| Ref | Part Number | Description |
|---|
| 1 |
233-37 |
KNOB Price: $31.99 |
| 1 |
796010 |
Cylinder Assembly Price: Call Us |
| 2 |
399265 |
Bushing/Seal Kit (Magneto Side) Price: Call Us |
| 2 |
85-5160-03 |
LEVER-VALVE ASM This part replaces 85-5160. Price: $69.31 |
| 3 |
2710-16 |
LINK-CHAIN Price: $7.23 |
| 4 |
43-1950 |
HYD CONTROL VALVE ASM Price: $695.34 |
| 4 |
697106 |
Sump-Engine Price: Call Us |
| 5 |
237-42 |
O-RING Price: $2.78 |
| 5 |
796025 |
Head-Cylinder Price: Call Us |
| 6 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 7 |
237-22 |
O-RING Price: $2.43 |
| 8 |
83-9630 |
DISCONTINUED Price: Call Us |
| 9 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 10 |
237-78 |
O-RING Price: $3.85 |
| 11 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 11 |
794683 |
Tube-Breather Price: Call Us |
| 12 |
83-9620 |
DISCONTINUED Price: Call Us |
| 13 |
793988 |
Screw (Cylinder Head) Price: Call Us |
| 13 |
85-5810-01 |
BALL JOINT MOUNT ASM This part replaces 85-5810. Price: $75.92 |
| 14 |
83-9640 |
DISCONTINUED Price: Call Us |
| 15 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 15 |
690946 |
Plug-Oil Drain Price: Call Us |
| 16 |
321-24 |
SCREW-HH This part replaces 321-23. Price: $2.31 |
| 16 |
797579 |
Crankshaft Price: Call Us |
| 17 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 18 |
237-21 |
O-RING Price: $0.70 |
| 19 |
340-110 |
FITTING-SWIVEL, 90 DEG Price: $49.98 |
| 20 |
110-0973 |
HOSE-HYD This part replaces 85-4990. Price: $84.41 |
| 21 |
340-23 |
CROSS-UNION Price: $31.69 |
| 22 |
692125 |
Screw (Crankcase Cover/Sump) Price: Call Us |
| 22 |
85-5190 |
DISCONTINUED Price: Call Us |
| 23 |
698281 |
Flywheel Price: Call Us |
| 24 |
222698S |
Key-Flywheel Price: Call Us |
| 25 |
796172 |
Piston Assembly (Standard) Price: Call Us |
| 26 |
791936 |
Ring Set (Standard) Price: Call Us |
| 27 |
698469 |
Lock-Piston Pin Price: Call Us |
| 28 |
796007 |
Pin-Piston Price: Call Us |
| 29 |
794122 |
Rod-Connecting Price: Call Us |
| 32 |
791118 |
Screw (Connecting Rod) Price: Call Us |
| 33 |
792868 |
Valve-Exhaust Price: Call Us |
| 34 |
791935 |
Valve-Intake Price: Call Us |
| 35 |
691279 |
Spring-Valve (Intake) Price: Call Us |
| 36 |
691279 |
Spring-Valve (Exhaust) Price: Call Us |
| 37 |
697352 |
Guard-Flywheel Price: Call Us |
| 42 |
499586 |
Keeper-Valve Price: Call Us |
| 43 |
691968 |
Slinger-Governor/Oil Price: Call Us |
| 45 |
690564 |
Tappet-Valve Price: Call Us |
| 46 |
793880 |
Gear-Cam Price: Call Us |
| 48 |
697761 |
Short Block Price: Call Us |
| 50 |
796180 |
Manifold-Intake Price: Call Us |
| 51A |
796081 |
Gasket-Intake Price: Call Us |
| 53 |
690227 |
Stud (Carburetor) Price: Call Us |
| 54 |
691148 |
Screw (Intake Manifold) Price: Call Us |
| 78 |
691003 |
Screw (Flywheel Guard) Price: Call Us |
| 94 |
793610 |
Kit-Idle Mixture Price: Call Us |
