| Ref | Part Number | Description |
|---|
| 1 |
121-8447 |
CORE-CONDENSER Price: $919.47 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 2 |
132-3469-03 |
LEG-LOWER Price: $49.94 |
| 2 |
583512701 |
SUBASM.AXLE.CAST.NZTR. Price: $169.99 |
| 3 |
32128-44 |
NUT Price: $2.69 |
| 4 |
132-3462-03 |
WALL-FRONT Price: $48.43 |
| 5 |
132-3463-03 |
WALL-BACK Price: $48.43 |
| 6 |
132-3464-03 |
WALL-SIDE, RIGHT Price: $24.92 |
| 6 |
532006266 |
WASHER THRUST Price: $4.99 |
| 7 |
132-3465-03 |
WALL-SIDE, LEFT Price: $24.92 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
132-3466 |
SEAL-STRIP Price: $3.72 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
132-3467 |
SEAL-EDGE Price: $2.87 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
363-8245 |
SCREW-TAP Price: $0.66 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
596238701 |
Washers Price: $3.99 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT Price: $34.99 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER Price: $7.99 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 35 |
583551401 |
GEAR.SECTOR.TEX.NZTR Price: $39.99 |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $2.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 585338801. Price: $14.99 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683701. Price: $4.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 80 |
532001370 |
THRUST WASHER Price: $4.99 |
| 81 |
597069702 |
Links Price: $9.99 |
| 82 |
532442147 |
SUBASM;PIVOT;BOLT;NZTR Price: $6.99 |
| 85 |
529846901 |
SERVICE KIT SUBASM.PIVOT.RH.NZ This part replaces 583561101. Price: $17.99 |
| 86 |
583561001 |
SUBASM.PIVOT.LH.NZTR Price: $27.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
