| Ref | Part Number | Description |
|---|
| 8 |
710-0376 |
Hex Screw, 5/16-18 x 1.00 This part replaces 1100045. Price: $3.66 |
| 9 |
712-04054 |
NUT-HFLK 5/16-18 ZP This part replaces 1186391. Price: $3.95 |
| 10 |
1100044 |
Hex Head Screw, 5/16-18 x 3/4 Price: $3.76 |
| 13 |
712-3000 |
Hex Lock Nut, 3/8-16 This part replaces 1733398. Price: $3.90 |
| 14 |
736-0275 |
FLAT WASHER This part replaces 1107382. Price: $5.99 |
| 26 |
736-0159 |
Washer This part replaces 1100254. Price: $3.71 |
| 33 |
1766984 |
SCREW-FLANGE LOCK Not Available Price: |
| 40 |
1766241 |
SPECIAL WASHER Not Available Price: |
| 53 |
1772776 |
BRACKET-STOP Not Available Price: |
| 81 |
710-3144 |
Hex Cap Screw, 3/8-16 x 2.00 This part replaces 1100048. Price: $4.02 |
| 83 |
710-0347 |
Hex Cap Screw 3/8-16 x 1.75 This part replaces 1100086. Price: $4.39 |
| 84 |
936-0329 |
Lock Washer This part replaces 1100241. Price: $3.90 |
| 85 |
736-3050 |
Washer, Plain (flat) 3/8, S.A.E. This part replaces 1107383. Price: $3.90 |
| 86 |
914-0507 |
Cotter Pin, 3/32 x .75 This part replaces 1100346. Price: $3.93 |
| 87 |
710-0176 |
Hex Bolt 5/16-18 x 2.75 This part replaces 1111609. Price: $3.89 |
| 88 |
710-0260A |
Carriage Bolt, 5/16-18 x .62 This part replaces 1186097. Price: $3.71 |
| 90 |
1715538 |
BUSHING-NYLINER .5X.5 Not Available Price: |
| 91 |
1732499 |
Locknut, 5/16-18 Price: $3.49 |
| 92 |
1770205 |
PIN-DRIVE Not Available Price: |
| 95 |
1756151 |
BACKSIDE PULLEY IDLER Not Available Price: |
| 96 |
1760096 |
BELT GUIDE Not Available Price: |
| 97 |
1760097 |
IDLER PULLEY Not Available Price: |
| 98 |
1769038 |
EYE-BOLT/ Not Available Price: |
| 99 |
1772460 |
CLUTCH ROD Not Available Price: |
| 100 |
1771514 |
LATCH-BRAK Not Available Price: |
| 101 |
1765156 |
CLIP Not Available Price: |
| 102 |
1765167 |
PAD-BRAKE Not Available Price: |
| 103 |
1772741 |
BRAKE PEDAL Not Available Price: |
| 104 |
1765257 |
BRACKET-BRAKE LOCK Not Available Price: |
| 105 |
1765297 |
PAD-PARKN Not Available Price: |
| 106 |
1765305 |
COMPRESSION SPRING Not Available Price: |
| 107 |
1985140 |
EXTENSION SPRING Not Available Price: |
| 108 |
1765402 |
Extension Spring Price: $29.34 |
| 109 |
1765461 |
PIVOT ROD Not Available Price: |
| 110 |
1766215 |
HUB CAP Not Available Price: |
| 113 |
1118808 |
RETAINING RING Not Available Price: |
| 117 |
1755319 |
COMPRESSION SPRING Not Available Price: |
| 118 |
1185802 |
BEARING-FL Not Available Price: |
| 122 |
1186393 |
Flange Nut, 3/8-16 Price: $2.63 |
| 134 |
1765064 |
ARM ASSEMBLY - IDLER Not Available Price: |
| 137 |
603-0644 |
No Longer Available Not Available Price: |
| 139 |
736-0140 |
Flat Washer, .385 x .62 x .063 This part replaces 1890945. Price: $6.20 |
| 142 |
1772191 |
BELT GUIDE Not Available Price: |
| 144 |
1720928 |
EXTENSION SPRING Not Available Price: |
| 150 |
1772208 |
BRAKE ROD Not Available Price: |
| 154 |
1766025 |
KEEPER-CLU Not Available Price: |
| 160 |
1772330 |
SHEAVE-ENG Not Available Price: |
| 161 |
1772844 |
FOOT PAD P Not Available Price: |
| 163 |
712-3017 |
HEX NUT 3/8-16 GR5 This part replaces 1186231. Price: $3.90 |
| 164 |
1767900 |
BELT GUIDE Not Available Price: |
| 167 |
736-0169 |
L-Wash. 3/8" I.D." This part replaces 1100243. Price: $3.33 |
| 171 |
1983110 |
KEY 3/16X3 Not Available Price: |
| 175 |
716-0231 |
E-ring..75 This part replaces 1185388. Price: $3.50 |
| 176 |
1747998 |
FLAT WASHER Not Available Price: |
| 178 |
1724885 |
ROLL PIN Not Available Price: |
| 183 |
1772222 |
ROD-HYDRO Not Available Price: |
| 187 |
1772728 |
BRAKE PEDAL ASSEMBLY Not Available Price: |
| 200 |
710-1260A |
SCREW 5/16-18 x .750 This part replaces 1724491. Price: $3.34 |
| 203 |
1773156 |
BELT GUIDE Not Available Price: |
| 221 |
1772207 |
SUPPORT-TRANSMISSI Not Available Price: |
| 222 |
1772253 |
V-Belt Price: $81.74 |
| 226 |
1773624 |
BELT GUIDE Not Available Price: |
| 233 |
710-04049 |
Flange Screw, 5/16-18,.625, Gr5 This part replaces 1186328. Price: $4.11 |
| 309 |
1747738 |
CLIP-J Not Available Price: |
| 310 |
1185715 |
WASHER-LK Not Available Price: |
| 359 |
710-3001 |
Hex Screw, 3/8-16, .880, Gr5, Std This part replaces 1100913. Price: $6.20 |
| 389 |
1730375 |
FLAT WASHER Not Available Price: |
| 390 |
936-0117 |
FLAT WASHER This part replaces 1705108. Price: $6.20 |
| 395 |
1772208 |
BRAKE ROD Not Available Price: |
| 396 |
1772223 |
CONTROL ARM Not Available Price: |
| 400 |
738-0322A |
Shoulder Screw, .625 x .217 This part replaces 7380322. Price: $5.94 |
| 401 |
936-0349 |
FLAT WASHER This part replaces 7360349. Price: $3.86 |
| 402 |
936-0349 |
FLAT WASHER This part replaces 7360349. Price: $3.86 |
| 403 |
741-0495 |
NYLINER BEARING Price: $4.02 |
| 404 |
603-0641 |
No Longer Available Not Available Price: |
| 405 |
932-0395 |
EXTENSION SPRING Not Available This part replaces 7320395. Price: |
| 406 |
1120210 |
DRIVE PIN, 3/16 x 1 Not Available Price: |
| 407 |
603-0637 |
Assm Not Available Price: |
| 518 |
1766275 |
TIRE-20 X Not Available Price: |
| 519 |
1765607 |
RIM Not Available Price: |
