| Ref | Part Number | Description |
|---|
| 1 |
1894595 |
S.R.E. Frame (Incl. Ref. #9-15) Price: Call Us |
| 1 |
530404367 |
Button - Tube Latch Price: $1.99 |
| 2 |
1876163 |
Rotor Assembly Price: Call Us |
| 3 |
1894594 |
Stator Assembly Price: Call Us |
| 3 |
530404204 |
Switch - on/off Price: $3.99 |
| 4 |
1970525 |
Frame Price: Call Us |
| 5 |
1116387 |
Regulator Price: Call Us |
| 5 |
530016120 |
Screw Price: $1.99 |
| 6 |
1971528 |
Diode Price: Call Us |
| 6 |
530403765 |
Tube - Blower This part replaces 530404358. Price: $37.99 |
| 7 |
1891055 |
Rectifier Bridge Price: Call Us |
| 7 |
530404374 |
Assy. Motor Price: $37.99 |
| 8 |
1894559 |
Brush Holder Brush Assy. Price: Call Us |
| 8 |
530404164 |
Spacer Price: $2.99 |
| 9 |
530400897 |
Washer Price: $1.99 |
| 9 |
9436831 |
Roller Bearing-S.R.E. Price: Call Us |
| 10 |
530404359 |
Impeller Price: $9.99 |
| 10 |
HY3225 |
DISCONTINUED This part replaces 908019. Price: Call Us |
| 11 |
1971411 |
Capacitor Price: Call Us |
| 12 |
1869573 |
Bracket Price: Call Us |
| 13 |
1894568 |
Terminal-Relay Price: Call Us |
| 14 |
1846900 |
Terminal Package Price: Call Us |
| 15 |
1961323 |
Oil-Seal Price: Call Us |
| 16 |
1971993 |
Bearing Retainer Price: Call Us |
| 18 |
1959991 |
Collar Outside Price: Call Us |
| 19 |
800832 |
Slinger Price: Call Us |
| 20 |
1956975 |
Bolt Price: Call Us |
| 27 |
1941978 |
Lockwasher Price: Call Us |
| 28 |
120622 |
Nut-Rectifier Bridge Price: Call Us |
| 29 |
1915172 |
Nut Price: Call Us |
| 31 |
1965104 |
Screw Price: Call Us |
| 32 |
1894586 |
Screw Washer-Brush Holder Attaching (Ground) Price: Call Us |
| 33 |
1876681 |
Screw Assy.-Brush Holder Attaching (Insulated) Price: Call Us |
| 34 |
436700 |
Screw-Brush Holder Attaching Pivot Price: Call Us |
| 35 |
1851612 |
Screw and Lockwasher Price: Call Us |
| 36 |
1851612 |
Screw and Lockwasher Price: Call Us |
| 37 |
1876668 |
Screw Washer-Rectifier Bridge Attaching Price: Call Us |
