| Ref | Part Number | Description |
|---|
| 1 |
125-7016 |
TAPPET Price: $16.62 |
| 2 |
125-7017 |
ROD-PUSH Price: $10.14 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
127-3797 |
CAMSHAFT ASM Price: $315.66 |
| 4 |
125-7008 |
METAL-THRUST Price: $25.42 |
| 6 |
127-3052 |
GEAR-CAMSHAFT Price: $199.39 |
| 7 |
125-7185 |
KEY Price: $2.16 |
| 8 |
127-3053 |
PULSER-CAMSHAFT Price: $19.46 |
| 9 |
125-7205 |
BOLT Price: $2.67 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
125-7213 |
BOLT Price: $2.67 |
| 11 |
127-3054 |
SENSOR-REV, GEAR Price: $158.02 |
| 11 |
583389701 |
KIT.SVC.CLUTCH.ELE.180505 This part replaces 532180505. Price: $299.99 |
| 12 |
127-3184 |
BOLT Price: $4.58 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
127-3063 |
SHAFT-IDLE, GEAR A Price: Call Us |
| 14 |
127-3066 |
IDLE GEAR A ASM Price: $135.01 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 17 |
125-7219 |
BOLT Price: $4.58 |
| 18 |
127-3070 |
GEAR-PUMP, SUPPLY Price: $121.19 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532194267. Price: $14.99 |
| 19 |
127-3167 |
WASHER-SPRING Price: $1.94 |
| 20 |
127-3185 |
NUT-LOCK Price: $5.51 |
| 21 |
127-3064 |
SHAFT-IDLE, GEAR B Price: Call Us |
| 21 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 22 |
127-3067 |
IDLE GEAR B ASM Price: $110.72 |
| 22 |
532187768 |
CONTROL.CHOKE.ERGO.BLACK This part replaces 532189541. Price: $27.99 |
| 25 |
127-3068 |
PLATE-IDLE, SHAFT Price: Call Us |
| 26 |
127-3069 |
GASKET-IDLE, SHAFT B Price: $4.14 |
| 27 |
125-7218 |
BOLT Price: $3.48 |
| 28 |
125-6927 |
BUSHING Price: $74.51 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
532181444 |
EXHAUST TUBE LH KAWI Price: $54.99 |
| 71 |
532181442 |
EXHAUST TUBE RH KAWI Price: $59.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 87 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
