| Ref | Part Number | Description |
|---|
| 1 |
117-8982 |
TANK-HYDRAULIC This part replaces 104-9254. Price: $1,846.02 |
| 1 |
159944X428 |
Wheel Steering Price: Call Us |
| 2 |
172393 |
Axle Asm Cast Iron LT Price: Call Us |
| 2 |
68-6150 |
BREATHER Price: $27.22 |
| 3 |
169840 |
Spindle Asm LH Price: Call Us |
| 3 |
61-2790 |
FILTER-SCREEN Price: $49.91 |
| 4 |
169839 |
Spindle Asm RH Price: Call Us |
| 4 |
94-9411 |
DIPSTICK Price: $42.51 |
| 5 |
354-73 |
FITTING Price: $27.56 |
| 5 |
6266H |
Bearing Race Thrust Harden Price: Call Us |
| 6 |
121748X |
Washer 25/32 X 1-5/8 X 16 Ga Price: Call Us |
| 6 |
93-7498 |
PLUG-PLASTIC Price: $25.26 |
| 7 |
340-8 |
FITTING-STRAIGHT Price: $9.70 |
| 8 |
12000029 |
Ring Klip #t5304-75 Price: Call Us |
| 8 |
340-87 |
FITTING-ELBOW, 45 DEG Price: $18.39 |
| 9 |
99-6932 |
FITTING-STR Price: $118.43 |
| 10 |
169832 |
Link Drag Price: Call Us |
| 10 |
321-24 |
SCREW-HH This part replaces 321-23. Price: $2.31 |
| 11 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 11 |
92-9098 |
MANIFOLD-TANK Price: $297.10 |
| 12 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 13 |
136518 |
Spacer Brg Axle Front Price: Call Us |
| 13 |
354-74 |
PLUG-HH Price: $17.90 |
| 14 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 15 |
145212 |
Nut Hex Flange Lock Price: Call Us |
| 15 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 16 |
75-5720 |
HOSE-RETURN Price: $39.38 |
| 17 |
156546 |
Shaft Asm Strg Price: Call Us |
| 17 |
75-6870 |
HOSE-INLET, PUMP Price: $50.00 |
| 18 |
57079 |
Washer Thrust 515 x 750 x 033 Price: Call Us |
| 19 |
104-7546 |
TANK STRAINER ASM Price: $170.48 |
| 19 |
160395 |
Support Shaft Price: Call Us |
| 20 |
2412-93 |
CLAMP-R Price: $1.02 |
| 21 |
75-1300 |
OIL FILTER ASM Price: $427.40 |
| 22 |
165857 |
Screw Hex Wsh Hd Torx Price: Call Us |
| 22 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 23 |
165851 |
Shaft Asm Pittman Price: Call Us |
| 23 |
340-139 |
FITTING-ELBOW 90 Price: $117.76 |
| 24 |
33105-025 |
SCREW-HHF Price: $1.56 |
| 25 |
154406 |
Bracket Steering Price: Call Us |
| 25 |
63-8410 |
WASHER Price: $1.76 |
| 26 |
75-6130 |
HOSE ASM Price: $158.19 |
| 27 |
136874 |
Gear Sector Price: Call Us |
| 27 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 28 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 29 |
17060612 |
Screw 3/8-16 x .75 Price: Call Us |
| 29 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 30 |
323-4 |
SCREW-HH Price: $1.02 |
| 31 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 32 |
171888 |
Rod Tie Price: Call Us |
| 32 |
340-82 |
FITTING-ELBOW, 90 DEG Price: $20.57 |
| 33 |
100-3739 |
RETURN DRAIN HOSE ASM Price: $149.42 |
| 33 |
19111216 |
Washer 11/32 x 3/4 x 16 Ga Price: Call Us |
| 34 |
10040500 |
Washer Lock Hvy Hlcl Spr 5/16 Price: Call Us |
| 34 |
93-7499 |
GASKET Price: $5.91 |
| 35 |
237-101 |
O-RING Price: $2.80 |
| 35 |
73540500 |
Crownlock Nut 5/16-24 Unf Price: Call Us |
| 36 |
155099 |
Bushing Strg Price: Call Us |
| 36 |
93-7588 |
COVER-TANK Price: $37.60 |
| 37 |
152927 |
Screw Price: Call Us |
| 37 |
92-8020 |
ADAPTER-BREATHER Price: $10.50 |
| 38 |
159946X428 |
Insert Cap Strg Wh Price: Call Us |
| 38 |
33104-020 |
SCREW-HHF Price: $2.07 |
| 39 |
19132411 |
Washer 13/32 X 1-1/2 X 11 Ga Price: Call Us |
| 39 |
353-508 |
PLUG-HH Price: $7.96 |
| 40 |
7810H |
Lock nut Price: Call Us |
| 41 |
159945 |
Adaptor Wheel Strg Price: Call Us |
| 42 |
145054X428 |
Boot Steering Dash Price: Call Us |
| 43 |
121749X |
Washer 25/32 X 1 1/4 X 16 Ga Price: Call Us |
| 44 |
153720 |
Extension Steering Shaft LR/LT Price: Call Us |
| 46 |
121232X |
Cap Spindle Fr Top Blk Price: Call Us |
| 51 |
73800500 |
Nut Lock Hex w/Ins 5/16-18 Price: Call Us |
| 54 |
74780520 |
Bolt Fin Hex 5/16-18 Unc x 1-1/4 Price: Call Us |
| 62 |
167902 |
Kit, Steering Assembly Svc Price: Call Us |
| 63 |
74780616 |
Bolt Fin Hex 3/8-16unc x 1 Gr. 5 Price: Call Us |
| 65 |
160367 |
Spacer Brace Axle Price: Call Us |
| 66 |
154404 |
Bearing Arm Pittman Price: Call Us |
| 67 |
72140618 |
Bolt Rdhd Sq 3/8-16 Unc x 2-3/4 Price: Call Us |
| 68 |
169827 |
Axle, Brace Price: Call Us |
| 79 |
19132012 |
Washer 13/32 x 1-1/4 x 12 Ga. Price: Call Us |
| 80 |
74950612 |
Bolt Hex Nylon 3/8-16 x 3/4 Price: Call Us |
| 82 |
169835 |
Bracket Susp Chassis Front Price: Call Us |
