| Ref | Part Number | Description |
|---|
| 0 |
640122A |
CARBURETOR This part replaces 632394B. Price: $77.00 |
| 1 |
108-4465 |
RH UPPER RAMP ASM Price: $111.86 |
| 1 |
530015241 |
Screw-Screen Price: $1.99 |
| 1 |
632166A |
SHAFT & LEV Price: $3.86 |
| 2 |
108-4464 |
LH UPPER RAMP ASM Price: $111.86 |
| 2 |
530071544 |
Kit-Spark Arrestor Price: $6.99 |
| 2 |
632169 |
SPRING Price: $1.25 |
| 3 |
107-7755 |
RAMP-LOWER, RH Price: $93.63 |
| 4 |
107-7753 |
RAMP-LOWER, LH Price: $94.01 |
| 4 |
530016338 |
Bolt-Muffler Price: $1.99 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
107-7763 |
ADJUSTER-GROOMER Price: $66.81 |
| 5 |
530071363 |
Gasket-Muffler (kit) Price: $5.99 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 6 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 6 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 6 |
631621 |
SHUTTER Price: $1.20 |
| 7 |
32120-64 |
RING-SNAP, EXTERNAL Price: $0.25 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 7 |
952030249 |
Spark Plug (RCJ-6Y) Price: $3.99 |
| 8 |
104-4754 |
SPRING-DETENT Price: $23.47 |
| 8 |
530071668 |
Kit - Cylinder Price: Call Us |
| 9 |
104-2065 |
SCREW-HWH Price: $0.28 |
| 9 |
530071363 |
Gasket-Cyl./Carb. (kit) Price: $5.99 |
| 10 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 10 |
545030402 |
CARBURETOR ADAPTOR This part replaces 530056403. Price: $8.99 |
| 10 |
631888 |
SHAFT & LEV Price: $5.16 |
| 11 |
108-4469 |
SPRING-COMPRESSION Price: $7.45 |
| 11 |
530016309 |
Screw Price: $1.99 |
| 12 |
3220-3 |
NUT-HJ Price: $0.28 |
| 12 |
530071363 |
Gasket-Carb. (kit) Price: $5.99 |
| 13 |
107-7769 |
ROD-BALL JOINT Price: $101.30 |
| 13 |
530071628 |
Kit-Carb. (C1Q-W10B) Price: $34.99 |
| 14 |
121-6991 |
BOLT-SHOULDER Price: $31.12 |
| 14 |
530038747 |
Choke Plate Mounting Price: $1.99 |
| 14 |
631815 |
SHUTTER Price: $1.20 |
| 15 |
530038686 |
Shutter-Choke Price: $1.99 |
| 15 |
630735 |
SPRING Price: $1.25 |
| 16 |
530052431 |
Air Box Price: $1.99 |
| 16 |
632164 |
FUEL FITTING Price: $5.95 |
| 16 |
99-2018 |
SPACER-ARM, IDLER Price: $14.99 |
| 17 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 17 |
530016353 |
Screw Price: $1.99 |
| 18 |
43-0940 |
SPACER Price: $1.25 |
| 18 |
530036569 |
Plate - Filter Support Price: $1.99 |
| 19 |
32121-134 |
PIN-ROLL Price: $0.35 |
| 19 |
530036575 |
Foam-Air Filter Price: $1.99 |
| 20 |
127-4256 |
PLATE-GROOMER, 5 INCH Price: $17.04 |
| 20 |
530054414 |
Cover-Air Filter Price: $3.99 |
| 21 |
127-4254 |
SPACER Price: $53.61 |
| 21 |
530015892 |
Screw Price: $1.99 |
| 22 |
121-1759 |
SPACER Price: $1.59 |
| 22 |
530015852 |
Spacer-Choke Price: $1.99 |
| 23 |
115-8486 |
SCREW-HH Price: $0.68 |
| 23 |
530015254 |
Washer Price: $1.99 |
| 25 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 25 |
631700 |
FLOAT BOWL Price: $2.99 |
| 26 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 26 |
632815 |
SPRING This part replaces 632386. Price: $1.10 |
| 27 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
530071363 |
Seal-Cylinder (kit) Price: $5.99 |
| 28 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 29 |
530055160 |
Ignition Module Price: $34.99 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
530016357 |
Screw Price: $1.99 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
581425901 |
SWITCH, GROUND WIRE This part replaces 530014662. Price: $1.99 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 32 |
530014663 |
Assy-Leadwire Price: $5.99 |
| 34 |
530016381 |
Screw-Nose Cone Price: $2.99 |
| 35 |
530016382 |
Nut-Nose Cone Price: $2.99 |
| 36 |
530071356 |
Kit-Switch Price: $4.99 |
| 37 |
530027569 |
Handle-Starter Price: $1.99 |
| 38 |
530069232 |
Kit - Rope Price: $3.99 |
| 39 |
530016080 |
Screw Price: $1.99 |
| 40 |
530038604 |
Coupling-Drive Price: $1.99 |
| 40 |
632385 |
NUT Price: $8.76 |
| 41 |
530015941 |
Retain. Ring-C'shaft Price: $1.99 |
| 42 |
530055728 |
Outer Bearing Price: $6.99 |
| 43 |
530071615 |
Kit-C'case Seal Price: $4.99 |
| 44 |
530032125 |
Inner Bearing Price: $11.99 |
| 44 |
631334A |
GASKET This part replaces 631334. Price: $2.25 |
| 45 |
530056710 |
Shroud-Rear Price: $14.99 |
| 46 |
530015934 |
Screw Price: $1.99 |
| 47 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 48 |
530015880 |
Screw Price: $1.99 |
| 49 |
530055351 |
Shield-Heat Price: $2.99 |
| 50 |
530015805 |
Screw Price: $1.99 |
| 51 |
530071363 |
O-Ring-C'case (kit) Price: $5.99 |
| 52 |
530054753 |
Assy-Crankshaft Price: $27.99 |
| 55 |
545221701 |
FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 56 |
530015828 |
Washer-Flat Price: $1.99 |
| 57 |
530015775 |
Screw Price: $1.99 |
| 58 |
530027523 |
Retainer-Can Price: $2.99 |
| 60 |
545008010 |
STARTER SPRING This part replaces 530042085. Price: $3.99 |
| 61 |
530056706 |
Assy.-Fan Hsg Price: $17.99 |
| 62 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 64 |
530016379 |
Screw Price: $2.99 |
| 65 |
530014347 |
Assy-Fuel Cap Price: $4.99 |
| 66 |
530095646 |
Assy-Fuel Pickup Price: $2.99 |
| 67 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 68 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
