| Ref | Part Number | Description |
|---|
| 1 |
43-6840 |
HOUSING-LOWER This part replaces 24-8820. Price: $1,467.48 |
| 1 |
532100710 |
Steering Wheel Insert (AYP part number) Price: $10.20 |
| 2 |
72-9420 |
VENT This part replaces 21-8230. Price: $6.85 |
| 2 |
873940800 |
Toplock Jam Hex Nut (AYP part number) Price: $3.99 |
| 3 |
3219-2 |
NUT-HEX Price: $0.37 |
| 3 |
532100712 |
Washer (AYP part number) Price: $2.42 |
| 4 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 4 |
532100713 |
Steering Wheel (AYP part number) Price: $64.99 |
| 5 |
21-8280 |
DISCONTINUED Price: Call Us |
| 5 |
532110711 |
Steering Wheel Adaptor (AYP part number) Price: $11.99 |
| 6 |
21-8270 |
PIN-DOWEL Price: $6.65 |
| 6 |
532109816 |
Snap-In Nyliner (AYP part number) Price: $2.99 |
| 7 |
21-7770 |
SCREW-GEAR, DRIVE Price: $1.97 |
| 7 |
812000029 |
Klip Ring (AYP part number) Price: $1.99 |
| 8 |
21-7670 |
CASE-DIFFERENTIAL Price: $687.90 |
| 8 |
532121749 |
Washer (AYP part number) Price: $1.99 |
| 9 |
21-7700 |
SHAFT-MATE, PINION Price: $54.05 |
| 9 |
532009040 |
Front Wheel Bearings Price: $3.99 |
| 10 |
21-7720 |
WASHER-THRUST Price: $3.39 |
| 10 |
532122073 |
TIRE.FRONT (15X6-6) TURF SAVER This part replaces 532106222. Price: $49.99 |
| 11 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 24-8790. Price: $702.98 |
| 11 |
532059904 |
Tube (Not furnished w/Tractor) Price: $22.99 |
| 12 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 21-7690. Price: $702.98 |
| 13 |
21-7730 |
WASHER-THRUST, PINION Price: $2.65 |
| 13 |
532065139 |
Valve Stem (AYP part number) Price: $5.99 |
| 14 |
532059192 |
Value Cap (AYP part number) Price: $3.99 |
| 15 |
21-8080 |
DISCONTINUED Price: Call Us |
| 15 |
532108075 |
Axle, Assembly, Front (AYP part number) This part replaces 532108076. Price: $62.55 |
| 16 |
874761060 |
Hex Bolt (AYP part number) Price: $3.99 |
| 16 |
92-1773 |
SCREW-HHF This part replaces 324-23. Price: $3.05 |
| 17 |
12-5450 |
SCREW Price: $7.99 |
| 17 |
532105654 |
R.H. Spindle Assembly (AYP part number) Price: $32.99 |
| 18 |
21-7830 |
COVER-GEAR Price: $26.87 |
| 18 |
873610500 |
This part replaces 873810500. Price: Call Us |
| 19 |
532170162 |
ROD.ASM.TIE.BALL.JOINT.NOVAN This part replaces 532121334. Price: $59.99 |
| 19 |
86-7230 |
GEAR-INPUT, TRANSMISSION This part replaces 21-8150. Price: $610.12 |
| 20 |
21-7820 |
DISCONTINUED Price: Call Us |
| 20 |
532124836 |
Grease Fitting (AYP part number) Price: $5.99 |
| 21 |
21-8030 |
DISCONTINUED Price: Call Us |
| 21 |
532110438 |
Front Axle Bearing Spacer (AYP part number) Price: $5.99 |
| 22 |
21-8040 |
DISCONTINUED Price: Call Us |
| 22 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 23 |
21-8050 |
BRG SHIM .010 Price: $6.29 |
| 23 |
873680600 |
LOCKNUT This part replaces 873610600. Price: $1.99 |
| 24 |
21-8060 |
DISCONTINUED Price: Call Us |
| 24 |
532130468 |
