| Ref | Part Number | Description |
|---|
| 1 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 2 |
29-9790 |
DISCONTINUED Price: Call Us |
| 3 |
321-9 |
SCREW-HH Price: $0.27 |
| 4 |
3210-7 |
SCREW-HH Price: $0.61 |
| 5 |
29-6170 |
EXTENDED LEAF SPRING ASM Price: $45.56 |
| 6 |
3219-2 |
NUT-HEX Price: $0.37 |
| 7 |
29-6162 |
SWITCH-MICRO Price: $107.13 |
| 8 |
3249-11 |
SCREW-MACHINE Price: $0.54 |
| 9 |
46-8810 |
STOP-SPRING, LEAF Price: $9.17 |
| 10 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 11 |
3217-16 |
NUT-HEX Price: $0.25 |
| 12 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 16 |
52-8890-03 |
DISCONTINUED This part replaces 52-8890. Price: Call Us |
| 17 |
52-9070 |
PLATE-PUMP Price: $101.93 |
| 18 |
322-17 |
SCREW-HH Price: $2.62 |
| 19 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 20 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 21 |
321-4 |
SCREW-HH Price: $0.99 |
| 22 |
110-9650 |
LEAF SPRING ASM This part replaces 29-6150. Price: $33.06 |
| 23 |
251-259 |
BEARING-BALL Price: $13.67 |
| 506506202 |
586966402 |
PEDAL RUBBER L = 102MM This part replaces 506506202. Price: $14.99 |
| 506506501 |
506506501 |
PEDAL SHAFT CLAMP Price: $6.99 |
| 506535602 |
506535602 |
SPRING Price: $4.99 |
| 506535702 |
506535702 |
SPRING Price: $5.99 |
| 506542501 |
506542501 |
SPRING Price: $6.99 |
| 506574501 |
506574501 |
BRAKE PEDAL ASSY Price: $59.99 |
| 506599201 |
506952601 |
CABLE This part replaces 506599201. Price: $44.99 |
| 506599301 |
506599301 |
CONNECTOR Price: $5.99 |
| 506770502 |
506770502 |
PEDAL Price: $54.99 |
| 506770601 |
506952501 |
CABLE This part replaces 506770601. Price: $49.99 |
| 506781802 |
506781802 |
Price: $46.55 |
| 506887701 |
506887701 |
LINK Price: $6.40 |
| 506919101 |
506919101 |
SPRING Price: $5.99 |
| 721615201 |
721615201 |
Cotter Pin Price: $1.99 |
| 721839901 |
721839901 |
CLEVIS PIN Price: $5.99 |
| 725244951 |
725244951 |
BOLT - M8X16 Price: $2.99 |
| 725246151 |
725246151 |
BOLT Price: $4.99 |
| 731211801 |
732211801 |
LOCKNUT M8 This part replaces 731211801. Price: $3.99 |
| 734116401 |
734116401 |
WASHER BRB 8.4X17 Price: $5.99 |
| 735311920 |
735311920 |
Price: Call Us |
