| Ref | Part Number | Description |
|---|
| 1 |
100-5797-03 |
BRACKET-HOC, RH Price: $30.11 |
| 2 |
323-12 |
SCREW-HH Price: $1.14 |
| 3 |
142932 |
Seal, Lip Price: Call Us |
| 3 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 4 |
104-1052-03 |
BRACKET-HOC, FRONT Price: $29.29 |
| 5 |
100-5799 |
SHIM-HOC, .060 INCH Price: $5.86 |
| 6 |
3231-9 |
SCREW-CARR Price: $1.18 |
| 7 |
104-4641 |
SHIM-HOC, .030 INCH Price: $2.34 |
| 8 |
150771 |
Bearing, Thrust 30 x 52 x 13 Price: Call Us |
| 8 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 9 |
3234-24 |
SCREW-HHF Price: $3.19 |
| 10 |
121-3575 |
SPACER-HOC This part replaces 105-9226. Price: $4.10 |
| 11 |
104-4624-03 |
BRACKET-HOC, LH Price: $30.11 |
| 12 |
136-2921 |
HOC PLATE ASM This part replaces 105-9225. Price: $6.80 |
| 13 |
142938 |
Block, Cylinder Assembly Price: Call Us |
| 15 |
142940 |
Seal, Lip Price: Call Us |
| 18 |
150772 |
Shaft, Motor Price: Call Us |
| 19 |
150773 |
Bearing, Thrust 42 x 68 x 16 Price: Call Us |
| 23 |
142944 |
Block, Cylinder Assembly Price: Call Us |
| 24 |
142945 |
Seal, Lip 10 x 25 x 7 Price: Call Us |
| 25 |
142946 |
Actuator, Bypass Price: Call Us |
| 27 |
142948 |
Seal, Lip 26 x 42 x 8 Price: Call Us |
| 28 |
142949 |
Ring, Retaining Price: Call Us |
| 29 |
142950 |
Washer 26 x 35 x 1 Price: Call Us |
| 34 |
142951 |
Oil Filter Element Price: Call Us |
| 35 |
142952 |
Arm, Bypass Price: Call Us |
| 36 |
142953 |
Ring, Retaining Price: Call Us |
| 37 |
142954 |
Arm, Actuating Price: Call Us |
| 38 |
142955 |
Pin, Actuating Price: Call Us |
| 39 |
150777 |
Bolt 5/16-24 x 1-3/4 Price: Call Us |
| 40 |
150778 |
Nut, Nylon Insert Hex Lock 5/16-24 Price: Call Us |
| 41 |
142958 |
Brake Rotor/Stator Kit Price: Call Us |
| 43 |
142884 |
Washer 7/8 O.D. x 7/16 x .060 Price: Call Us |
| 44 |
150829 |
Differential Assembly Price: Call Us |
| 52 |
142991 |
Washer 3/4 x 1.5 x .13 Price: Call Us |
| 53 |
142961 |
Seal .75 x 1.25 x .250 Price: Call Us |
| 56 |
142963 |
Shaft, Input Price: Call Us |
| 58 |
142964 |
Bolt 1/4-20 x 1.38 Price: Call Us |
| 59 |
142965 |
Pin .5 OD x .43 ID x .750 Price: Call Us |
| 62 |
142966 |
Arm, Control Price: Call Us |
| 63 |
142967 |
Puck, Dampener Price: Call Us |
| 64 |
142920 |
Set Screw Price: Call Us |
| 68 |
142969 |
Spring Price: Call Us |
| 69 |
144610 |
Stud 5/16-24 Price: Call Us |
| 83 |
142971 |
Jack Shaft Assembly Price: Call Us |
| 91 |
142976 |
Seal, Wiper Price: Call Us |
| 92 |
142977 |
Spring, helical compression Price: Call Us |
| 93 |
142978 |
Washer, Block Thrust Price: Call Us |
| 113 |
142917 |
Cap, Vent Assembly Price: Call Us |
| 114 |
142918 |
Fitting, O-Ring Assembly Price: Call Us |
| 119 |
142980 |
Spacer Price: Call Us |
| 134 |
144607 |
Nut, Castle 5/16-24 Price: Call Us |
| 135 |
144608 |
Pin, Cotter Price: Call Us |
| 139 |
150775 |
Spring, Compression Price: Call Us |
| 140 |
150776 |
Nut, Hex 5/16-24 Price: Call Us |
