| Ref | Part Number | Description |
|---|
| 1 |
03865A |
Upper Housing (AYP part number) Price: Call Us |
| 1 |
27-7200 |
AIR CLEANER HOSE Price: $90.31 |
| 2 |
001919 |
Tapping Screw (Dana part number) Price: Call Us |
| 2 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 3 |
001151 |
Detent Ball (Dana part number) Price: Call Us |
| 3 |
27-7180 |
CAP Price: $70.51 |
| 4 |
003626 |
Detent Spring (Dana part number) Price: Call Us |
| 4 |
27-7100 |
AIR CLEANER ASM Price: $323.10 |
| 5 |
003623 |
Screw Set (Dana part number) Price: Call Us |
| 5 |
27-7160 |
DECAL-INSTALLATION Price: $19.89 |
| 6 |
004458 |
Shifter Assembly (Dana part number) Price: Call Us |
| 6 |
32107-11 |
NUT-SQUARE Price: $0.22 |
| 7 |
3258-19 |
SCREW Price: $0.42 |
| 7 |
530003789 |
V-Ring Price: $3.33 |
| 8 |
003907 |
Friction Puck (Dana part number) Price: Call Us |
| 8 |
3217-6 |
NUT-HEX Price: $1.19 |
| 9 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 9 |
530003906 |
Plain Washer Price: $3.33 |
| 10 |
001099 |
Retaining Ring (Dana part number) Price: Call Us |
| 10 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 11 |
001068 |
Plain Washer .632 x 1.00 x .041 (Dana part number) Price: Call Us |
| 11 |
001082 |
Plain Washer .632 x 1.00 x .031 (Dana part number) Price: Call Us |
| 11 |
001145 |
Plain Washer .632 x 1.00 x .060 (Dana part number) Price: Call Us |
| 11 |
001319 |
Plain Washer .632 x 1.00 x .082 (Dana part number) Price: Call Us |
| 11 |
001358 |
Plain Washer .632 x 1.00 x .050 (Dana part number) Price: Call Us |
| 11 |
001423 |
Plain Washer .632 x 1.00 x .026 (Dana part number) Price: Call Us |
| 11 |
001424 |
Plain Washer .632 x 1.00 x .036 (Dana part number) Price: Call Us |
| 11 |
001425 |
Plain Washer .632 x 1.00 x .046 (Dana part number) Price: Call Us |
| 11 |
001441 |
Plain Washer .632 x 1.00 x .020 (Dana part number) Price: Call Us |
| 11 |
001959 |
Plain Washer .632 x 1.00 x .010 (Dana part number) Price: Call Us |
| 11 |
003312 |
O-Ring (Dana part number) Price: Call Us |
| 11 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 12 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 13 |
27-7150 |
A/C CUP ASM Price: $82.89 |
| 13 |
531003876 |
Plain Washer .632 x 1.38 x .046 Price: Call Us |
| 14 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 14 |
530001374 |
Woodruff #9 Key Price: $3.33 |
| 15 |
004171 |
Input Shaft Assembly Kit (Dana part number) Price: Call Us |
| 15 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 16 |
3290-360 |
SCREW-HH Price: $4.34 |
| 17 |
003624 |
Retaining Ring (Dana part number) Price: Call Us |
| 17 |
22-7810 |
SPACER Price: $16.90 |
| 18 |
322-3 |
SCREW-HH Price: $0.79 |
| 19 |
001542 |
Flange Bearing (Dana part number) Price: Call Us |
| 21 |
003631 |
Clutch Collar (Dana part number) Price: Call Us |
| 22 |
003828 |
Clutch Key (Dana part number) Price: Call Us |
| 23 |
530001369 |
Woodruff #3 Key Price: $3.33 |
| 24 |
003976 |
Intermediate Shaft (Dana part number) Price: Call Us |
| 25 |
001375 |
Woodruff #61 Key (Dana part number) Price: Call Us |
| 26 |
003627 |
Retaining Ring (Dana part number) Price: Call Us |
| 28 |
003841 |
Spacer (Dana part number) Price: Call Us |
| 35 |
003628 |
Plain Washer (Dana part number) Price: Call Us |
| 37 |
003422 |
Spacer (Dana part number) Price: Call Us |
| 38 |
004193 |
Comb. Gear Assembly (Dana part number) Price: Call Us |
| 39 |
003967 |
Idler Shaft (Dana part number) Price: Call Us |
| 40 |
530001708 |
Plain Washer Price: $1.99 |
| 44 |
003973 |
Drive Shaft (Dana part number) Price: Call Us |
| 45 |
003724 |
Tapping Screw (Dana part number) Price: Call Us |
| 51 |
001145 |
Plain Washer (Dana part number) Price: Call Us |
| 52 |
003191 |
Felt Seal (Dana part number) Price: Call Us |
| 53 |
003180 |
Plain Washer (Dana part number) Price: Call Us |
| 54 |
003880 |
L.H. Axle (Dana part number) Price: Call Us |
| 56 |
003656 |
Retaining Ring (Dana part number) Price: Call Us |
| 58 |
003919 |
Cross Shaft (Dana part number) Price: Call Us |
| 60 |
003881 |
R.H. Axle (Dana part number) Price: Call Us |
| 61 |
03864B |
Lower Housing (AYP part number) Price: Call Us |
| 62 |
003920 |
Friction Puck (Dana part number) Price: Call Us |
| 63 |
003276 |
Brake Disc(Dana part number) Price: Call Us |
| 64 |
003758 |
Spacer (Dana part number) Price: Call Us |
| 65 |
003916 |
Brake Jaw (Dana part number) Price: Call Us |
| 66 |
003843 |
Dowel Pin (Dana part number) Price: Call Us |
| 67 |
003915 |
Tapping Screw (Dana part number) Price: Call Us |
| 68 |
530003768 |
Actuating Lever Price: $1.99 |
| 69 |
530003760 |
Plain Washer Price: $3.33 |
| 70 |
003917 |
Anti-Rotation Bracket (Dana part number) Price: Call Us |
| 71 |
003847 |
Locknut (Dana part number) Price: Call Us |
