| Ref | Part Number | Description |
|---|
| 1 |
579841401 |
KITS.CHASSIS.STAMPED.SERVICE This part replaces 532174619. Price: $379.99 |
| 1 |
99-8346 |
GASKET Price: $1.43 |
| 2 |
532176554 |
DRAWBAR, 12GA Price: $37.99 |
| 2 |
98-9417 |
BOLT-JOINT, EYE Price: $12.10 |
| 3 |
115-4126 |
BOLT-JOINT, EYE This part replaces 98-9418. Price: $12.34 |
| 3 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 4 |
98-9419 |
OIL PIPE ASM Price: $64.29 |
| 5 |
108-4422 |
GASKET This part replaces 98-9435. Price: $1.48 |
| 5 |
532155272 |
BUMPER.RUBBER.HOOD Price: $3.99 |
| 6 |
138-1238 |
KIT-PIPE, OIL This part replaces 98-9461. Price: $212.76 |
| 7 |
98-7568 |
BOLT This part replaces 98-9587. Price: $0.84 |
| 8 |
98-9591 |
PIN-BAND Price: $6.96 |
| 9 |
532168336 |
DASH This part replaces 532171853. Price: $33.08 |
| 9 |
98-9601 |
CLAMP-PIPE Price: $6.61 |
| 10 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 10 |
98-9714 |
CLAMP-HOSE Price: $2.66 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX Price: $9.99 |
| 11 |
98-9721 |
PIPE-OIL Price: $14.77 |
| 12 |
532145660 |
CLIP Price: $2.99 |
| 12 |
98-9723 |
HOLDER ASM Price: $154.38 |
| 13 |
532181719 |
PANEL DASH RH Price: $8.99 |
| 13 |
98-9724 |
PIPE-COOLER, OIL Price: $31.43 |
| 14 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 14 |
98-9578 |
PIPE-RETURN, WATER This part replaces 98-9725. Price: $11.28 |
| 15 |
98-9579 |
BAND-PIPE This part replaces 98-9726. Price: $5.22 |
| 16 |
98-9727 |
COLLAR Price: $9.86 |
| 17 |
104-5157 |
OIL COOLER SERVICE KIT This part replaces 98-9728. Price: $1,236.62 |
| 17 |
532159639 |
HOOD.STEEL.LT.ORANGE This part replaces 532162237. Price: $64.99 |
| 18 |
532126938 |
BUMPER HOOD T Price: $3.99 |
| 18 |
98-9729 |
O-RING Price: $6.27 |
| 19 |
99-8383 |
OIL PIPE ASM Price: $63.74 |
| 20 |
108-3841 |
FILTER-OIL This part replaces 98-9651. Price: $10.81 |
| 24 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 25 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 26 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 28 |
532179100 |
GRILL ASSEMBLY Price: $169.99 |
| 29 |
532140273 |
LENS This part replaces 532168154. Price: $16.99 |
| 30 |
532175274 |
FENDER This part replaces 532176953. Price: $107.99 |
| 31 |
532136619 |
BRACKET FENDER Price: $4.99 |
| 33 |
532182507 |
FOOTREST.LH.BLACK This part replaces 532181057. Price: $37.99 |
| 34 |
532182508 |
FOOTREST.RH.BLACK This part replaces 532181058. Price: $22.99 |
| 35 |
596136001 |
Bolts This part replaces 872110606. Price: $3.99 |
| 37 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 38 |
532175710 |
BRACKET.ASM.PIVOT.MOWER.REAR Price: $9.99 |
| 51 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 52 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 53 |
532144697 |
BRACKET.GRILLE.LH Price: $4.99 |
| 54 |
532161464 |
SCREW.HEX.WS.HD.8-18 X 7/8 Price: $3.99 |
| 55 |
532144696 |
BRACKET Price: $4.99 |
| 57 |
596230901 |
Screws This part replaces 874780412. Price: $2.99 |
| 58 |
532150127 |
AIR DUCT P/L/LT Price: $13.99 |
| 64 |
532154798 |
DASH LOWER Price: $17.99 |
| 142 |
532175702 |
PLATE REINFORCEMENT Price: $7.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 206 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 207 |
817670508 |
SCREW, 5/16-18 X 1/2 Price: $7.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 212 |
532174503 |
INSERT, LENS This part replaces 532156229. Price: $22.99 |
