| Ref | Part Number | Description |
|---|
| 1 |
137-6110 |
TUBE ROLLER 3.0IN DIA X 24.5IN This part replaces 114-5413-03. Price: $273.64 |
| 1 |
581708382 |
KIT.CHASSIS.ASM.428 Price: $49.99 |
| 2 |
114-5403 |
SHAFT-ROLLER, FRONT Price: $82.00 |
| 2 |
532182219 |
LINE.BUND.18PC Price: $14.99 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 3 |
532173715 |
SCREW Price: $2.99 |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
532185476 |
BELT-V.STRING TRIMMER. Price: $22.99 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 5 |
586909102 |
BRACKET.IDLER.STRG.TRIM.004.15 Price: $1.99 |
| 6 |
114-5411 |
NUT-LOCK, BEARING Price: $24.46 |
| 6 |
532166042 |
PULLEY.V-GROOVE.IDLER Price: $14.99 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
874760620 |
BOLT This part replaces 532173716. Price: $3.99 |
| 8 |
873680600 |
LOCKNUT This part replaces 873930600. Price: $1.99 |
| 9 |
532166043 |
IDLER PULLEY Price: $17.99 |
| 10 |
532160829 |
SHOULDER BOLT Price: $3.99 |
| 11 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 12 |
532173717 |
SPACER.IDLER.BRACKET Price: $2.99 |
| 13 |
532174719 |
BOLT SHOULDER 3/8 -16X1 Price: $3.99 |
| 14 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT Price: $2.99 |
| 15 |
532173811 |
SPRING.RETURN.WHEELED.TRIMMER Price: $3.99 |
| 16 |
584953201 |
DEFLECTOR.BOTTOM.HW.TRIMMER Price: $34.99 |
| 17 |
817060410 |
SCREW 14-20 X 5/8 Price: $3.99 |
| 18 |
532178848 |
SCREW Price: $3.99 |
| 19 |
586916602 |
KEEPER.BELT.STRING.TRIM.BZP.15 This part replaces 586916603. Price: $11.99 |
| 20 |
581819302 |
COVER.CHASIS.STRIM.POU PRO.E/F Price: $17.99 |
| 21 |
532149746 |
SCREW.SLOT.TORX. Price: $3.99 |
| 22 |
873680600 |
LOCKNUT This part replaces 873610600. Price: $1.99 |
| 23 |
539990118 |
SLW 3/8 STD This part replaces 532850263. Price: $1.99 |
| 24 |
819121214 |
WASHER, FLAT 3/8 Price: $9.99 |
| 25 |
532180340 |
PULLEY.SPINDLE.WHEELED.TRIMMER Price: $24.99 |
| 26 |
532172551 |
SPACER, PULLEY Price: $3.99 |
| 27 |
532110485 |
BEARING This part replaces 532174549. Price: $7.99 |
| 28 |
532172520 |
JACKSHAFT.WHEELED.TRIMMER Price: $11.99 |
| 29 |
532186752 |
CHASSIS.COVER.BOTTOM.BLACK Price: $7.99 |
| 31 |
532174581 |
RING, RETAINING, EXTERNAL, Price: $3.99 |
| 32 |
532173973 |
SPRING.1.5".COMPRESSION Price: $11.99 |
| 33 |
532172519 |
PLATE.LOCKING.WHEELED.TRIMMER Price: $3.99 |
| 34 |
532180338 |
CARRIER PLATE ASSEMBLY Price: $49.99 |
| 36 |
532172516 |
COVER, BEARING Price: $4.99 |
| 37 |
532174580 |
RING, RETAINING, INTERNAL, Price: $5.99 |
| 38 |
532180337 |
MOW BALL This part replaces 532172523. Price: $11.99 |
| 39 |
532180334 |
BOLT, MOW BALL Price: $8.99 |
| 41 |
532174029 |
SPACER (2 2MC) Price: $2.99 |
| 43 |
532174042 |
DECAL, INSTRUCTION Price: $5.99 |
| 44 |
584990601 |
DECAL.TRIMMER.WARNING.CE Price: $2.99 |
| 45 |
532186753 |
BRACKET.BELT.KEEPER.BLACK Price: $3.99 |
| 46 |
817060408 |
SCREW Price: $3.99 |
| 50 |
114-5430 |
ROLLER REBUILD KIT Price: $99.53 |
