| Ref | Part Number | Description |
|---|
| 0 |
632370A |
CARBURETOR This part replaces 632110. Price: $95.04 |
| 1 |
123385X |
Pulley Price: Call Us |
| 1 |
140-5505 |
BRUSH-WAVE, 22 INCH FAIRWAY This part replaces 127-1577. Price: $197.56 |
| 1 |
631776A |
SHAFT & LEV This part replaces 631776. Price: $12.00 |
| 2 |
12000028 |
Ring, Retainer (AYP part number) Price: Call Us |
| 2 |
127-1567 |
BRUSH SHAFT ASM Price: $259.01 |
| 2 |
631970 |
RET SPRING Price: $3.00 |
| 4 |
2228M |
Key, Woodruff #9 (AYP part number) Price: Call Us |
| 5 |
73680500 |
Nut, Crownlock 5/16-18 Price: Call Us |
| 6 |
631778 |
SHUTTER Price: $1.20 |
| 6 |
72140506 |
Bolt, Carriage 5/16-18 UNC x 3/4 Price: Call Us |
| 7 |
123378X |
Strap, Torque Price: Call Us |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
17490512 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 9 |
146682 |
Spring, Brake Price: Call Us |
| 10 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 10 |
632112 |
SHAFT & LEV Price: $5.21 |
| 11 |
123583X |
Key, Square Price: Call Us |
| 14 |
632174 |
SHUTTER Price: $2.95 |
| 15 |
19171616 |
Washer 17/32 x 1 x 16 Ga. Price: Call Us |
| 15 |
630735 |
SPRING Price: $1.25 |
| 16 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $1.99 |
| 16 |
632164 |
FUEL FITTING Price: $5.95 |
| 17 |
126293X |
Link, Shift Price: Call Us |
| 17 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 18 |
74550412 |
Bolt 1/4-28 UNF Gr. 8 W/Patch Price: Call Us |
| 19 |
10040400 |
Washer, Lock 1/4 Price: Call Us |
| 20 |
19091210 |
Washer 9/32 x 3/4 x 10 Ga. Price: Call Us |
| 20 |
632281 |
IDLE SCREW Price: $2.60 |
| 21 |
126292X |
Arm, Shift Price: Call Us |
| 21 |
630766 |
SPRING Price: $1.25 |
| 22 |
105701X |
Washer, Shift Plate Price: Call Us |
| 22 |
630739 |
WASHER Price: $1.25 |
| 23 |
106933X |
Knob, Duckhead Price: Call Us |
| 23 |
630740 |
O RING Price: $1.49 |
| 24 |
128215 |
Rod Shift Price: Call Us |
| 25 |
631867 |
FLOAT BOWL Price: $2.34 |
| 25 |
76020416 |
Pin, Cotter 1/8 x 1 Price: Call Us |
| 26 |
73810500 |
Locknut 5/16-24 UNF Price: Call Us |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
128085 |
Extension, Spring Price: Call Us |
| 28 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 29 |
128084 |
Support Handle Shift RH Price: Call Us |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
137057 |
Spacer Axle Price: Call Us |
| 31 |
631022 |
CLIP Price: $1.25 |
| 32 |
19111116 |
Washer 11/32 x 11/16 x 16 Price: Call Us |
| 35 |
12000001 |
E-Ring Price: Call Us |
| 36 |
17720408 |
Screw, Thdrol 5/16-18 x 1/2 Price: Call Us |
| 40 |
631583 |
POWER SCREW Price: $10.18 |
| 41 |
630740 |
O RING Price: $1.49 |
| 42 |
630739 |
WASHER Price: $1.25 |
| 43 |
630738 |
SPRING Price: $1.25 |
| 44 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
