| Ref | Part Number | Description |
|---|
| 1 |
323-7 |
SCREW-HH Price: $0.65 |
| 1 |
395990 |
CYLINDER ASSEMBLY Price: Call Us |
| 2 |
297565 |
BUSHING, CYLINDER Price: Call Us |
| 2 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 3 |
299819 |
SEAL, OIL Price: Call Us |
| 3 |
32146-20 |
NUT-HEX Price: $3.23 |
| 4 |
99-6940-03 |
AXLE SUPPORT ASM Price: $974.39 |
| 5 |
214040 |
HEAD, CYLINDER Price: Call Us |
| 5 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 6 |
237-165 |
GROMMET Price: $15.70 |
| 7 |
272157 |
GASKET, CYLINDER HEAD Price: Call Us |
| 8 |
32121-32 |
PIN-ROLL Price: $1.34 |
| 8 |
495774 |
BREATHER ASSEMBLY Price: Call Us |
| 9 |
140-6101 |
PIN ASM-AXLE PIVOT This part replaces 98-8173. Price: $42.42 |
| 9 |
27549 |
GASKET, VALVE COVER Price: Call Us |
| 10 |
71-4540 |
WASHER-THRUST Price: $1.97 |
| 10 |
94621 |
SCREW, STEMS Price: Call Us |
| 11 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 11 |
66578 |
GROMMET, BREATHER TUBE Price: Call Us |
| 12 |
270080 |
GASKET CRANKCASE STANDARD .015" Price: Call Us |
| 12 |
99-8431 |
WASHER-THRUST Price: $4.63 |
| 13 |
94221 |
SCREW, CYLINDER HEAD 2-3/32" Price: Call Us |
| 13 |
99-8432 |
WASHER-THRUST Price: $4.21 |
| 14 |
94679 |
SCREW, CYLINDER HEAD 2-15/32" Price: Call Us |
| 15 |
93448 |
PLUG, PIPE, HEX SOCKET Price: Call Us |
| 16 |
492088 |
CRANKSHAFT Price: Call Us |
| 18 |
297602 |
COVER ASSEMBLY, CRANKCASE Price: Call Us |
| 19 |
495660 |
BUSHING, CRANKCASE COVER Price: Call Us |
| 20 |
294606 |
SEAL, OIL Price: Call Us |
| 21 |
66768 |
PLUG, OIL FILLER Price: Call Us |
| 22 |
94682 |
SCREW Price: Call Us |
| 23 |
297229 |
FLYWHEEL, MAGNETO Price: Call Us |
| 24 |
222698 |
KEY, FLYWHEEL Price: Call Us |
| 25 |
298904 |
PISTON ASSEMBLY, STANDARD Price: Call Us |
| 26 |
298982 |
RING SET, PISTON, STANDARD Price: Call Us |
| 27 |
26026 |
LOCK, PISTON PIN Price: Call Us |
| 28 |
298909 |
PIN ASSY, PISTON, STD Price: Call Us |
| 29 |
299430 |
ROD ASSEMBLY, CONNECTING Price: Call Us |
| 30 |
221890 |
DIPPER, CONNECTING ROD Price: Call Us |
| 32 |
94745 |
SCREW, CONNECTING ROD Price: Call Us |
| 33 |
211119 |
VALVE, EXHAUST Price: Call Us |
| 34 |
261044 |
VALVE, INTAKE Price: Call Us |
| 35 |
260552 |
SPRING, INTAKE VALVE Price: Call Us |
| 36 |
26478 |
SPRING, EXHAUST VALVE Price: Call Us |
| 37 |
222443 |
GUARD, FLYWHEEL Price: Call Us |
| 40 |
93312 |
RETAINER, VALVE SPRING Price: Call Us |
| 45 |
260642 |
TAPPET, VALVE Price: Call Us |
| 46 |
212733 |
GEAR, CAM Price: Call Us |
| 52 |
271936 |
GASKET, INTAKE ELBOW MOUNTING Price: Call Us |
| 55 |
494846 |
HOUSING, REWIND STARTER Price: Call Us |
| 56 |
493824 |
PULLEY, REWIND STARTER Price: Call Us |
| 57 |
262594 |
SPRING, REWIND STARTER Price: Call Us |
| 58 |
280406 |
ROPE, REWIND STARTER Price: Call Us |
| 59 |
396892 |
INSERT, HANDLE Price: Call Us |
| 60 |
393152 |
HANDLE, REWIND STARTER Price: Call Us |
| 65 |
94686 |
SCREW, HOUSING MOUNTING Price: Call Us |
| 69 |
280973 |
WASHER Price: Call Us |
| 69A |
224322 |
WASHER Price: Call Us |
| 73 |
224632 |
SCREEN, ROTATING Price: Call Us |
