| Ref | Part Number | Description |
|---|
| 1 |
532123385 |
Pulley Price: $22.99 |
| 1 |
93-2085-01 |
ROD ASM Price: $134.61 |
| 2 |
532002267 |
Ring, Retaining This part replaces 812000028. Price: $3.99 |
| 2 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 3 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 4 |
49-6440-03 |
PEDAL-FORWARD Price: $84.90 |
| 4 |
532125096 |
Key, Woodruff #9 Price: $3.99 |
| 5 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 5 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873680500. Price: $2.69 |
| 6 |
33124-020 |
SCREW-CARR Price: $0.88 |
| 6 |
539990316 |
RHSNB.5/16-18.X3/4.GR.5.ZD This part replaces 872140506. Price: $1.49 |
| 7 |
321-9 |
SCREW-HH Price: $0.27 |
| 7 |
532123378 |
Strap, Torque Price: $2.99 |
| 8 |
871490512 |
Screw 5/16 - 18 x 3/4 Price: Call Us |
| 9 |
105-9750-01 |
PLATE-FLOOR Price: $194.85 |
| 9 |
532146682 |
Spring Return Brake This part replaces 532110422. Price: $4.99 |
| 10 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 10 |
532121749 |
Washer 25/32 x 1-1/4 x 16 Ga. Price: $1.99 |
| 11 |
532123583 |
Key, Square Price: $2.69 |
| 11 |
94-1371 |
SPACER Price: $14.81 |
| 12 |
874760644 |
Bolt, Fin Hex 5/16-18 x 2-1/2 Price: $3.99 |
| 12 |
94-1383 |
PEDAL-PIVOT Price: $229.74 |
| 13 |
256-311 |
BUSHING-SPLIT Price: $13.37 |
| 14 |
33115-090 |
SCREW-HH Price: $13.76 |
| 15 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 15 |
532052160 |
Washer This part replaces 819171616. Price: $3.99 |
| 16 |
107-2550 |
CABLE-CONTROL, TRACTION Price: $194.40 |
| 16 |
532124600 |
Support, Handle Shift L. H. Price: $2.38 |
| 17 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 17 |
532123632 |
Link, Shift Price: $14.99 |
| 18 |
17-9420 |
SCREW-HANDLE Price: $3.49 |
| 18 |
871040412 |
Bolt, Fin Hex 1/4-28 UNF x 3/4 Gr. 8 Price: $3.99 |
| 19 |
810040400 |
Washer, Lock 1/4 Price: $3.99 |
| 19 |
94-1373 |
BRACKET-LOCK Price: $24.82 |
| 20 |
734115201 |
WASHER - M6 This part replaces 819091210. Price: $1.99 |
| 20 |
94-1372 |
BRACKET-MOW Price: $18.44 |
| 21 |
532123484 |
Arm, Shift Price: $2.38 |
| 21 |
94-1375 |
TRUNNION-BRACKET, LOCK Price: $23.45 |
| 22 |
532105701 |
Washer, Shift Plate Price: $3.99 |
| 22 |
94-1374 |
TRUNNION-BRACKET, MOW Price: $14.18 |
| 23 |
532106933 |
Knob, Shift Control Price: $3.99 |
| 23 |
94-1386 |
SHAFT-PEDAL Price: $44.42 |
| 24 |
532128215 |
Shift Rod Price: $20.99 |
| 24 |
94-1304 |
CABLE-LOCK, NEUTRAL Price: $153.45 |
| 25 |
32128-20 |
NUT-HF Price: $0.99 |
| 25 |
876020416 |
Pin, Cotter 1/8 x 1 Price: $3.99 |
| 26 |
873610500 |
NUT This part replaces 873810500. Price: Call Us |
| 26 |
94-3489 |
SCREW-HH Price: $1.70 |
| 27 |
140-6108 |
PIN-FLAG, NEUTRAL LOCK This part replaces 94-1300. Price: $31.21 |
| 27 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873510500. Price: $2.69 |
| 28 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 28 |
532128085 |
Extension, Spring Price: $4.99 |
| 29 |
2411-41 |
ROD END-BALL JOINT Price: $40.28 |
| 29 |
532128084 |
Support, Handle Shift R. H. Price: $2.38 |
| 30 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 31 |
532123409 |
Spacer, Split Price: $3.08 |
| 31 |
93-2092 |
CLAMP-CABLE Price: $3.46 |
| 32 |
33114-016 |
SCREW-HH Price: $0.27 |
| 33 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 33 |
8736800600 |
Nut Crownlock 3/8 - 16 Price: Call Us |
| 34 |
810040500 |
Washer Lock Hvy Hlcl Spr 5/16 This part replaces 811050500. Price: $2.99 |
| 34 |
93-2279 |
CLAMP-CABLE Price: $7.12 |
| 35 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 36 |
33115-016 |
SCREW-HH Price: $0.75 |
| 37 |
33014-00 |
NUT-HEX Price: $0.25 |
| 38 |
2411-38 |
JOINT-BALL Price: $21.96 |
| 39 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 40 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 41 |
33093-00 |
WASHER-FLAT Price: $0.70 |
