| Ref | Part Number | Description |
|---|
| 1 |
27-6860 |
DISCONTINUED Price: Call Us |
| 2 |
99-6969 |
SEAL-OIL, WHEEL END This part replaces 21-8330. Price: $14.71 |
| 3 |
21-8180 |
BEARING ASM Price: $65.11 |
| 4 |
21-9450 |
SHIELD-DUST Price: $45.14 |
| 5 |
43-6810 |
SPIDER-TORQUE This part replaces 40-2190. Price: $138.50 |
| 6 |
21-9390 |
SOCKET-SCREW, ADJUSTING Price: $5.56 |
| 7 |
21-9370 |
SCREW-ADJUSTING Price: $18.80 |
| 8 |
21-9380 |
NUT-PIVOT Price: $26.77 |
| 9 |
242-34 |
STUD-DRIVE Price: $11.61 |
| 10 |
21-8360 |
CLIP-RETAINING Price: $1.29 |
| 11 |
28-0680-03 |
DRUM-BRAKE This part replaces 28-0680. Price: $358.84 |
| 12 |
99-5694 |
NUT W/WASHER This part replaces 43-6800. Price: $3.86 |
| 13 |
28-0670 |
SEAL-GREASE Price: $19.74 |
| 14 |
21-9440 |
SPRING-SCREW, ADJUSTING Price: $11.92 |
| 15 |
21-9460 |
RETAINER-LEVER, BRAKE Price: $2.18 |
| 16 |
43-2690 |
SEE PB #747 Price: Call Us |
| 17 |
21-9420 |
SPRING-RETURN, LH Price: $19.96 |
| 18 |
21-9430 |
SPRING-RETURN, RH Price: $19.96 |
| 19 |
27-6880 |
BRAKE LEVER ASSY Price: $85.13 |
| 20 |
21-8320 |
REFER TO(PB#807 OR MISC COMM SB#50) Price: Call Us |
| 21 |
99-5691 |
SCREW W/WASHER This part replaces 28-0660. Price: $7.18 |
| 22 |
24-8840 |
RING-RETAINING, WHEEL BEARING Price: $37.15 |
| 503210625 |
503214925 |
SCREW This part replaces 503210625. Price: $3.99 |
| 503842201 |
503842201 |
FAN MOUNT Price: $30.36 |
| 530001733 |
530001733 |
NUT Price: $4.75 |
| 530015647 |
530015647 |
PIN-PIVOT Price: $1.67 |
| 530015667 |
530015667 |
SPRING-TORSION (RIGHT) Price: $1.41 |
| 530015672 |
530015672 |
SPRING-TORSION (LEFT) Price: $2.99 |
| 530015814 |
530015814 |
SCREW Price: $0.17 |
| 530019167 |
530019167 |
O-RING SEAL Price: $2.99 |
| 530029118 |
530047077 |
ASSY-IMPELLER This part replaces 530029118. Price: $7.70 |
| 530029173 |
530029173 |
BAND-BLOWER HSG Price: $2.25 |
| 530049445 |
530049445 |
UPPER HOUSING Price: $4.99 |
| 530049446 |
530047736 |
BLOWER HOUSING ASSY - BLACK This part replaces 530049446. Price: $17.99 |
| 530049447 |
530049447 |
INLET DOOR Price: $6.67 |
| 530049448 |
530049448 |
BLOWER TUBE Price: $7.99 |
| 530069961 |
530069961 |
KIT TUBE & NOZZLE Price: $8.99 |
| 530095355 |
530095355 |
MULCH BLADE Price: $4.99 |
| 530095356 |
530047702 |
IMPELLAR ASSY This part replaces 530095356. Price: $11.99 |
| 531030377 |
531030377 |
SPACER Price: $1.67 |
| 738220119 |
503252301 |
BALL BEARING This part replaces 738220119. Price: $11.99 |
