| Ref | Part Number | Description |
|---|
| 1 |
127-3189 |
GASKET KIT Price: $835.82 |
| 1 |
583304901 |
DECK SVCX 38"194251X431 This part replaces 532194251. Price: $279.99 |
| 2 |
127-3126 |
GASKET-HEAD, CYLINDER Price: $178.72 |
| 3 |
127-3106 |
GASKET-COVER Price: $49.95 |
| 4 |
127-2986 |
SEAL-STEM, VALVE Price: $6.38 |
| 5 |
127-3027 |
SEAL-STEM, VALVE Price: $6.79 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
127-3021 |
GASKET-INJECTOR Price: $4.54 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 7 |
127-3107 |
GASKET-MANIFOLD, INTAKE Price: $21.63 |
| 7 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 8 |
127-3032 |
O RING-SENSOR, PRESSURE Price: $18.19 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 9 |
127-3033 |
O-RING Price: $13.39 |
| 10 |
127-3034 |
GASKET-COLLECTOR Price: $9.66 |
| 11 |
127-3037 |
GASKET-THROTTLE Price: $2.87 |
| 11 |
581116302 |
BLADE.2 IN 1.38"DECK.BLACK This part replaces 532193957. Price: $14.99 |
| 12 |
127-3108 |
GASKET-MANIFOLD, EXHAUST Price: $14.96 |
| 13 |
121-3058 |
GASKET-EXHAUST This part replaces 127-3019. Price: $19.54 |
| 13 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192872. Price: $49.99 |
| 14 |
127-2987 |
GASKET-SILENCER Price: $13.97 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 15 |
127-3043 |
GASKET-COOLER, E G R Price: $3.64 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
127-3046 |
GASKET-E G R Price: $4.88 |
| 17 |
127-3016 |
GASKET Price: $3.83 |
| 18 |
127-3050 |
GASKET-INTAKE VALVE, E G R Price: $5.09 |
| 19 |
127-3051 |
GASKET-OUT VALVE, E G R Price: $4.47 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 20 |
127-3162 |
GASKET-D P F Price: $19.60 |
| 21 |
127-3056 |
GASKET-SENSOR Price: $2.23 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
125-7070 |
GASKET Price: $4.75 |
| 23 |
125-7071 |
GASKET Price: $7.59 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 24 |
127-3069 |
GASKET-IDLE, SHAFT B Price: $4.14 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
127-3004 |
GASKET Price: $2.73 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 26 |
125-6909 |
O-RING Price: $2.55 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
127-2973 |
O-RING Price: $3.16 |
| 27 |
597316601 |
Shields This part replaces 532401618. Price: $44.99 |
| 28 |
125-7022 |
GASKET Price: $7.07 |
| 29 |
125-7024 |
GASKET Price: $3.16 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
125-7047 |
GASKET Price: $5.13 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
125-7048 |
O-RING Price: $2.87 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
125-6979 |
GASKET Price: $2.55 |
| 32 |
531170001 |
SERVICE KIT PULLEY PULLEY.MAND This part replaces 532199789. Price: $17.99 |
| 33 |
125-7110 |
GASKET Price: $3.76 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
125-7026 |
GASKET Price: $2.90 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 35 |
125-6978 |
GASKET Price: $2.00 |
| 36 |
127-3074 |
O-RING Price: $29.78 |
| 37 |
125-7174 |
WASHER-SEAL Price: $5.45 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 38 |
125-7175 |
WASHER-SEAL Price: $6.16 |
| 38 |
532400140 |
BELT KEEPER.MANDREL.38"COATED This part replaces 532199541. Price: $39.99 |
| 39 |
125-7176 |
WASHER-SEAL Price: $7.31 |
| 40 |
127-3166 |
WASHER-SEAL Price: $6.77 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 41 |
125-7177 |
WASHER-SEAL Price: $6.86 |
| 42 |
125-7192 |
GASKET Price: $1.14 |
| 42 |
532198410 |
SPRING.TORSION.BRAKE Price: $4.99 |
| 43 |
125-7193 |
GASKET Price: $1.28 |
| 43 |
532197256 |
SRPING.TORSION.RETAINE Price: $4.99 |
| 44 |
127-3174 |
GASKET Price: $1.28 |
| 45 |
93-0418 |
O-RING Price: $7.29 |
| 46 |
125-7197 |
O-RING Price: $2.55 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
125-7198 |
O-RING Price: $7.26 |
| 48 |
127-3176 |
O-RING Price: $2.87 |
| 49 |
127-3000 |
HONE Price: $654.34 |
| 55 |
531169401 |
SERVICE KIT IDLER.ARM This part replaces 532197249. Price: $5.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 60 |
532199471 |
ARM BRAKE MOWER RH 38" Price: $14.99 |
| 62 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 63 |
532400130 |
BRAKE.ARM.LH.38"TEX.COATED This part replaces 532199470. Price: $14.99 |
| 64 |
532199918 |
LINKAGE.BRAKE.ASM.ZINC This part replaces 532199790. Price: $11.99 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $6.99 |
| 68 |
532408381 |
V-BELT Price: $37.99 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 70 |
532401246 |
CLUTCH.ASM.MANUAL.LT.PRED Price: $32.99 |
| 86 |
532406563 |
CLUTCH.ASM.CABLE.HUSQ.TEX This part replaces 532197798. Price: $71.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $14.99 |
| 115 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 122 |
531169501 |
SERVICE KIT BELT KEEPER This part replaces 532197258. Price: $4.99 |
| 123 |
531169701 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532197259. Price: $6.99 |
| 144 |
597024901 |
Keepers This part replaces 532156085. Price: $3.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 147 |
532401872 |
SPRING RETURN Price: $4.99 |
| 151 |
532401246 |
CLUTCH.ASM.MANUAL.LT.PRED This part replaces 532401244. Price: $32.99 |
| 152 |
532435111 |
CABLE.CLUTCH.MANUAL. This part replaces 532408714. Price: $29.99 |
| 186 |
532406563 |
CLUTCH.ASM.CABLE.HUSQ.TEX This part replaces 532197799. Price: $71.99 |
| 187 |
532401246 |
CLUTCH.ASM.MANUAL.LT.PRED This part replaces 532401245. Price: $32.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 194 |
532406563 |
CLUTCH.ASM.CABLE.HUSQ.TEX This part replaces 532197797. Price: $71.99 |
| 195 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 197 |
532406563 |
CLUTCH.ASM.CABLE.HUSQ.TEX This part replaces 532197801. Price: $71.99 |
| 199 |
531170401 |
SERVICE KIT BAFFLE BAFFLE.VORT This part replaces 532400095. Price: $14.99 |
| 205 |
817640416 |
This part replaces 817490416. Price: $1.92 |
| 206 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 210 |
532409256 |
NEEDS DESCRIPTION Price: Call Us |
| 211 |
532409257 |
NEEDS DESCRIPTION Price: Call Us |
