPACER Price: $5.35 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
67-8420-03 |
BRACKET This part replaces 67-8420. Price: $32.98 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 587016002. Price: $34.99 |
| 16 |
67-9120 |
MUFFLER Price: $619.96 |
| 17 |
N605799-S2 |
Bolt Price: Call Us |
| 18 |
67-8480-03 |
MOUNT-ENGINE ASM This part replaces 67-8480. Price: $82.18 |
| 19 |
32128-37 |
NUT-HF Price: $3.63 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
131-1821 |
MOUNT-ENGINE This part replaces 53-9680. Price: $105.39 |
| 21 |
53-9480 |
WASHER-SNUBBER Price: $3.87 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 586840201. Price: $7.99 |
| 22 |
324-11 |
SCREW-HH Price: $3.05 |
| 23 |
N80057-S2 |
Bolt Price: Call Us |
| 24 |
D2RY-6379-4 |
Bolt Price: Call Us |
| 25 |
67-8440 |
PLATE-ENGINE SUPPORT, REAR Price: $339.53 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 26 |
D8RZ-6384A |
Ring Gear-Flywheel Price: Call Us |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 27 |
89BM-6375-AA |
Flywheel Assembly (Incl. Ref. #26) Price: Call Us |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 28 |
N6200482-S2 |
Nut Price: Call Us |
| 29 |
E804627-S76 |
Stud Price: Call Us |
| 30 |
NG20481-S2 |
Nut Price: Call Us |
| 31 |
EBJI-9430-CA |
Manifold-Exhaust Price: Call Us |
| 32 |
89BM-9448-BA |
Gasket-Manifold Price: Call Us |
| 33 |
E7JI-6A312-AA |
Pulley Price: Call Us |
| 34 |
E7JI-6N300-AA |
Locking Ring Set Price: Call Us |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 35 |
E7JI-6378-AA |
Compression Ring Price: Call Us |
| 36 |
E7JI-6K340-AA |
Bolt Price: Call Us |
| 37 |
Dory-6B316-A |
Key Price: Call Us |
| 38 |
92BX8591-BA |
Water Pump Kit (Incl. Pulley Gasket) Price: Call Us |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $2.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683701. Price: $4.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
