| Ref | Part Number | Description |
|---|
| 1 |
233-39 |
KNOB-CONTROL Price: $16.12 |
| 2 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 3 |
76-8450 |
DISCONTINUED Price: Call Us |
| 4 |
3290-148 |
NUT-HF Price: $0.25 |
| 4 |
530058982 |
BOLT MUFFLER Price: $2.99 |
| 5 |
545227101 |
SCREW 6-19X.437 This part replaces 530015241. Price: $2.99 |
| 5 |
70-1480 |
RELAY Price: $105.19 |
| 6 |
545049301 |
KIT SWITCH Price: $8.99 |
| 6 |
83-2280 |
TIMER-DELAY Price: $126.04 |
| 7 |
3256-77 |
WASHER-FLAT Price: $1.60 |
| 7 |
545128201 |
PROTECTOR, SWITCH Price: $3.99 |
| 8 |
3290-126 |
SCREW-HWH Price: $1.79 |
| 8 |
530030179 |
PLUG SPARK (RCJ6-Y) This part replaces 952030249. Price: $3.99 |
| 9 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 10 |
3256-78 |
WASHER-FLAT Price: $1.21 |
| 10 |
545132501 |
BOOT, CARB Price: $12.99 |
| 11 |
530016187 |
SCREW Price: $3.99 |
| 11 |
94-5627 |
PLUG Price: $1.22 |
| 12 |
321-2 |
SCREW-HH Price: $2.79 |
| 12 |
545133301 |
PLATE, CARB Price: $5.99 |
| 13 |
77-3970 |
DISCONTINUED Price: Call Us |
| 14 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 15 |
76-5260 |
DISCONTINUED Price: Call Us |
| 16 |
545081813 |
GASKET Price: $14.99 |
| 16 |
76-8440 |
DISCONTINUED Price: Call Us |
| 17 |
545109801 |
BASE, AIRBOX Price: $6.99 |
| 17 |
86-5410 |
DISCONTINUED Price: Call Us |
| 18 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 18 |
530016101 |
NUT Price: $4.99 |
| 19 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 19 |
597797901 |
Air Filters This part replaces 545112101. Price: $6.99 |
| 20 |
545109601 |
COVER, AIRBOX This part replaces 545176801. Price: $11.99 |
| 20 |
67-7160 |
BLOCK-FUSE Price: $18.75 |
| 21 |
109355 |
FUSE-BLADE, 15 AMP This part replaces 218-581. Price: $3.09 |
| 21 |
218-573 |
FUSE-5 AMP Price: $2.64 |
| 21 |
530059796 |
KNOB ASSY AIRBOX COVER Price: $4.99 |
| 22 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 22 |
545108201 |
LEAD WIRE ASSY W/GROUND This part replaces 545108202. Price: $9.99 |
| 23 |
2412-31 |
CLAMP-BODEN Price: $1.56 |
| 23 |
585836101 |
MODULE IGNITION 125B HAOLONG This part replaces 545108101. Price: $27.99 |
| 24 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 24 |
530016456 |
SCREW M4 X .70 TT 16MM Price: $2.99 |
| 25 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 26 |
575227901 |
RING PISTON This part replaces 530019283. Price: $5.99 |
| 26 |
76-4300 |
LEVER-THROTTLE Price: $33.40 |
| 27 |
2412-39 |
CLAMP-R Price: $1.70 |
| 27 |
530015162 |
WRIST PIN RET. Price: $2.99 |
| 28 |
48-7880 |
NUT-HEX Price: $0.25 |
| 28 |
545081816 |
KIT, CRANKSHAFT Price: $29.99 |
| 29 |
48-7890 |
NUT-HEX Price: $0.25 |
| 29 |
545013401 |
BEARING RADIAL BALL (6201) Price: $5.99 |
| 30 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 30 |
545081815 |
CRANKSHAFT SEAL Price: $7.99 |
| 32 |
577929601 |
CAP BEARING This part replaces 545068301. Price: $14.99 |
| 33 |
530015940 |
SCREW Price: $2.99 |
| 34 |
530015897 |
SCREW-M5-0.8 X 25MM(TAP) Price: $2.99 |
