| Ref | Part Number | Description |
|---|
| 1 |
125-7091 |
CRANKSHAFT ASM Price: $2,915.83 |
| 2 |
125-6995 |
PIN Price: $5.45 |
| 2 |
532412282 |
DRAWBAR.LOWER.2PC.18/22 Price: $32.99 |
| 3 |
532430771 |
LOGO.HUSQ.GT.LT.CROWN.H This part replaces 532405012. Price: $5.99 |
| 4 |
125-6937 |
GEAR Price: $205.45 |
| 5 |
125-7185 |
KEY Price: $2.16 |
| 5 |
532438964 |
SUBASM.DASH.UPPER.W/BUMPER This part replaces 532407592. Price: $49.99 |
| 7 |
125-7182 |
PIN-SPRING Price: $3.77 |
| 8 |
125-6925 |
V-PULLEY Price: $255.74 |
| 9 |
125-7109 |
WASHER Price: $19.67 |
| 10 |
125-6956 |
BOLT Price: $40.22 |
| 11 |
125-6951 |
BOLT Price: $6.77 |
| 12 |
127-3160 |
FLYWHEEL ASM Price: $1,222.30 |
| 14 |
125-6943 |
GEAR Price: $137.73 |
| 14 |
532441267 |
HOOD.HUSQVARNA.LT.ORANGE This part replaces 532411073. Price: $79.99 |
| 15 |
532406664 |
LENS.HUSQVARNA LT.LH This part replaces 532411079. Price: $14.99 |
| 16 |
127-3097 |
PISTON ASM Price: $292.63 |
| 18 |
127-3098 |
PISTON RING ASM Price: $90.40 |
| 18 |
532439421 |
ASM.GRILLE HUSQVARNA.LT.498 This part replaces 532406667. Price: $129.99 |
| 24 |
125-7030 |
PIN Price: $43.23 |
| 25 |
125-7180 |
RING Price: $2.39 |
| 25 |
532406663 |
LENS.HUSQVARNA LT.RH This part replaces 532411078. Price: $14.99 |
| 26 |
125-7242 |
CONNECTING ROD ASM Price: $467.89 |
| 29 |
125-6955 |
BOLT Price: $20.62 |
| 30 |
125-7018 |
PIN-CRANK Price: $20.94 |
| 32 |
125-6997 |
PIN-PISTON Price: $21.73 |
| 33 |
125-7019 |
PIN-CRANK (.25) Price: $20.96 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS This part replaces 532196125. Price: $59.99 |
| 35 |
127-3099 |
PISTON ASM (0.25 O.S.) Price: $267.86 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 52 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 58 |
531152601 |
SERVICE KIT DRAWBAR FENDER DRA This part replaces 532412280. Price: $44.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 130 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 150 |
532407537 |
DUCT.AIR. Price: $34.99 |
| 151 |
532407807 |
BRACKET PIVOT Price: $27.99 |
| 152 |
531169901 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532199535. Price: $19.99 |
| 159 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 175 |
532199472 |
CROSSMEMBER Price: $24.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195228 |
BUSHING STEERING Price: $4.99 |
| 180 |
532415063 |
CHASS.WLDMNT.TL.12GA/2P.48/54 Price: $169.99 |
| 182 |
532407176 |
DASH.LOWER.PREDATOR LT Price: $69.99 |
| 183 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 191 |
532406665 |
INSERT REFLECTIVE Price: $6.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
532439976 |
PLUG.TEX.DASH.SVC.MINDER.GREY This part replaces 532411115. Price: $4.99 |
| 199 |
532413485 |
PLATE.DECK.LIFT.HUSQ.LT Price: $9.99 |
| 202 |
532406671 |
VENT SIDE HOOD This part replaces 532411074. Price: $8.99 |
| 203 |
532406670 |
VENT SIDE HOOD This part replaces 532411075. Price: $5.99 |
| 204 |
532441375 |
SUBASM.TOP.VENT.HUSQ.LT This part replaces 532411116. Price: $17.99 |
| 205 |
532406668 |
SKIRT.SIDE.HUSQVARNA.LT.RH.GRE This part replaces 532411076. Price: $11.99 |
| 206 |
532441345 |
SKIRT.SIDE.HUSQVARNA.LT.LEFT This part replaces 532411077. Price: $11.99 |
| 213 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 234 |
532404742 |
BUMPER.HOOD.TEX.HUSQVARNA Price: $5.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 238 |
532407881 |
TRIM.HUSQ LT.668 This part replaces 532411119. Price: $19.99 |
| 239 |
532404883 |
IS ITO Price: $5.99 |
| 282 |
532414110 |
CLIP.RETAINER.CONSOLE.LT.HUSQ Price: $2.99 |
| 283 |
532413492 |
CONSOLE ASM.DCKLFT.N/F This part replaces 532416316. Price: $37.99 |
| 284 |
583746501 |
CONSOLE.SFT.HYD.HUSQLT.SVC.498 This part replaces 532416345. Price: $22.99 |
| 285 |
532416315 |
CONSOLE INSERT RH Price: $14.99 |
| 286 |
532416317 |
CONSOLE.INSRT.LH.HUSQ.LT.BLACK Price: $11.99 |
| 287 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
