| Ref | Part Number | Description |
|---|
| 1 |
240-4 |
GROMMET-RUBBER Price: $9.91 |
| 1 |
73510500 |
NUT Price: Call Us |
| 2 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 2 |
69-8970 |
SPACER Price: $9.57 |
| 3 |
69-8940 |
WASHER Price: $1.76 |
| 3 |
73220600 |
NUT.HEX.3/8-16UNC Price: Call Us |
| 4 |
340-70 |
NUT-LOCK Price: $2.10 |
| 4 |
74930568 |
BOLT TI Price: Call Us |
| 5 |
1572H |
SUB= 2882J Price: Call Us |
| 5 |
32152-2 |
NUT-LOCK, CONE Price: $1.79 |
| 6 |
110111X |
LEVER ASM CRT Price: Call Us |
| 6 |
328-24 |
SCREW-HH Price: $23.99 |
| 7 |
69-4400-01 |
CARRIER-DECK, WING Price: $2,088.97 |
| 7 |
72110404 |
BOLT Price: Call Us |
| 8 |
32128-45 |
NUT-HHF Price: $7.67 |
| 8 |
8700J |
PANEL TI Price: Call Us |
| 9 |
321-9 |
SCREW-HH Price: $0.27 |
| 9 |
86777 |
SUB= 750097 Price: Call Us |
| 10 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 10 |
9484R |
CONDIUT CLIP T Price: Call Us |
| 11 |
10040400 |
LOCKWASHER Price: Call Us |
| 11 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 12 |
32152-4 |
NUT-LOCK, CONE Price: $1.29 |
| 12 |
73220400 |
SUB= 50675 Price: Call Us |
| 13 |
23230506 |
SET SCREW Price: Call Us |
| 13 |
3272-33 |
PIN-COTTER Price: $0.54 |
| 14 |
120938X |
SPACER Price: Call Us |
| 15 |
19111116 |
WASHER Price: Call Us |
| 17 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 18 |
110651X |
SPACER CRT Price: Call Us |
| 19 |
2649M |
KEY T Price: Call Us |
| 20 |
110653X |
GUARD CRT Price: Call Us |
| 21 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 21 |
131691 |
SPLIT SPACER Price: Call Us |
| 22 |
104214X |
NUT TI Price: Call Us |
| 22 |
69-9450-03 |
BRACKET-HOSE, WING (LH) Price: $26.57 |
| 22 |
69-9460-03 |
BRACKET-HOSE, WING (RH) Price: $25.43 |
| 23 |
102190X |
TIRE.CHV.13X5.0-6 Price: Call Us |
| 23 |
340-117 |
CAP Price: $10.30 |
| 24 |
126875X |
RIVET.DRILL.1.75 Price: Call Us |
| 24 |
240-3 |
GROMMET-RUBBER Price: $17.44 |
| 25 |
125-1984 |
SPACER This part replaces 69-9000. Price: $0.68 |
| 25 |
4497H |
RETAINER M Price: Call Us |
| 26 |
69-9010 |
WASHER Price: $1.83 |
| 27 |
132672 |
BELT-V Price: Call Us |
| 27 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 28 |
104679X |
PULLEY-IDLER TI Price: Call Us |
| 28 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 29 |
12000032 |
KLIP RING Price: Call Us |
| 29 |
99-5917 |
SHAFT-PIVOT, LIFT ARM Price: $381.77 |
| 30 |
105611X |
SUB= 918105611X Price: Call Us |
| 30 |
340-115 |
FITTING-TEE, SWIVEL NUT Price: $56.09 |
| 31 |
102384X |
BOLT CRT Price: Call Us |
| 31 |
323-6 |
SCREW-HH Price: $0.66 |
| 32 |
102141X |
SHIFT ARM CRT Price: Call Us |
| 32 |
32108-103 |
SCREW-FH Price: $0.68 |
| 33 |
328-26 |
SCREW-HH Price: $38.75 |
| 33 |
74760616 |
BOLT Price: Call Us |
| 34 |
102383X |
COUNTERWEIGHT CRT Price: Call Us |
| 34 |
69-9300 |
PAD-BUMPER Price: $8.68 |
| 35 |
74760524 |
BOLT.HEX.5/16-1.5 Price: Call Us |
| 35 |
93-9922 |
SPACER Price: $11.40 |
| 36 |
102331X |
BRACKET LH CRT Price: Call Us |
| 36 |
72-4310 |
SWITCH-BALL Price: $84.47 |
| 37 |
130816 |
ENGINE SHEAVE Price: Call Us |
| 37 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 38 |
39-7650-01 |
COVER Price: $14.67 |
| 39 |
93-9925-01 |
ARM-LIFT, RH Price: $2,514.65 |
| 39 |
93-9926-01 |
ARM-LIFT, LH Price: $2,514.68 |
| 40 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 41 |
98-1452 |
WASHER-THRUST Price: $0.94 |
| 42 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 43 |
328-8 |
SCREW-HH Price: $5.54 |
| 44 |
69-5490 |
HOSE ASM Price: $89.51 |
| 45 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 46 |
74-2170 |
HYD CYLINDER ASM Price: $1,341.49 |
| 47 |
323-15 |
SCREW-HH Price: $1.53 |
| 48 |
74-2680-03 |
BRACKET-BULKHEAD Price: $34.49 |
| 49 |
98-7346 |
SPACER Price: $30.67 |
| 50 |
69-1580-03 |
ANCHOR-LH Price: $527.05 |
| 50 |
69-1600-03 |
ANCHOR-RH Price: $527.05 |
| 51 |
69-5970 |
TUBE-HYD Price: $143.02 |
| 52 |
95-6498 |
TUBE-HYD Price: $161.76 |
| 124258X |
RIM |
Price: Call Us 124258X |
