| Ref | Part Number | Description |
|---|
| 1 |
532196498 |
DECK.SVC.54".4GWB.GREY This part replaces 532196838. Price: $499.99 |
| 1 |
93-5633 |
DISCONTINUED Price: Call Us |
| 2 |
67-1300 |
DECAL Price: $29.99 |
| 3 |
33103-016 |
SCREW-HHF Price: $5.18 |
| 4 |
33105-020 |
SCREW-HHF Price: $0.54 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 5 |
93-5988 |
HUB-PIVOT This part replaces 93-5204. Price: $29.62 |
| 6 |
532187297 |
COVER.MANDREL.LH.DECK.54" Price: $27.99 |
| 6 |
93-5447 |
NUT-CLINCH Price: $0.95 |
| 7 |
532188187 |
COVER.MANDREL.RH.DECK.54" Price: $27.99 |
| 7 |
95-0814 |
DECAL-TOWER, STEERING This part replaces 93-5424. Price: $24.40 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 532174365. Price: $6.99 |
| 8 |
93-5205 |
DISCONTINUED Price: Call Us |
| 9 |
256-132 |
BUSHING-FLANGE Price: $8.20 |
| 10 |
9547 |
WASHER-THRUST This part replaces 256-260. Price: $5.69 |
| 11 |
93-5312 |
KNOB Price: $9.21 |
| 12 |
93-5629 |
TOWER COVER ASM Price: $141.80 |
| 13 |
597023501 |
MANDRELS This part replaces 532187291. Price: $24.99 |
| 13 |
98-1471 |
WHEEL-STEERING This part replaces 93-5212. Price: $145.99 |
| 14 |
108-9342 |
NUT-HEX This part replaces 93-5590. Price: $3.49 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 15 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
93-5429 |
COLLAR-FOAM Price: $36.18 |
| 17 |
93-5439 |
SEAL-STEERING Price: $9.64 |
| 18 |
32151-29 |
RING-RETAINING Price: $3.59 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 19 |
93-5428 |
SHAFT-STEERING Price: $205.06 |
| 20 |
93-5446 |
CAP-VINYL Price: $1.41 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 21 |
93-5309 |
ROD-BRAKE PARKING Price: $18.80 |
| 22 |
93-5262 |
SPRING-EXTENSION Price: $10.21 |
| 23 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 24 |
114-2718 |
PAWL-BRAKE This part replaces 93-5276. Price: $32.10 |
| 25 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 25 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $4.99 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 26 |
93-5165 |
VALVE-CONTROL, STEERING Price: $1,040.32 |
| 27 |
283-5 |
PIN-CLEVIS Price: $11.99 |
| 27 |
532187257 |
DEFLECTOR.BLACK.54" This part replaces 532188938. Price: $64.99 |
| 28 |
93-5989 |
ROD-TILT This part replaces 93-5208. Price: $72.02 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
532173436 |
PULLEY MANDREL Price: $14.99 |
| 33 |
596134801 |
Nuts This part replaces 532178342. Price: $1.00 |
| 34 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 35 |
532188635 |
PIN.SUSPENSION.REAR.54" Price: $21.99 |
| 36 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 38 |
532188657 |
SPRING COMPRESSION PULL Price: $4.99 |
| 39 |
532187284 |
PULLEY.IDLER.STATIONARY Price: $49.99 |
| 40 |
819132203 |
Washer 13/32 x 1-3/8 x 3 Ga. Price: $4.99 |
| 41 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 42 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 43 |
532196216 |
ARM.IDLER.54" Price: $129.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
584451901 |
V-BELT.54".HIGH-PERFORMANCE This part replaces 532191273. Price: $79.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 50 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 51 |
596987501 |
Bolts This part replaces 872110610. Price: $3.99 |
| 52 |
532188460 |
IDLER PULLEY Price: $43.99 |
| 53 |
596564404 |
Bolts This part replaces 874780636. Price: $2.99 |
| 56 |
532155986 |
BAR.ADJUST.WHEEL.ANTI.SCALP.BL Price: $17.99 |
| 57 |
532156941 |
RIVET.PIN.HEAD.YELLOW. Price: $4.99 |
| 58 |
531168601 |
SERVICE KIT BAFFLE.RIGHT.54" This part replaces 532187342. Price: $12.99 |
| 59 |
531168701 |
SERVICE KIT BAFFLE.LEFT.54" BA This part replaces 532187344. Price: $19.99 |
| 60 |
531168801 |
SERVICE KIT BAFFLE BAFFLE CENT This part replaces 532187607. Price: $19.99 |
| 90 |
596580801 |
Bolts This part replaces 874760516. Price: $2.99 |
| 91 |
529846201 |
SERVICE KIT BRKT.NOSEROLLER.RH This part replaces 532180535. Price: $5.99 |
| 94 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 95 |
529846101 |
SERVICE KIT BRKT.NOSEROLLER.LH This part replaces 532180534. Price: $5.99 |
| 97 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 98 |
532187282 |
SPRING.CLUTCH.DRIVE.54 Price: $11.99 |
| 113 |
596435701 |
Bolts This part replaces 872110508. Price: $2.99 |
| 114 |
532187556 |
ROD TENSION RELIEF Price: $17.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 118 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 122 |
532187557 |
BUSHING.RELIEF.TENSION Price: $7.99 |
| 180 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 182 |
594092501 |
Rods This part replaces 532179127. Price: $5.99 |
| 183 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
