| Ref | Part Number | Description |
|---|
| 1 |
111-4779-01 |
ARM-LIFT, LH Price: Call Us |
| 1 |
823230506 |
Screw, Set, Forged Socket, Headless 5/16-18 x 3/8 (AYP part number) Price: $2.99 |
| 2 |
532130811 |
Pulley, Engine Price: $3.33 |
| 3 |
532122955 |
Bracket Assembly, Guard, Belt (AYP part number) Price: $3.33 |
| 4 |
119-2200 |
PAD-RUBBER, REAR HOC Price: $10.33 |
| 4 |
872140404 |
Bolt, Carriage 1/4-20 x 1/2 (AYP part number) Price: $3.99 |
| 5 |
119-2230 |
PAD-PLASTIC, REAR HOC Price: $7.14 |
| 5 |
874770812 |
Bolt, Hex 1/2-20 x 3/4 (AYP part number) Price: Call Us |
| 6 |
110-0606 |
RIVET-BLIND Price: $1.15 |
| 6 |
532121463 |
Keeper, Belt, Transmission Pulley (AYP part number) Price: $3.33 |
| 7 |
105-7441 |
BEARING-SPHERICAL Price: $56.85 |
| 7 |
583644101 |
NUT-CAP TI This part replaces 532104213. Price: $3.99 |
| 8 |
32151-34 |
RING-RETAINING Price: $0.67 |
| 8 |
819091016 |
Washer 9/32 x 5/8 x 16 Ga. (AYP part number) Price: $2.99 |
| 9 |
3269-26 |
WASHER-PLAIN Price: $0.99 |
| 9 |
532125342 |
Guard, Belt (AYP part number) Price: $3.33 |
| 10 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 10 |
532109227 |
Pad, Idler (AYP part number) Price: $2.99 |
| 11 |
872110407 |
BOLT.CARRIAGE.1/4-20 X 7/8 This part replaces 872140406. Price: $2.99 |
| 12 |
532009179 |
V-Belt (AYP part number) Price: $3.33 |
| 13 |
532002649 |
Key, Square (AYP part number) Price: $2.99 |
| 14 |
532009174 |
Pulley, Transmission (AYP part number) Price: $3.33 |
| 15 |
532132213 |
Bolt, Belt Guard Price: $3.33 |
| 16 |
812000036 |
Ring, Klip (AYP part number) Price: $3.99 |
| 17 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 18 |
532009178 |
Pulley, Idler (AYP part number) Price: $14.99 |
| 19 |
532124688 |
Idler Arm Assembly (AYP part number) Price: $29.99 |
| 20 |
874760620 |
Bolt, Hex 3/8-16 x 1-1/4 (AYP part number) Price: $3.99 |
| 21 |
532106968 |
Shaft, Idler Arm (AYP part number) Price: $11.99 |
| 22 |
532105358 |
Shield, Dirt (AYP part number) Price: $3.33 |
| 23 |
810040400 |
Washer, Lock 1/4 (AYP part number) Price: $3.99 |
| 24 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $3.99 |