| 81 |
222263 |
LOCK, SCREW Price: Call Us |
| 90 |
495426 |
CARBURETOR ASSEMBLY Price: Call Us |
| 95 |
93499 |
SCREW Price: Call Us |
| 96 |
223793 |
THROTTLE, CARBURETOR Price: Call Us |
| 97 |
490048 |
SHAFT AND LEVER THROTTLE Price: Call Us |
| 108 |
491177 |
VALVE AND SHAFT GROUP, CHOKE Price: Call Us |
| 118 |
231533 |
VALVE, NEEDLE Price: Call Us |
| 121 |
495606 |
CARBURETOR OVERHAUL KIT Price: Call Us |
| 124 |
94616 |
SCREW, ELBOW MOUNTING Price: Call Us |
| 127 |
220352 |
PLUG, WELCH Price: Call Us |
| 127A |
223789 |
PLUG, WELCH Price: Call Us |
| 149 |
26336 |
SPRING, NEEDLE VALVE Price: Call Us |
| 152 |
260575 |
SPRING, THROTTLE ADJUSTMENT Price: Call Us |
| 153 |
490589 |
SCREW AND COLLAR Price: Call Us |
| 154 |
93527 |
SCREW, MACHINE, ROUND HEAD Price: Call Us |
| 163 |
271935 |
GASKET, AIR CLEANER MOUNTING Price: Call Us |
| 180 |
495405 |
TANK ASSEMBLY, FUEL Price: Call Us |
| 181 |
494559 |
CAP, FUEL TANK Price: Call Us |
| 190 |
94712 |
SCREW, FUEL TANK Price: Call Us |
| 190A |
94677 |
SCREW, FUEL TANK MOUNTING1-3/4" Price: Call Us |
| 191 |
272489 |
GASKET, FUEL TANK TO CARBURETOR Price: Call Us |
| 200 |
223886 |
GUIDE, AIR Price: Call Us |
| 202 |
262270 |
LINK, THROTTLE Price: Call Us |
| 203 |
280720 |
BELL CRANK Price: Call Us |
| 204 |
222962 |
BUSHING, GOVERNOR LEVER, FLAT Price: Call Us |
| 205 |
231520 |
SCREW, SHOULDER Price: Call Us |
| 208 |
262279 |
ROD, SPEED CONTROL Price: Call Us |
| 209 |
262283 |
SPRING, GOVERNOR Price: Call Us |
| 216 |
262359 |
LINK, CHOKE Price: Call Us |
| 219 |
494845 |
GEAR, GOVERNOR Price: Call Us |
| 220 |
221551 |
WASHER THRUST Price: Call Us |
| 222 |
490649 |
PANEL, CONTROL Price: Call Us |
| 223 |
223455 |
LEVER, GOVERNOR CONTROL Price: Call Us |
| 224 |
93491 |
RIVET, GOVERNOR CONTROL LEVER MOUNTING Price: Call Us |
| 227 |
490374 |
LEVER ASSEMBLY, GOVERNOR Price: Call Us |
| 230 |
222450 |
WASHER, GOVERNOR LEVER Price: Call Us |
| 256 |
223813 |
CRANK, BELL Price: Call Us |
| 257 |
93543 |
SCREW, SEMS, HEX HEAD Price: Call Us |
| 300 |
393615 |
MUFFLER, EXHAUST Price: Call Us |
| 304 |
495759 |
HOUSING, BLOWER Price: Call Us |
| 306 |
221511 |
SHIELD, CYLINDER Price: Call Us |
| 307 |
94680 |
SCREW, CYLINDER SHIELD Price: Call Us |
| 308 |
224738 |
COVER, CYLINDER HEAD Price: Call Us |
| 332 |
92284 |
NUT, FLYWHEEL Price: Call Us |
| 333 |
397358 |
ARMATURE GROUP Price: Call Us |
| 334 |
93414 |
SCREW, ARMATURE MOUNTING Price: Call Us |
| 337 |
802592 |
PLUG, SPARK Price: Call Us |
| 346 |
93705 |
SUB= 69485 Price: Call Us |
| 356 |
398808 |
WIRE, GROUND Price: Call Us |
| 363 |
19069 |
PULLEY, FLYWHEEL Price: Call Us |
| 373 |
92987 |
NUT, HEX Price: Call Us |
| 383 |
89838 |
WRENCH SPARK PLUG Price: Call Us |
| 392 |
262328 |
SPRING, FUEL PUMP DIAPHRAGM Price: Call Us |
| 394 |
272538 |
DIAPHRAGM Price: Call Us |
| 414 |
220982 |
WASHER Price: Call Us |
| 432 |
221377 |
CAP, SPRING Price: Call Us |
| 433 |
93265 |
PIN, DIAPHRAGM COVER Price: Call Us |
| 434 |
214021 |
COVER, DIAPHRAGM Price: Call Us |
| 435 |
93141 |
SCREW, DIAPHRAGM Price: Call Us |