| 95 |
690718 |
Screw (Throttle Valve) Price: Call Us |
| 98 |
695408 |
Kit-Idle Speed Price: Call Us |
| 108 |
695419 |
Valve-Choke Price: Call Us |
| 117 |
843099 |
Jet-Main (Standard) Price: Call Us |
| 118 |
790890 |
Jet-Main (High Altitude) Price: Call Us |
| 121 |
796184 |
Kit-Carburetor Overhaul Price: Call Us |
| 125 |
796109 |
Carburetor Price: Call Us |
| 130 |
699500 |
Valve-Throttle Price: Call Us |
| 131 |
699501 |
Kit-Throttle Shaft Price: Call Us |
| 133 |
694914 |
Float-Carburetor Price: Call Us |
| 135 |
698780 |
Tube-Fuel Transfer Price: Call Us |
| 141 |
792777 |
Kit-Choke Shaft Price: Call Us |
| 146 |
691639 |
Key-Timing Price: Call Us |
| 186 |
794873 |
Connector-Hose (Intake Manifold) Price: Call Us |
| 187 |
791805 |
Line-Fuel (Formed) (Cut to Required Length) Price: Call Us |
| 188 |
691693 |
Screw (Control Bracket) Price: Call Us |
| 192 |
691986 |
Adjuster-Rocker Arm Price: Call Us |
| 202 |
691841 |
Link-Mechanical Governor Price: Call Us |
| 209 |
692208 |
Spring-Governor (Green) Price: Call Us |
| 216 |
691840 |
Link-Choke Price: Call Us |
| 217 |
695409 |
Spring-Choke Return Price: Call Us |
| 222 |
694042 |
Bracket-Control Price: Call Us |
| 227 |
691374 |
Lever-Governor Control Price: Call Us |
| 232 |
691842 |
Spring-Governor Link Price: Call Us |
| 238 |
691843 |
Cap-Valve Price: Call Us |
| 240 |
394358S |
Filter-Fuel Price: Call Us |
| 265 |
691024 |
Clamp-Casing Price: Call Us |
| 267 |
794904 |
Screw (Casing Clamp) Price: Call Us |
| 276 |
695410 |
Washer-Sealing Price: Call Us |
| 304 |
796416 |
Blower Housing Price: Call Us |
| 305 |
697102 |
Screw (Blower Housing) (Long) Price: Call Us |
| 305A |
793376 |
Screw (Blower Housing) (Short) Price: Call Us |
| 306 |
796006 |
Shield-Cylinder Price: Call Us |
| 307 |
691003 |
Screw (Cylinder Shield) Price: Call Us |
| 309 |
693551 |
Motor-Starter Price: Call Us |
| 310 |
690323 |
Screw (Starter Motor) Price: Call Us |
| 324 |
796308 |
Screen/Cup Assembly Price: Call Us |
| 333 |
795315 |
Armature-Magneto Price: Call Us |
| 334 |
691061 |
Screw (Magneto Armature) Price: Call Us |
| 337 |
491055S |
Plug-Spark Price: Call Us |
| 358 |
796187 |
Gasket Set-Engine Price: Call Us |
| 404 |
691691 |
Washer (Governor Crank) Price: Call Us |
| 415 |
690283 |
Plug (Intake Manifold) Price: Call Us |
| 415A |
794129 |
Plug (Cover/Retainer) Price: Call Us |
| 431 |
697122 |
Elbow-Intake Price: Call Us |
| 445 |
698083 |
Filter-Air Cleaner Cartridge Price: Call Us |
| 462 |
691261 |
Washer (Starter Cable) Price: Call Us |
| 474 |
696459 |
Alternator Price: Call Us |
| 503 |
691532 |
Strap-Starter Price: Call Us |
| 505 |
691251 |
Nut (Governor Control Lever) Price: Call Us |
| 510 |
693699 |
Drive-Starter Price: Call Us |
| 513 |
692024 |
Clutch-Drive Price: Call Us |
| 523 |
699908 |
Dipstick Price: Call Us |
| 525 |
697184 |