Link Drag Sol Ball Jt 20 064 (AYP part number) This part replaces 532124032. Price: $49.99 |
| 25 |
28-0640 |
DISCONTINUED Price: Call Us |
| 25 |
532124041 |
Steering Shaft (AYP part number) Price: $3.33 |
| 26 |
532057079 |
Washer (AYP part number) Price: $2.99 |
| 26 |
99-5691 |
SCREW W/WASHER This part replaces 28-0660. Price: $7.18 |
| 27 |
254-90 |
BEARING-CUP Price: $11.29 |
| 27 |
532165857 |
SCREW.HX.WSH.HD This part replaces 871070410. Price: $2.99 |
| 28 |
21-8010 |
BRG CONE Price: $30.15 |
| 28 |
532124036 |
Steering Bracket Assembly (AYP part number) Price: $4.99 |
| 29 |
32151-83 |
RING-SNAP This part replaces 32120-32. Price: $0.34 |
| 29 |
532136874 |
Gear Sector (AYP part number) This part replaces 532124034. Price: $49.99 |
| 30 |
21-7850 |
PLUG-CUP Price: $23.35 |
| 30 |
810040400 |
Lock Washer (AYP part number) Price: $3.99 |
| 31 |
21-7870 |
DISCONTINUED Price: Call Us |
| 31 |
532160395 |
STEERING SHAFT SUPPORT This part replaces 532124035. Price: $6.99 |
| 32 |
21-8020 |
SPACER-BEARING Price: $28.84 |
| 32 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $5.99 |
| 33 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532124033. Price: $27.99 |
| 34 |
21-8070 |
DISCONTINUED Price: Call Us |
| 34 |
532156483 |
SPINDLE ASM LH This part replaces 532105656. Price: $14.99 |
| 35 |
254-66 |
CUP-BEARING, ROLLER Price: $17.92 |
| 35 |
532122819 |
Thd. Form Washer Hd. Hex Screw (AYP part number) Price: $2.38 |
| 36 |
254-65 |
BEARING-ROLLER, CONE Price: $62.13 |
| 36 |
583612401 |
LOCKNUT M (1 2) (5 2) This part replaces 873901000. Price: $2.99 |
| 37 |
32121-15 |
PIN-ROLL This part replaces 21-7710. Price: $1.60 |
| 37 |
532003366 |
Bearing (AYP part number) Price: $1.99 |
| 38 |
21-8090 |
SHIM-BEARING, DIFFERENTIAL (.003) Price: $1.09 |
| 38 |
532104757 |
Front Hub Cap (AYP part number) Price: $1.99 |
| 39 |
21-8100 |
SHIM-BEARING, DIFFERENTIAL (.005) Price: $3.46 |
| 39 |
532000278 |
Grease Fitting (AYP part number) Price: $2.99 |
| 40 |
21-8110 |
SHIM-BEARING, DIFFERENTIAL (.010) Price: $3.73 |
| 40 |
532121748 |
Washer (AYP part number) Price: $1.99 |
| 41 |
21-8120 |
SHIM-BEARING, DIFFERENTIAL (.030) Price: $5.43 |
| 41 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 42 |
532100714 |
Steering Shaft Tube (AYP part number) Price: $3.33 |
| 43 |
532105664 |
Front Saddle Support (AYP part number) Price: $9.99 |
| 44 |
532105663 |
Rear Saddle Support (AYP part number) Price: $8.25 |
| 45 |
817490508 |
Thd. Roll. Washer Hd., Hex Screw (AYP part number) Price: $3.99 |
| 46 |
810040500 |
Lock Washer (AYP part number) Price: $2.99 |
| 47 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111216. Price: $2.99 |
| 48 |
532124037 |
Pinion Gear (AYP part number) Price: $4.99 |
| 49 |
819091116 |
Washer (AYP part number) Price: $3.33 |
| 50 |
819272016 |
Washer (AYP part number) Price: $2.99 |
| 51 |
532121232 |
Spindle Cap (AYP part number) Price: $1.99 |
