| Ref | Part Number | Description |
|---|
| 1 |
532170551 |
CONTROL.THROTTLE/CHOKE.BLACK This part replaces 532140310. Price: $24.99 |
| 1 |
95-0552 |
MUFFLER Price: $349.57 |
| 2 |
322-6 |
SCREW-HH Price: $0.45 |
| 2 |
596582501 |
Bolts This part replaces 817720410. Price: $2.99 |
| 3 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 4 |
532137348 |
MUFFLER.SINGLE.B&S.10-12HP Price: $89.99 |
| 4 |
95-0586 |
CLAMP ASM Price: $5.56 |
| 5 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 6 |
92-8996-03 |
SCREEN This part replaces 92-8996. Price: $52.36 |
| 7 |
95-0557 |
BRACKET-MUFFLER Price: $22.62 |
| 8 |
75-4705 |
HOSE-FUEL Price: $1.99 |
| 9 |
3269-32 |
RIVET-POP Price: $0.25 |
| 10 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 11 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 12 |
110-7501 |
HOSE-FUEL This part replaces 95-0619. Price: $12.75 |
| 13 |
322-10 |
SCREW-HH Price: $0.70 |
| 13 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED This part replaces 532125593. Price: $8.99 |
| 14 |
2412-73 |
CLAMP-R Price: $2.56 |
| 14 |
813280324 |
Nipple Pipe 3/8 Npt X 3" Price: $3.12 |
| 15 |
532428287 |
VALUE.OIL.DRAIN This part replaces 813200300. Price: $14.99 |
| 15 |
95-0556-03 |
BASE-ENGINE This part replaces 95-0556. Price: $156.32 |
| 16 |
120-3411 |
ENGINE-16HP, VANGUARD (SERVICE) GAS This part replaces 98-0940. Price: $2,857.81 |
| 16 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 17 |
95-0551 |
TUBE-EXHAUST Price: $69.74 |
| 18 |
532136718 |
HEAT SHIELD Price: $3.79 |
| 18 |
95-0550 |
MANIFOLD-EXHAUST Price: $149.32 |
| 19 |
114-0607-03 |
AIR CLEANER COVER ASM This part replaces 85-8370. Price: $229.75 |
| 19 |
532105839 |
RECEPTACLE LT Price: $3.99 |
| 20 |
532105838 |
RETAINER LT Price: $4.99 |
| 20 |
85-8360 |
GASKET-RING Price: $23.07 |
| 21 |
596582301 |
Washers This part replaces 819091016. Price: $2.99 |
| 21 |
85-8430-03 |
BASE-CLEANER, AIR This part replaces 85-8430. Price: $210.07 |
| 22 |
105-8523 |
DISCONTINUED-SEE PB 954 This part replaces 95-5827. Price: Call Us |
| 23 |
33113-012 |
SCREW-HH Price: $0.71 |
| 23 |
532128953 |
HEAT SHIELD Price: $3.08 |
| 24 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 24 |
817021008 |
SCREW Price: $3.99 |
| 25 |
95-0645 |
PLATE-SURFACE, HOT Price: $37.68 |
| 26 |
86-7450 |
CABLE-GROUND Price: $23.53 |
| 27 |
86-7570 |
WIRE ASSY Price: $30.90 |
| 28 |
2412-98 |
CLAMP-HOSE Price: $1.39 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
98-0992 |
Shield-Carburetor, Inlet Price: Call Us |
| 30 |
532127057 |
STRIP Price: $2.38 |
| 31 |
532180645 |
GAS TANK 2GAL This part replaces 532140280. Price: $59.99 |
| 31 |
83-1770 |
BRIGGS 394018 Price: Call Us |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532140527. Price: $22.99 |
| 32 |
85-0420 |
Plate-Cover Price: Call Us |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 33 |
95-0582 |
HOSE-INTAKE, AIR Price: $61.51 |
| 34 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 35 |
88-8640 |
BRIGGS#692297 Price: Call Us |
| 36 |
85-0430 |
Knob-Air Cleaner Price: Call Us |
| 37 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 37 |
98-8154 |
Screw-Washer Face Price: Call Us |
| 38 |
85-0540 |
Screw Price: Call Us |
| 39 |
85-0470 |
Gasket-Carburetor Price: Call Us |
| 40 |
532124028 |
BUSHING.SNAP.NYL.BLK. Price: $4.99 |
| 41 |
33113-008 |
SCREW-HH Price: $0.95 |
| 42 |
83-2490 |
DECAL-JAPANESE Price: $14.18 |
| 43 |
95-0574 |
DISCONTINUED Price: Call Us |
| 44 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 44 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE This part replaces 817490412. Price: $3.99 |
| 46 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 62 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 72 |
596134201 |
Screws This part replaces 871070512. Price: $2.99 |
| 78 |
874760620 |
BOLT This part replaces 817490620. Price: $4.99 |