Tube-Dipstick Price: Call Us |
| 552 |
697144 |
Bushing-Governor Crank Price: Call Us |
| 562 |
691119 |
Screw (Governor Control Lever) Price: Call Us |
| 579 |
691029 |
Nut (Starter Cable) Price: Call Us |
| 601 |
791850 |
Hose-Clamp (Green) Price: Call Us |
| 614 |
691620 |
Pin-Cotter Price: Call Us |
| 616 |
692012 |
Crank-Governor Price: Call Us |
| 633 |
699813 |
Seal-Choke/Throttle Shaft (Choke Shaft) Price: Call Us |
| 635 |
691909 |
Boot-Spark Plug Price: Call Us |
| 643 |
698401 |
Retainer-Air Filter Price: Call Us |
| 654 |
690958 |
Nut (Carburetor) Price: Call Us |
| 684 |
697157 |
Screw (Breather Assembly) Price: Call Us |
| 718 |
690959 |
Pin-Locating Price: Call Us |
| 724 |
697478 |
Link-Starter Switch Price: Call Us |
| 729 |
691224 |
Clip-Wire Price: Call Us |
| 741 |
697128 |
Gear-Timing Price: Call Us |
| 757 |
793242 |
Link-Counterweight Price: Call Us |
| 758 |
793763 |
Counterweight Price: Call Us |
| 759 |
697392 |
Pin-Counterweight Price: Call Us |
| 783 |
693713 |
Gear-Pinion Price: Call Us |
| 789 |
698329 |
Harness-Wiring Price: Call Us |
| 797 |
693167 |
Nut (Brush Retainer) Price: Call Us |
| 801 |
691283 |
Cap-Drive Price: Call Us |
| 802 |
691286 |
Cap-End Price: Call Us |
| 830 |
691095 |
Stud-Rocker Arm Price: Call Us |
| 847 |
790442 |
Dipstick/Tube Assembly Price: Call Us |
| 851 |
692424 |
Terminal-Spark Plug Price: Call Us |
| 914 |
697551 |
Screw (Rocker Cover) Price: Call Us |
| 947 |
699915 |
Solenoid-Fuel Price: Call Us |
| 967 |
697015 |
Filter-Pre Cleaner Price: Call Us |
| 968 |
698403 |
Cover-Air Cleaner Price: Call Us |
| 975 |
699502 |
Bowl-Fuel Price: Call Us |
| 1005 |
796083 |
Fan-Flywheel Price: Call Us |
| 1023 |
797421 |
Cover-Rocker Price: Call Us |
| 1026 |
692003 |
Rod-Push (Intake) Price: Call Us |
| 1029 |
691751 |
Arm-Rocker Price: Call Us |
| 1034 |
690822 |
Guide-Push Rod Price: Call Us |
| 1040 |
698368 |
Plate-Trim Price: Call Us |
| 1044 |
698139 |
Screw (Flywheel) Price: Call Us |
| 1051 |
691265 |
Ring-Retaining Price: Call Us |
| 1054 |
280275 |
Tie-Cable Price: Call Us |
| 1059 |
698516 |
Kit-Screw/Washer Price: Call Us |
| 1070 |
690363 |
Screw (Flywheel Fan) Price: Call Us |
| 1090 |
691293 |
Retainer-Brush Price: Call Us |
| 1091 |
691333 |
Cap-Limiter Price: Call Us |
| 1095 |
794152 |
Gasket Set-Valve Price: Call Us |
| 1119 |
691183 |
Screw (Alternator) Price: Call Us |
| 1127 |
695407 |
Screw (Float Bowl) Price: Call Us |
| 1263 |
697124 |
Reed-Breather Price: Call Us |
| 1264 |
697104 |
Screw (Breather Reed) Price: Call Us |
| 1267 |
697419 |
Latch-Blower Housing Price: Call Us |
| 1270 |
793243 |
Plug-AVS Counterweight Price: Call Us |
| 1329 |
331771372B1 |
Replacement Engine Price: Call Us |
| 792649 |
Ring |
Set (.020" Oversize) Price: Call Us 792649 |
| 796173 |
Piston |
Assembly (.020" Oversize) Price: Call Us 796173 |
