| Ref | Part Number | Description |
|---|
| 1 |
140310 |
CONTROL THROTTLE Price: Call Us |
| 1 |
710-04744 |
Screw, #12-16 X 1.00" Price: $4.47 |
| 2 |
17720410 |
SCREW LT Price: Call Us |
| 2 |
92-9725-03 |
LH SPINDLE ASM Price: $553.13 |
| 3 |
287707 |
ENGINE B&S Price: Call Us |
| 3 |
92-9724-03 |
RH SPINDLE ASM Price: $644.87 |
| 3 |
951-12683 |
Recoil Starter Assembly Price: $80.84 |
| 4 |
137352 |
MUFFLER Price: Call Us |
| 4 |
3220-7 |
NUT-JAM Price: $4.09 |
| 5 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 6 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 6 |
712-05015 |
Nut M6 This part replaces 712-04212. Price: $5.78 |
| 7 |
254-106 |
CONE-BEARING, TAPERED Price: $19.51 |
| 8 |
254-92 |
CONE-BEARING, OUTER Price: $15.84 |
| 8 |
951-11721 |
Recoil Spring and Pulley Ass'y Price: $43.48 |
| 9 |
114-3908 |
HUB ASM This part replaces 92-9651. Price: $129.48 |
| 10 |
69-2980 |
SEAL Price: $33.94 |
| 11 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 12 |
98-8839 |
DISCONTINUED Price: Call Us |
| 13 |
272293 |
GASKET ENG 1 313 LD TIN PLATED Price: Call Us |
| 13 |
93-0309 |
WASHER-TAB Price: $3.52 |
| 14 |
13280324 |
PIPE NIPPLE Price: Call Us |
| 14 |
93-0307 |
NUT-LOCK, RETAINER Price: $3.36 |
| 15 |
100-3769 |
PROTECTOR-BEARING Price: $41.94 |
| 15 |
13200300 |
ELBOW Price: Call Us |
| 15 |
751-11722 |
Stud Left/Black Price: $3.68 |
| 16 |
11050600 |
LOCKWASHER Price: Call Us |
| 16 |
951-11723 |
Stud Front/Unmarked Price: $3.77 |
| 17 |
951-11724 |
Stud Right/White Price: $3.77 |
| 18 |
951-10875 |
Inner Shroud Not Available Price: |
| 19 |
750-05320 |
Engine Shroud Spacer Price: $3.56 |
| 20 |
712-04287A |
FLYWHEEL NUT M14-1.5 This part replaces 712-04287. Price: $5.33 |
| 23 |
156123 |
SHIELD-HEAT Price: Call Us |
| 29 |
137180 |
SUB= 532137180 Price: Call Us |
| 31 |
109202X |
TANK.FUEL.LT. Price: Call Us |
| 32 |
140527 |
CAP ASM FUEL Price: Call Us |
| 33 |
123487X |
HOSE CLAMP Price: Call Us |
| 35 |
17490512 |
SCREW Price: Call Us |
| 37 |
137040 |
LINE FUEL Price: Call Us |
| 40 |
124028X |
SUB= 532124028 Price: Call Us |
| 44 |
17490412 |
SCREW HEX CRT Price: Call Us |
| 46 |
19091416 |
WASHER Price: Call Us |
| 62 |
10040500 |
LOCKWASHER Price: Call Us |
| 72 |
71070512 |
SCREW Price: Call Us |
| 78 |
17490620 |
SCREW Price: Call Us |
