| Ref | Part Number | Description |
|---|
| 1 |
86-1970 |
V-BELT Price: $94.70 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 2 |
84-1550 |
MOUNT-RUBBER Price: $27.49 |
| 3 |
86-2020 |
DISCONTINUED Price: Call Us |
| 4 |
86-1990 |
WASHER-THRUST Price: $1.81 |
| 5 |
325-9 |
SCREW-HH Price: $1.87 |
| 6 |
93-6697 |
DECAL-LUBE This part replaces 70-2560. Price: $11.38 |
| 7 |
323-14 |
SCREW-HH Price: $1.34 |
| 8 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 9 |
100-2585 |
GEARBOX This part replaces 86-3090. Price: $3,295.02 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
86-1730 |
DISCONTINUED Price: Call Us |
| 11 |
532414336 |
KIT.SVC.CLUTCH.ELECTRIC. This part replaces 532400008. Price: $329.99 |
| 11 |
86-1830 |
COVER-DRIVESHAFT Price: $138.71 |
| 12 |
32144-70 |
SCREW-HWHTF Price: $1.99 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
86-1910 |
WIRE HARNESS-DECK Price: $326.77 |
| 14 |
2412-138 |
R-CLAMP Price: $1.36 |
| 15 |
32128-23 |
NUT-HF Price: $1.51 |
| 15 |
581290101 |
TANK.ASSEMBL.2.5GAL.NON-EPA This part replaces 532407489. Price: $99.99 |
| 16 |
86-1410 |
DISCONTINUED Price: Call Us |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 20 |
532423502 |
CONTROL.TH/CK.COBRA.B&S.TWN.BK Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK This part replaces 532160589. Price: $22.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