| 455 |
224250 |
CUP, STARTER Price: Call Us |
| 456 |
224321 |
RETAINER, REWIND STARTER Price: Call Us |
| 459 |
492833 |
PAWL, STARTER Price: Call Us |
| 461 |
262626 |
PIN, STARTER Price: Call Us |
| 467 |
280715 |
KNOB, CONTROL Price: Call Us |
| 515 |
262625 |
SPRING, TORSION Price: Call Us |
| 526 |
94659 |
SCREW,SEMS,TANK BRACKET MOUNT Price: Call Us |
| 527 |
223786 |
CLAMP BREATHER TUBE Price: Call Us |
| 528 |
231550 |
TUBE, BREATHER Price: Call Us |
| 529 |
67838 |
GROMMET, BREATHER TUBE Price: Call Us |
| 542 |
93572 |
SCREW Price: Call Us |
| 552 |
231079 |
BUSHING, GOVERNOR CRANK Price: Call Us |
| 562 |
92613 |
BOLT, GOVERNOR LEVER Price: Call Us |
| 592 |
231082 |
NUT, HEX Price: Call Us |
| 608 |
495766 |
STARTER ASSEMBLY, REWIND Price: Call Us |
| 611 |
391813 |
FUEL PIPE AND CLIP ASSEMBLY Price: Call Us |
| 613 |
93935 |
SCREW, HEX HEAD Price: Call Us |
| 614 |
93306 |
COTTER, HAIR PIN Price: Call Us |
| 615 |
93307 |
RETAINER, E-RING Price: Call Us |
| 616 |
231077 |
CRANK, GOVERNOR Price: Call Us |
| 621 |
396847 |
SWITCH, STOP Price: Call Us |
| 634 |
271853 |
WASHER, THROTTLE SHAFT, FOAM Price: Call Us |
| 635 |
66538 |
ELBOW, SPARK PLUG Price: Call Us |
| 676 |
393757 |
DEFLECTOR, EXHAUST, SIDE OUTLET Price: Call Us |
| 679 |
270382 |
WASHER, FOAM Price: Call Us |
| 680 |
221839 |
WASHER, BRASS Price: Call Us |
| 741 |
261696 |
GEAR, TIMING Price: Call Us |
| 779 |
262570 |
LINK, SPEED CONTROL Price: Call Us |
| 851 |
221798 |
TERMINAL, IGNITION CABLE Price: Call Us |
| 869 |
211787 |
SEAT, INTAKE VALVE, STANDARD Price: Call Us |
| 870 |
211172 |
SEAT, INTAKE VALVE, STANDARD Price: Call Us |
| 871 |
262001 |
GUIDE, EXHAUST VALVE Price: Call Us |
| 916 |
280321 |
RACK, GEAR CONTROL Price: Call Us |
| 966 |
492797 |
BASE, AIR CLEANER Price: Call Us |
| 967 |
491588 |
SUB= 3364 Price: Call Us |
| 968 |
495357 |
COVER, AIR CLEANER Price: Call Us |
| 969 |
490073 |
SCREW, COVER MOUNTING Price: Call Us |
| 971 |
94018 |
SCREW, AIR CLEANER Price: Call Us |
| 987 |
398970 |
SEAL, THROTTLE SHAFT Price: Call Us |
| 995 |
223887 |
BRACKET, CONTROL LINK Price: Call Us |
| 1012 |
490507 |
RETAINER, LINK Price: Call Us |
| 63709 |
GUIDE, |
INTAKE VALVE Price: Call Us 63709 |
| 94387 |
PLUG |
OIL DRAIN Price: Call Us 94387 |
| 230978 |
CRANKSHAFT |
GEAR PIN Price: Call Us 230978 |
| 270125 |
GASKET, |
CRANKCASE .005" THICK Price: Call Us 270125 |
| 270126 |
GASKET, |
CRANKCASE .009" THICK Price: Call Us 270126 |
| 298905 |
PISTON |
ASSEMBLY .010" OVERSIZE Price: Call Us 298905 |
| 298906 |
PISTON |
ASSEMBLY .020" OVERSIZE Price: Call Us 298906 |
| 298907 |
PISTON |
ASSEMBLY .030" OVERSIZE Price: Call Us 298907 |
| 298908 |
PIN |
ASSEMBLY, PISTON .005" OVERSIZE Price: Call Us 298908 |
| 298983 |
RING |
SET, PISTON .010" OVERSIZE Price: Call Us 298983 |
| 298984 |
RING |
SET, PISTON .020" OVERSIZE Price: Call Us 298984 |
| 298985 |
RING |
SET, PISTON .030" OVERSIZE Price: Call Us 298985 |
| 299742 |
RING |
SET, PISTON, CHROME, STANDARD Price: Call Us 299742 |
| 390459 |
ROD |
ASSEMBLY, CONNECTING Price: Call Us 390459 |
