| Ref | Part Number | Description |
|---|
| 1 |
69-1180 |
ARMREST Price: $166.08 |
| 2 |
32128-19 |
NUT-HF Price: $0.99 |
| 3 |
323-9 |
SCREW-HH Price: $1.29 |
| 4 |
3234-14 |
SCREW-HHF This part replaces 3234-23. Price: $0.61 |
| 5 |
104-4620 |
SEAT This part replaces 66-5400. Price: $273.15 |
| 6 |
92-6534 |
ORDER COMPLETE SEAT This part replaces 67-9560. Price: Call Us |
| 7 |
32128-20 |
NUT-HF Price: $0.99 |
| 8 |
40-3790 |
ADJ TRACK & LATCH Price: $261.53 |
| 9 |
322-1 |
SCREW-HH Price: $0.22 |
| 10 |
40-3820 |
ADJ TRACK Price: $351.81 |
| 11 |
71-2400 |
DISCONTINUED Price: Call Us |
| 12 |
71-2380 |
WASHER Price: $1.22 |
| 13 |
71-2390 |
RIVET-POP Price: $2.47 |
| 14 |
40-3890 |
TRIM Price: $89.47 |
| 15 |
65-5890 |
CAP-END Price: $8.09 |
| 16 |
2412-102 |
CLAMP-R Price: $6.85 |
| 17 |
39-5710 |
PLUG-PLASTIC Price: $8.50 |
| 18 |
65-5870 |
TUBE Price: $20.33 |
| 19 |
33114-025 |
SCREW-HH This part replaces 48-9460. Price: $0.70 |
| 20 |
3253-4 |
WASHER-LOCK This part replaces 48-9570. Price: $0.25 |
| 21 |
107-1188 |
SEAT SUSPENSION This part replaces 71-2420. Price: $951.87 |
| 22 |
68-9400 |
NUT-FLANGE This part replaces 48-7930. Price: $2.29 |
| 23 |
71-2410 |
PLATE-SUSPENSION, UPPER Price: $198.33 |
| 24 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 25 |
48-2920 |
DISCONTINUED Price: Call Us |
| 26 |
69-9660 |
SEAT SUPPORT BAR *B Price: $21.28 |
| 27 |
69-0770 |
BRACKET-ARM, RH Price: $117.82 |
| 28 |
69-1260 |
SPACER Price: $11.05 |
| 29 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 539102827 |
539102827 |
SPACER Price: $4.99 |
| 539102828 |
539102828 |
SCREW, 5/16 X 5/8 SHOULDER Price: $3.99 |
| 539103547 |
539103547 |
WASHER Price: $0.99 |
| 539105069 |
539105069 |
E-RING 5/8 Price: $2.99 |
| 539108120 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539108120. Price: $1.99 |
| 539108460 |
539108460 |
BOLT 5/16-18 X 1 1/4 TFS Price: $2.99 |
| 539108793 |
539108793 |
DAMPENER Price: $49.99 |
| 539110021 |
539110021 |
POST, RETURN TO NEUTRAL Price: $3.99 |
| 539110142 |
539110142 |
SHAFT, MOTION, BRAKE PLATED Price: $54.99 |
| 539110145 |
539110145 |
MOTION CASTING Price: $34.99 |
| 539110146 |
539113121 |
MOTION BUSHING This part replaces 539110146. Price: $3.99 |
| 539110233 |
539110233 |
MOTION CONTROL ARM, WLDMNT LH Price: $59.99 |
| 539110236 |
539110236 |
MOTION CONTROL ARM, WLDMNT RH Price: $59.99 |
| 539110268 |
539110268 |
BRAKE ROD FORMED RT Price: $11.99 |
| 539110269 |
539110269 |
BRAKE ROD FORMED LT Price: $11.99 |
| 539110282 |
539110282 |
BRAKE LEVER Price: $9.99 |
| 539110337 |
539110337 |
CONTROL LEVER CUSHION Price: $6.99 |
| 539110338 |
539110338 |
CONTROL LEVER Price: $54.99 |
| 539110340 |
594977001 |
Nuts This part replaces 539110340. Price: $4.99 |
| 539110342 |
596299801 |
Springs This part replaces 539110342. Price: $2.99 |
| 539110430 |
539110430 |
BUSHING ELASTOMER Price: $3.99 |
| 539110477 |
539110477 |
BRAKE LEVER SPRING Price: $3.99 |
| 539110478 |
539110478 |
BRAKE LEVER CAP Price: $2.99 |
| 539110675 |
539110675 |
SPRING BRACKET Price: $14.99 |
| 539916159 |
539916159 |
SPRING-TRANS Price: $5.99 |
| 539976935 |
596582201 |
Bolts This part replaces 539976935. Price: $2.99 |
| 539976937 |
539976937 |
HCS 5/16-18X2 Price: $2.99 |
| 539976978 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 539976988 |
596580601 |
Pins This part replaces 539976988. Price: $3.99 |
| 539990585 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 539990643 |
596565401 |
Screws This part replaces 539990643. Price: $1.99 |
| 539990692 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 539990717 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 539991034 |
596584001 |
Screws This part replaces 539991034. Price: $2.99 |
