| Ref | Part Number | Description |
|---|
| 1 |
485805 |
Belt, Cutter Deck Price: Call Us |
| 2 |
483422 |
Pulley, 5" Idler Price: Call Us |
| 3 |
04112-06 |
Nut, 3/4-16 Spiral Lock Price: Call Us |
| 4 |
04063-01 |
Key, 1/4 x 1/4 x 1-1/4" Price: Call Us |
| 5 |
483324 |
Pulley, 5.73" OD - 25mm Bore (52H) Price: Call Us |
| 6 |
04021-09 |
Nut, 3/8-16 Elastic Stop Price: Call Us |
| 7 |
04043-11 |
Flat washer, 1/4-.266 x .875 x .125 Price: Call Us |
| 8 |
483453-03 |
Bearing, 1" ID Price: Call Us |
| 9 |
462944 |
Pivot, Idler Price: Call Us |
| 10 |
483375 |
Spring, Cutter Deck Idler Price: Call Us |
| 11 |
463333 |
Cutter Deck w/Decals, SWZT36H This part replaces 462945. Price: Call Us |
| 12 |
43708 |
Pivot, Idler Price: Call Us |
| 13 |
424615 |
Bracket, Belt Guide Price: Call Us |
| 14 |
427325 |
Belt Cover LH SMZL-36 Price: Call Us |
| 15 |
04011-29 |
Screw, 1/4-20 x .375" (52H) Price: Call Us |
| 16 |
04001-30 |
Bolt, Hex Head 3/8-16 x 4.00 Price: Call Us |
| 17 |
461950 |
Spindle Assembly Price: Call Us |
| 18 |
483304 |
Debris Shield Price: Call Us |
| 19 |
483303 |
Bearing Price: Call Us |
| 20 |
43693 |
Spacer Price: Call Us |
| 21 |
43696 |
Spindle Housing Price: Call Us |
| 22 |
43694 |
Protector, Bearing Price: Call Us |
| 23 |
43695 |
Shaft, Spindle Price: Call Us |
| 24 |
04001-121 |
Bolt, Hex Head 5/8-11 x 1-1/2" Price: Call Us |
| 25 |
04030-07 |
Lockwasher, 5/8" Spring Price: Call Us |
| 26 |
04043-06 |
Flatwasher, 5/8-.688 x 1.75 x .134 HD Price: Call Us |
| 27 |
482878 |
Cutter Blade, 18" (52H) Price: Call Us |
| 29 |
04001-77 |
Bolt, Hex Head 3/8-16 x 3-1/2" Price: Call Us |
| 30 |
04041-38 |
Flatwasher, 3/8-.406 x 2.250 x .188 Price: Call Us |
| 31 |
482295 |
Wheel, Anti-Scalp Price: Call Us |
| 32 |
04117-01 |
Nut, 5/16-18 Flange Elastic Stop Price: Call Us |
| 33 |
451926 |
Shaft Weldment, Guide Roller Price: Call Us |
| 34 |
04001-09 |
Bolt, Hex Head 5/16-18 x 1" Price: Call Us |
| 35 |
462031 |
Discharge Chute Price: Call Us |
| 36 |
04021-10 |
Nut, 5/16-18 Elastic Stop Price: Call Us |
| 37 |
482245 |
Spring, Discharge Chute Price: Call Us |
| 38 |
04001-154 |
Bolt, Hex Head 5/16-18 x 4-3/4" Price: Call Us |
| 39 |
04001-12 |
Bolt, Hex Head 5/16-18 x 1-3/4" Price: Call Us |
| 40 |
427319 |
Belt Cover, RH SMZL-36 Price: Call Us |
| 41 |
04030-03 |
Lockwasher, 5/16" Price: Call Us |
| 43 |
04019-04 |
Nut, 3/8-16 Serrated Flange Price: Call Us |
| 44 |
04001-03 |
Bolt, Hex Head 1/4-20 x 2.00 Price: Call Us |
| 46 |
43711 |
Spacer Price: Call Us |
| 47 |
04043-04 |
Flatwasher, 3/8-.391 x .938 x .105 HD Price: Call Us |
